Sennheiser Ew 100 G4 Manuel utilisateur

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

Printed in Germany, Publ. 01/18, 575860/A01

Quick Guide

Kurzanleitung

Guide rapide

Guida rapida

Guía de inicio rápido

Guia rápido

Beknopte handleiding

Krótka instrukcja obsługi

Snabbguide

Kort vejledning

Pikaohje

Γρήγορος οδηγός

Kısa Kılavuz

Краткая инструкция

快速指南

快速使用指南

クイックガイド

퀵 가이드

ew 100 G4

Sennheiser Documentation App

or online at

www.sennheiser.com/download

ew 100 G4_

EM 100

SKM 100 SKM 100-S

Battery

Setup

Standard display

On Menu

Off

Low Battery

SK 100

MUTE MIC/LINE

ew G4

MHz

548.100

DATA

AFOUT

BAL/UNBAL ANTII ANTI

RFIN RFIN

DCIN 12V/300mA +18dBuMAX 12V/300mA

DATA

AF OUT

BAL/UNBAL ANT II ANT I

RF IN RFIN

DC IN 12V/300mA +18dBu MAX 12V/300mA

DATA

AF OUT

BAL/UNBAL ANT II ANT I

RF IN RFIN

12V/300mA +18dBu MAX 12V/300mA

DATA

AFOUT

BAL/UNBAL ANTII ANTI

RFIN RFIN

DCIN 12V/300mA +18dBuMAX 12V/300mA

OR OR

ew G4

MHz

548.100

MUTE MIC/LINE

548.100

ew100 G4

1. 1

PEAK

MUTE

-10

10 -20

-30

MHz

548.100

ew100 G4

1. 1

PEAK

MUTE

-10

10 -20

-30

MHz

548.100

ew G4

MUTE

MHz

548.100

ew G4

MUTE

MHz

548.100

B.Ch: 1.1

MUTE

B.Ch: 1.1

MUTE

ew G4

PEAK

-10

10 -20

-30

440 Hz

MUTE

533.875

ew100 G3

20.12

MHz

PEAK

-10

10 -20

-30

548.100

ew 100 G4

20.12

MHz

PEAK

-10

10 -20

-30

Instruction

Manual

Instruction

Manual

Squelch

Easy Setup

Frequency Preset

Name

AF Out

Equalizer

Auto Lock

Advanced

Exit

Main menu

“Menu”

Reset List

Current List

Scan New List

Exit

“Easy Setup”

Tune

Guitar Tuner

Pilot Tone

LCD Contrast

Reset

Software Revision

Exit

Extended menu

“Advanced Menu”

SET

DOWN

SET

ON/OFF

ESC

ON/OFF

ESC

KOR

Frequency

Pilot tone

RF on

Audio level

Change frequency

Sensitivity

Mute Battery

Auto lock

Peak hold

Name

Radio

frequency

level (RF)

Pilot tone

Audio level (AF)

Sensitivity

Diversity

Mute Battery

Auto lock

Squelch

Bank . Channel Frequency

Sync

Change frequency

Extended menu

“Advanced Menu”

Tune

Mute Mode

Cable Emulation

Pilot Tone

LCD Contrast

Reset

Software Revision

Exit

Tune

Mute Mode (SKM -S)

Pilot Tone

LCD Contrast

Reset

Software Revision

Exit

Extended menu

“Advanced Menu”

SKM

Main menu

“Menu”

Sensitivity

Frequency Preset

Name

Auto Lock

Advanced

Exit

A B CA C

6.3 mmXLR-3

SK/SKMEM

short

long

on + RX mute

on + RF mute

EM/SK/SKM

123123

long off

100 %

70 %

30 %

> 8 h

4 - 6 h

2 - 3 h

LOW BATT

ON/OFF

SET

ESC

SYNC

DOWN

575860_0118_A01_QG_EW_100_G4_PRT.pdf 1 15.11.2017 09:16:16

All manuals and user guides at all-guides.com

all-guides.com

Auto lock Mute

Squelch

Change frequency

New frequency

Sync

AF out

Sensitivity

SKM

Multichannel - Easy Setup

ME 2 | ME 4

ME 3-II

MUTE MIC/LINE

Instruction

Manual

Instruction

Manual

short

High

Middle

Low

Easy Setup

Scan New List

Easy Setup

Sync 758.200 MHz

B.Ch: 1. 1...12

Stored

Scan New List

734 . . . 776 MHz

Frequency Preset

B.Ch: 1.1

Frequency Preset

767.900 MHz

B.Ch. 15.6

Frequency Preset

767.900 MHz

B.Ch. 15. 6

Stored

Easy Setup

Free: 0 ...12

Bank 1 ... 20

MUTE MIC/LINE

ON/OFF

LEVEL

–24dB

Sensitivity

Instruction

Manual

DCIN 12V/300mA DCIN 12V/300mA

AFOUT

BAL/UNBAL

DATA

ANTII

ANTI

RFIN

RFIN DCIN 12V/300mA DCIN 12V/300mA

AFOUT

BAL/UNBAL

DATA

ANTII

ANTI

RFIN

DCIN 12V/300mA DCIN 12V/300mA

AFOUT

BAL/UNBAL

DATA

ANTII

ANTI

RFIN

RFIN DCIN 12V/300mA DCIN 12V/300mA

AFOUT

BAL/UNBAL

DATA

ANTII

ANTI

RFIN

Instruction

Manual

Instruction

Manual

SYNC

ESC

SYNC

SET

PEAK

-10

10 -20

-30

Easy Setup

Squelch

PEAK

-10

10 -20

-30

Low

PEAK

-10

10 -20

-30

AF Out

+18 dB

MUTE

PEAK

-10

10 -20

-30

PEAK

-10

10 -20

-30

Instruction

Manual

PEAK

-10

-20

-30

PEAK

-10

-20

-30

SYNC

PEAK

-10

10 -20

-30

SKM SKM 100

SK 100

SKM 100-S

EM 100

Locked Unlock?

SET SET

Locked Unlock?

Auto lock

10 s

RX Mute

On?

RX Mute

Off?

SET

RF Mute

On?

RF Mute

Off?

SET

AF Mute

Mute On

Mute Off

Mute On

Mute Off

RF Mute

321

132

SET SET SET SET

≤ 10 cm

≤ 4"

2 4

5 6

No frequency Squelch: Middle ...

Easy Setup EM Frequency Preset

EM, SK, SKM

SET

SET SET

SET

SKM/SK off!

WAIT

30s

–48 dB . . . 0 dB

–24 dB . . . +24 dB

–60 dB . . . 0 dB

AF PEAK

max.

12 channels

>12 channels

RJ 10

Bank 1 . . . 20; U

Channel 1 . . . 12

25 cm

(10")

ME 2

ME 4

2...3 cm

(1")

Advanced

SET

Mute Mode

Advanced

AF On/Off

Mute Mode

RF On/Off

Mute Mode
