Sharp MX-3610N Manuel utilisateur

OPERATION GUIDE - OPERATIONS COMMON TO ALL MODES

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01.htm[24/03/2011 2:55:57 PM]

MX-2610N / MX-3110N / MX-3610N

OPERATIONS COMMON TO ALL MODES

NAMES AND FUNCTIONS OF INDIVIDUAL PARTS

PERIPHERAL DEVICES

This section introduces peripheral devices that can be installed in the

machine. It also describes the names of the respective components of major

peripheral devices.

TOUCH PANEL

TURNING ON THE POWER

This section describes how to turn on/off the machine's power and how to

restart the machine.

CHANGING MODES

STOPPING/DELETING A JOB, PRIORITY PROCESSING AND

CHECKING THE STATUS

A job is a discrete unit of action such as copy, fax and image send. This

section explains how to stop a job and how to perform priority processing.

USER AUTHENTICATION

This function only allow registered users to use the machine. You can set

available functions by user, if needed.

CHARACTER ENTRY

ECO

LOADING PAPER

The following provides information you should know before loading paper.

LOADING PAPER INTO A TRAY

OPERATION GUIDE - OPERATIONS COMMON TO ALL MODES

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01.htm[24/03/2011 2:55:57 PM]

Index

LOADING PAPER INTO A LARGE CAPACITY TRAY

Use the large capacity tray for outputting massive prints that cannot be

processed using the regular tray (with a maximum capacity of 500 sheets).

Up to 3500 sheets can be stored.

LOADING PAPER INTO THE BYPASS TRAY

Use the bypass tray for printing on plain paper, envelopes, label sheets, tab

paper, and other special media.

HOW TO PLACE THE ORIGINAL

ADDRESS BOOK

beforehand so that you can easily retrieve them in fax or image send mode.

REMOTE OPERATION OF THE MACHINE

You can remotely operate the machine from the same panel as the

machine's operation panel that is displayed on your PC, with the same feel as

operating in front of the machine.

SHARP OSA

Using Sharp OSA, operation panel control and device functions such as scan

send can be linked to an external application.

OPERATION GUIDE - EXTERNAL PARTS

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-001.htm[24/03/2011 2:55:59 PM]

MX-2610N / MX-3110N / MX-3610N

EXTERIOR

Index Contents

OPERATIONS COMMON TO ALL MODES

This section describes the names and functions of the respective parts on the exterior of the

machine.

Tap the name to make its details pop up.

* Optional

OPERATION GUIDE - INTERNAL PARTS

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-002.htm[24/03/2011 2:56:00 PM]

MX-2610N / MX-3110N / MX-3610N

INTERIOR

Index Contents

OPERATIONS COMMON TO ALL MODES

This section describes the names and functions of the respective parts inside the machine.

Tap the name to make its details pop up.

OPERATION GUIDE - UPPER SIDE

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-003.htm[24/03/2011 2:56:01 PM]

MX-2610N / MX-3110N / MX-3610N

TOP

Index Contents

OPERATIONS COMMON TO ALL MODES

This section describes the names and functions of the respective parts on the upper side of

the machine.

Tap the name to make its details pop up.

OPERATION GUIDE - SIDE AND BACK

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-004.htm[24/03/2011 2:56:01 PM]

MX-2610N / MX-3110N / MX-3610N

SIDE AND BACK

Index Contents

OPERATIONS COMMON TO ALL MODES

This section describes the names and functions of the respective parts on the side and back of

the machine.

Tap the name to make its details pop up.

OPERATION GUIDE - OPERATION PANEL

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-005.htm[24/03/2011 2:56:02 PM]

MX-2610N / MX-3110N / MX-3610N

OPERATION PANEL

Index Contents

OPERATIONS COMMON TO ALL MODES

This section describes the names and functions of the respective parts of the operation panel.

Tap the name to make its details pop up.

You can change the angle of the

touch panel. Adjust the angle for

ease of viewing by pushing the

movable part of the touch panel to

the left.

The indicators of the operation panel may differ depending on the country and

region.

OPERATION GUIDE - TOUCH TYPES

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-006.htm[24/03/2011 2:56:03 PM]

MX-2610N / MX-3110N / MX-3610N

TOUCH TYPES

OPERATIONS COMMON TO ALL MODES

In addition to tapping, equivalent to

conventional touching, the touch panel of the

machine can be operated by long touching,

flicking and sliding.

Operation types

Operation on respective screens

Key (tapping)

List (tapping, sliding and flicking)

Slider (sliding)

Tab (tapping)

Operation types

Tapping

Touch the panel with your

finger and then lift it quickly.

Use this method to select a

key, tab or check box.

Long

touching

Touch the

panel with

your finger

and hold it for

a while.

Double tapping

Lightly tap the touch panel

twice. Use this function to

switch a preview mode or to

enlarge a preview image.

Flicking

Flick the panel

to scroll a

preview image

quickly.

Sliding

Slide the scroll bar (with your

finger touching the panel) to

scroll up and down a list with a

large number of items.

Dragging

Drag (slide

your finger

touching the

panel in a

random

direction) to

replace a

page in the

original during

preview.

Operation on respective screens

Key (tapping)

OPERATION GUIDE - TOUCH TYPES

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-006.htm[24/03/2011 2:56:03 PM]

List (tapping, sliding and flicking)

Slider (sliding)

A. Tap to select an item. The

selected key turns into a

different colour.

B. Tap numeric keys to enter

numbers.

C. Tap to increase or decrease the

value. Long touching causes the

value to be increased or

decreased until you stop

touching.

D. Activate to enable the

setting.

E. Tapping finalizes the setting

and then closes the screen.

A. Tap to select an item. The

selected item changes to a

different colour.

B. Drag the bar up and down.

It appears when the item does

not fit in the screen.

C. Flick the key upwards or

downwards. The item scrolls up

or down.

A. Slide the knob from side to side.

OPERATION GUIDE - TOUCH TYPES

file:///G|/Documents/Products/MX2610_3110_3610N/Operation%20Manual/MX3610OP_0122A1/mx3610_ex_ope/contents/01-006.htm[24/03/2011 2:56:03 PM]

Index Contents

Tab (tapping)

A. Tap a tab to switch what is

displayed.
