Sharp MX 3070 Mode d'emploi

Common Copier Printer

Fax Image Send Document Filing

Troubleshooting

Click the icon of the function you want to know more about.

Preface

ABOUT THIS GUIDE

This guide provides information about how to use the machine and what to do when a problem occurs.

If you encounter a problem, check this guide before calling a support center.

Please note

•This guide assumes that the persons who install and use this product have a working knowledge of their computer

and web browser.

•For information on your operating system or web browser, please refer to your operating system guide or web browser

guide, or the online Help function.

•The explanations of screens and procedures are primarily for Internet Explorer®on Windows®8. The screens may

vary depending on the version of the operating system or the software application.

•Wherever "MX-xxxx" appears in this guide, please substitute your model name for "xxxx".

•Considerable care has been taken in preparing this manual. If you have any comments or concerns about the manual,

please contact your dealer or nearest authorized service representative.

•This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or other

problem is discovered, please contact your dealer or nearest authorized service representative.

•Aside from instances provided for by law, SHARP is not responsible for failures occurring during the use of the

product or its options, or failures due to incorrect operation of the product and its options, or other failures, or for any

damage that occurs due to use of the product.

Warning

•Reproduction, adaptation or translation of the contents of the manual without prior written permission is prohibited,

except as allowed under copyright laws.

•All information in this manual is subject to change without notice.

CONTENTS

If the problem persists after you follow the instructions in this guide…

If you are unable to solve a problem using the solutions in this manual, press the [Power] button and then turn the main

power switch to the " " position. Wait at least 10 seconds and then turn the main power switch to the " " position.

After the main power indicator color changes to green, press the [POWER] button.

ABOUT THIS GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

General Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Copying Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Printing Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Image Send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Document Filing Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

When the background color of the job status display at the upper right corner of the touch panel is not gray, do not switch off

the main power switch or unplug the power plug. This may damage the hard drive or cause the data being stored or received

to be lost.

Points to Keep in Mind

For a checklist of general problems, refer to "CHECK LIST (page 7)".

Power and connector positions

Fax reception /

data indicator

Touch panel

Main power indicator

Power switch

Error indicator

[Power Save Mode]

button/Indicator

[Home Screen] key

LAN connector

(A type)

Main power switch

Extension telephone

jack (TEL)

Line jack (LINE)

OPERATION PANEL

Person sensor

General Problems

Placing the original and adding paper

Do not exceed the

indicator line Align the edges and place

face up Insert all the way in

Adjust to the original size

If the original has a fold, straighten the fold before placing. (This

prevents original mismfeeds and incorrect detection of the original size)

●Automatic Document Feeder

●Document glass

Place the original in the back left corner.

If the original has a fold, straighten the fold before placing.

(This prevents original misfeeds and incorrect detection of

the original size)

Mark

Platen

Scale

Original size

detection plate

●Paper tray

Fan the paper well before loading it.

Set the guides to the size of the paper.

The paper must not exceed the indicator line.

●Bypass tray

Pull the extension guide all

the way out.

Load the paper with the print

side facing down.

Set the bypass tray guides

to the width of the paper.

Is the original placed correctly?

Is the paper loaded correctly?

General Problems

Maintenance

How to clean the automatic document feeder and document glass

How to clean the bypass feed

Position of staple replacement and

staple jam explanation label

Discarding punch waste

Paper feed roller

Bypass feed roller

Toner cartridge

Toner container

●Inner finisher

●Finisher

●Saddle stitch finisher

●Inner finisher

●Saddle stitch finisher

●Finisher

Removing a toner

cartridge

General Problems

CHECK LIST

Alert Message Check Page

I CAN'T USE A PARTICULAR

FUNCTION OR PERIPHERAL

DEVICE

Have functions been disabled by the administrator? 9

I DON'T KNOW HOW TO CHECK

THE TOTAL NUMBER OF PAGES

USED

Hold down the [Home Screen] key. 9

You can check in the status of setting mode. 9

THE OPERATION PANEL CANNOT

BE USED

Is the main power indicator lit? 10

Did you just power on the machine? 10

Is the [Power Save Mode] button blinking? 10

Is a cover open or a device separated from the machine? 10

Did login fail three times in a row? 10

Does a message appear indicating that Auto Login failed? 10

Does the message "Call for service. Code:xx-xx*." appear in the touch

panel?

