Sennetech SCT-1034 Manuel utilisateur

1 SCT-1034 Ver. 1.0

CAMERACONTROLCODETRANSLATOR

ERNITECRS-485TOBOSCH BIPHASE Ver. 1.0

SCT-1034

www.sennetech.net

Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151

PRODUCT DESCRIPTION

TheSCT-1034 isanErnitectoBosch control code translator designedtopermitcontrolof Bosch

camerasfromErnitec VIP-1500 controllers. ItreceivesErnitecRS-485 commands and transmits

theappropriate commandsinBosch biphaseformat.Therearefour independentbiphaseoutputs.

Thebiphase outputcanbe limitedtofixed-speed-onlycommandsfor compatibilitywitholder Burle

receivers.

Inputandoutput connectionsaremade with matingscrewterminal connectors. FrontpanelLEDs

indicatestatusof power,receive,and transmit.

There is an optional 19" rack mount panel (one rack unit high).

SPECIFICATIONS

SIZE: 5.57"W x 1.52H x 5.45D

WEIGHT: 1.5 lbs.

POWER: 9Volt to 15VoltAC or DC at 75ma

INDICATORS: Front panel LEDs: Power, Rx, & Tx

RS-485INPUT(2400baud): (1) mating3-pinscrewterminal connector

BIPHASEOUTPUT: (4) mating 3-pinscrewterminalconnectors

3 SCT-1034 Ver. 1.0

SETTING THE SWITCHES

Tosetthe configuration switches,removethe

back panel, which is secured by two screws.

Then slide the cover back to expose the

switches.The switches canbechanged while

thecode translatorispoweredupandthenew

settings will take effect immediately.

CONFIGURATION

SWITCH

SW1-1

BIPHASECODETYPE

ON: VARIABLE SPEED

OFF: FIXEDSPEED

SettoONif thereceivers canaccept

variablespeedbiphasecode

Setto OFFfor olderreceivers thatonly

recognizefixedspeedcommands

12345678

OFF

INSTALLATION

REAR PANEL

Power

input

Ernitec

RS-485input

Connectto the+and-lines

fromthe Erniteccontroller

S=shield (optional)

(Datainput is2400 baud)

Bosch biphase

outputs

Thefour outputsare identical.

Connectto theBoschreceiver

biphase+ and-lines

S=shield (optional)

FRONTPANEL

Power

indicator

TheRx indicator willflashwhenever thereisdatafromthe Erniteccontroller. Iftheinput lineshave

reversedpolarity, the Rxindicatorwillbe on solidly.Biphase codeisrepeating,so theTx indicator

will continue to flash while the camera is moving.

If you have Rx but no Tx, possible causes are:

The Ernitec code coming into the translator is not camera control code.

The Ernitec data out is not set at 2400 baud.

If the code translator is sending data and does not get a follow-up Ernitec command in about 12

seconds, it will time out and quit sending that stream of data.

Ernitec

receive

indicator

Flasheswhen

receivingRS-485

data

Bosch

transmit

indicator

Flashes continu-

ouslywhile sending

biphasedata

BIPHASEDATAOUTPUTSERNITEC

RS-485 IN POWER

12V to 15V

AC or DC

SSSS

Power TxRx

CODETRANSLATOR

5 SCT-1034 Ver. 1.0

OPERATION

Pan, Tilt, Zoom, Focus, and Iris commands are converted directly.

Ernitec Store and Recall pre-position commands are converted to Bosch Set and Shot com-

mands.

Aux 1 is converted toAux ON 1, which is interpreted by the Bosch domes asAutoscan (without

limits).

Aux 2 is converted to Aux ON 2, which is interpreted by the Bosch domes as Autopan (within

limits).

PAN &TILT SPEEDS

If the code translator is configured for fixed speed Bosch receivers, the Pan and Tilt commands

havenospeed value associatedwiththem.

TheErniteccontrollerdoes not send speed values forPanandTiltcommands.

Ifthe codetranslatoris configuredforvariable speedBoschreceivers,thecode translatorwillgive

aspeed valuetoPan andTiltcommands.Onpower-up, thedefaultis amediumspeed.Aux3 and

Aux 4 are used to change the Tilt speed value.Aux 5 andAux 6 change the Pan speed.

Eachtimeone of thoseAuxbuttons is pressed, asmallchangeis made to theassociatedspeed.

Aux 3 Decreasetiltspeed

Aux 4 Increasetiltspeed

Aux 5 Decrease panspeed

Aux 6 Increase panspeed

March 2003 SCT-1034 Ver. 1.0