PRINTING IS NOT POSSIBLE OR

STOPS DURING A JOB

Is a tray out of paper? 11

Is the machine out of toner? 11

Has a paper misfeed occurred? 11

Is the output tray full? 11

Is the toner collection container full? 11

Are restrictions placed on the trays that can be used in each

mode(copy, print, image send, and document filing)?

I DON'T KNOW HOW TO PROHIBIT

COLOR PRINTING

You can prohibit color printing in User Control. 11

For copy mode, you can set copying to black & white priority. For

printing mode, you can set printing to black & white priority in the printer

driver settings.

THE ORIGINAL SIZE IS NOT

AUTOMATICALLY SELECTED OR

THE WRONG SIZE IS SELECTED

Is the original curled or folded? 12

Did you place an original smaller than 5-1/2" x 8-1/2" (A5) size? 12

THE DISPLAYED BYPASS TRAY

PAPER SIZE IS NOT CORRECT

Is the extension guide pulled out? 12

THE ORIGINAL MISFEEDS

(AUTOMATIC DOCUMENT FEEDER)

Is too much paper loaded into the document feeder tray? 12

Is the original a long original? 12

Is the original on thin paper? 12

THE PAPER MISFEEDS Is a torn piece of paper remaining in the machine? 13

Is too much paper loaded in the tray? 13

Are multiple sheets feeding at once? 13

Are you using paper that is not within the specifications? 13

Has the paper in the tray absorbed moisture? 13

Are the bypass tray guides adjusted to the width of the paper? 13

Is the bypass tray extension guide pulled out? 13

Is the bypass feed roller dirty? 13

Is 5-1/2" x 8-1/2" (A5) size paper loaded? 13

Is the paper size specified? 13

Did you add paper to the bypass tray? 13

PAPER DOES NOT FEED FROM

THE PAPER TRAY

Is the paper loaded correctly into the paper tray? 14

Has the tray been prohibited in some modes (copy, print, fax, image

send, document filing)?

I DON'T KNOW HOW TO CHANGE

THE PAPER SIZE

Set the paper size used in each tray in the tray settings. 14

General Problems

THE IMAGE IS SKEWED ON THE

PAPER

Is too much paper loaded into the bypass tray? 14

Are the bypass tray guides adjusted to the width of the paper? 14

Are the original guides adjusted to the width of the paper? 14

LINES APPEAR IN THE SCANNED


Are the scanning areas of the document glass or automatic document

feeder dirty?

Is the bypass feed roller dirty? 15

Did you clean the main charger of the photoconductive drum? 15

Did you clean the PT charger of the primary transfer belt? 15

Did you clean the laser unit? 15

SMUDGES APPEAR ON PRINTED

OUTPUT

Are you using paper that is not within the specifications? 15

Are you printing on pre-punched paper? 15

Does a message appear indicating the need for maintenance? 15

WHEN PRINTING ON THICK PAPER,

THE PRINT RESULT IS DIRTY FROM

THE 2ND PAGE ON

Has the paper type been set correctly? 16

I DON'T KNOW HOW TO CHANGE

THE OUTPUT TRAY

Is the output tray specified? 16

PART OF THE IMAGE IS CUT OFF Has the correct paper size been set? 16

Was the original placed in the correct position? 16

PRINTING TAKES PLACE ON THE

WRONG SIDE OF THE PAPER

Is the paper loaded with the print side facing in the correct direction? 17

A COVER OR INSERT IS NOT

PRINTED ON THE SPECIFIED

PAPER

Has the paper type been set correctly? 17

THE CONNECTED USB DEVICE

CANNOT BE USED

Is the USB device compatible with the machine? 17

Is the connected USB device recognized correctly? 17

Is the format of the USB memory device FAT32? 17

Are you using a USB memory device with a capacity of more than 32

GB?

THE FINISHER/SADDLE FINISHER

DOES NOT OPERATE

Does a message appear indicating that you need to remove paper from

the stapler compiler?

Have functions been disabled by the administrator? 18

STAPLING DOES NOT TAKE

PLACE(INCLUDING SADDLE

STITCH)

Does a message appear instructing you to check the staple unit? 18

Does a message appear instructing you to add staples? 18

Is a different width of paper mixed in? 18

Are there more sheets than can be stapled at once? 18

Is a paper size that cannot be stapled included in the print job? 18

Is the paper type setting of the tray selected in the printer driver set to a

paper type that cannot be stapled?

PUNCHING DOES NOT TAKE

PLACE

Does a message appear instructing you to check the punch module? 19

Is a different size of paper mixed in? 19

Is a paper size that cannot be punched included in the print job? 19

Is the tray selected in the printer driver set to a paper type that cannot

be punched?

THE STAPLING POSITION OR

PUNCH POSITION IS NOT

CORRECT

Is the stapling position set correctly? 19

Are the punching positions set correctly? 19

FOLDING DOES NOT TAKE PLACE Did the administrator enable the [Disabling of Duplex] setting? 19

Are you using a paper type that has a specific front and reverse side? 19

PREVIEW IMAGES OR THUMBNAIL

IMAGES DO NOT APPEAR

Are there a number of jobs waiting to be executed? 20

Alert Message Check Page

General Problems

THE TOUCH PANEL DISPLAY IS

DIFFICULT TO VIEW

Is the brightness properly adjusted? 20

YOU WERE LOGGED OUT

WITHOUT LOGGING OUT

YOURSELF

Did Auto Clear activate? 20

I DON'T KNOW WHERE THE IP

ADDRESS SETTING IS

The IP address is set in the Network Settings of Setting mode. 20

I DON'T KNOW HOW TO CHANGE

THE BACKGROUND COLOR OF

THE HOME SCREEN

You can change the background color in "MFP Display Pattern Setting". 21

I DON'T KNOW HOW TO ADD A

SHORTCUT TO OR DELETE A

SHORTCUT FROM THE HOME

SCREEN

You can change a shortcut in "Edit Home". 21

I DON'T KNOW HOW TO RESTORE

THE LARGE TEXT SETTING TO ITS

ORGINAL STATE

Is large text mode enabled in the home screen? 21

I DON'T KNOW HOW TO ADJUST

THE TIME THE MACHINE ENTERS

ENERGY SAVE MODE

Set the time the machine enters energy save mode in the Energy Save

settings of setting mode.

I FORGOT THE ADMINISTRATOR

PASSWORD

Was the administrator password changed from the factory default

setting?

I DON'T KNOW WHOM TO

CONTACT FOR MAINTENANCE

AND SERVICE

Please check the customer support information. 22

I CAN'T USE A PARTICULAR FUNCTION OR

PERIPHERAL DEVICE

Check Solution

Have functions been disabled by the

administrator?

■Check with your administrator.

Some functions may have been disabled in the setting mode. When user

authentication is enabled, the functions that you can use may be restricted in

your user settings.

I DON'T KNOW HOW TO CHECK THE TOTAL

NUMBER OF PAGES USED

Check Solution

Hold down the [Home Screen] key. ■When you hold down the [Home Screen] key, a message appears showing the

total page usage and toner level.

You can check in the status of setting

mode.

■[Total Count] appears in the [Status] of setting mode. You can check the total

pages used from this item.

Alert Message Check Page

General Problems

THE OPERATION PANEL CANNOT BE USED

Check Solution

Is the main power indicator lit? ■If the main power indicator is not lit up, turn the machine's power on.

Make sure that the power plug is firmly inserted in the power outlet, switch the

main power switch to the " " position,

Did you just power on the machine? ■Wait until a message appears indicating that the machine is ready.

After the [Power] button is turned on, the machine requires some time to

complete warmup operation. During warmup operation, functions can be

selected, but a job cannot be run.

Is the [Power Save Mode] button

blinking?

■Auto Power Shut-Off mode has activated. To return the machine to normal

operation, press the [Power Save Mode] button. For more information, see the

"User's Manual" .

Is a cover open or a device separated

from the machine?

■Read the message and take appropriate actions.

A warning message will appear when a cover is open or a device is separated

from the machine.

Did login fail three times in a row? ■After operation unlocks, log in using the correct user information.

When [A Warning when Login Fails] is enabled in the setting mode and login fails

3 times in a row, a warning will be displayed and user authentication operation

will lock for 5 minutes.

(If you do not know your user information, contact your administrator.)

"Setting mode" →[User Control] →[Default Settings]

→[A Warning when Login Fails]

Does a message appear indicating

that Auto Login failed?

■Check with your administrator.

Auto Login failed due to network or other problems. If you are the administrator,

tap the [Administrator Password] key, log in as an administrator, and temporarily

change the auto login settings in the setting mode. (Restore the changed settings

to their original state after the problems have been solved.)

Does the message "Call for service.

Code:xx-xx*." appear in the touch

panel?

*Letters and numbers appear in xx-xx.

■Turn on the machine power again.

■Make sure that the background color of the job status display at the upper right

corner of the touch panel is gray, and press the [Power] button and then turn the

main power switch to the " " position. Wait at least 10 seconds and then turn

the main power switch to the " " position.

■If the message still appears after switching the [Power] button and the main

power switch off and on several times, it is likely that a failure has occurred that

requires service. In this event, stop using the machine, unplug the power plug,

and contact your dealer or nearest SHARP Service Department. (When

contacting your dealer or nearest SHARP Service Department, inform them of

the displayed error code.)

Autres manuels pour MX 3070

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sharp Imprimante tout-en-un

Sharp

Sharp MX-M3071 Manuel d'instructions

Sharp

Sharp AL-2051 Mode d’emploi

Sharp

Sharp FO-3800M Manuel utilisateur

Sharp

Sharp AR-BC320 Manuel utilisateur

Sharp

Sharp PN-L602B Manuel utilisateur

Sharp

Sharp MX-M550 Manuel utilisateur

Sharp

Sharp AR-M160 Manuel utilisateur

Sharp

Sharp FO-DC535 Instructions d'installation et d'entretien

Sharp

Sharp AR-M237 IMAGERs Manuel utilisateur

Sharp

Sharp MX-3500N Manuel utilisateur

Sharp

Sharp MX-M753 Manuel utilisateur

Sharp

Sharp MX-M503N Manuel d'installation et d'exploitation

Sharp

Sharp MX-C402SC Mode d’emploi

Sharp

Sharp MX-C312 Mode d’emploi

Sharp

Sharp MX-4501N Manuel utilisateur

Sharp

Sharp AL-1655CS Manuel utilisateur

Sharp

Sharp AR-M280N Imager Manuel utilisateur

Sharp

Sharp MX-B382 Mode d’emploi

Sharp

Sharp AR-M270 Series Guide de configuration

Sharp

Sharp AL-2051 Manuel utilisateur

Sharp

Sharp MX 5500N - Color Laser - Copier Instructions d'utilisation

Sharp

Sharp AR-M277 IMAGERs Manuel utilisateur

Sharp

Sharp AL-1633 Manuel utilisateur

Sharp

Sharp MX-5001N Manuel d'installation et d'exploitation

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
