Sena EXPAND MESH Manuel utilisateur

USER’S GUIDE

ENGLISH

SENA

Version 1.0.0

TABLE OF CONTENTS

1. ABOUT THE EXPAND MESH 5

1.1 Product Features 5

1.2 Product Details 6

1.3 Package Contents 7

1.4 Wearing the Headset 7

2. GETTING STARTED 8

2.1 Downloadable Sena Software 8

2.1.1 Sena Outdoor App 8

2.1.2 Sena Device Manager 8

2.2 Charging 8

2.3 Legend 9

2.4 Powering On and Off 9

2.5 Checking the Battery Level 9

2.6 Volume Adjustment 10

3. PAIRING THE HEADSET WITH OTHER

BLUETOOTH DEVICES 11

3.1 Phone Pairing 11

3.1.1 Initially Pairing the Expand Mesh 11

3.1.2 Pairing When the Expand Mesh is Turned Off 12

3.1.3 Pairing When the Expand Mesh is Turned On 12

3.2 Second Mobile Phone Pairing - Second

Mobile Phone and SR10 13

4. MOBILE PHONE USAGE 14

4.1 Making and Answering Calls 14

TABLE OF CONTENTS CONTINUED

4.2 Speed Dialing 14

4.2.1 Assigning Speed Dial Presets 14

4.2.2 Using Speed Dial Presets 14

5. STEREO MUSIC 16

5.1 Playing Music with Bluetooth Devices 16

6. MESH INTERCOM 17

6.1 What is Mesh Intercom? 17

6.1.1 Open Mesh 18

6.1.2 Group Mesh 18

6.2 Starting Mesh Intercom 19

6.3 Using the Mesh in Open Mesh 19

6.3.1 Channel Setting (Default: channel 1) 19

6.4 Using Mesh in Group Mesh 20

6.4.1 Creating a Group Mesh 20

6.4.2 Joining an Existing Group Mesh 21

6.5 Enable/Disable Mic (Default: Enable) 22

6.6 Toggling Open Mesh/Group Mesh 22

6.7 Reset Mesh 22

7. MESH AUDIO MULTITASKING (ALWAYS ON) 23

8. FUNCTION PRIORITY AND FIRMWARE

UPGRADES 24

8.1 Function Priority 24

8.2 Firmware Upgrades 24

TABLE OF CONTENTS CONTINUED

9. CONFIGURATION SETTING 25

9.1 Headset Conﬁguration Menu 25

9.2 Software Conﬁguration Setting 25

9.2.1 Headset Language 26

9.2.2 VOX Phone (Default: Enable) 26

9.2.3 VOX Sensitivity (Default: 3) 26

9.2.4 Intercom-Audio Overlay Sensitivity (Default: 3) 26

9.2.5 Audio Overlay Volume Management

(Default: Disable) 26

9.2.6 Voice Prompt (Default: Enable) 26

10. TROUBLESHOOTING 27

10.1 Fault Reset 27

10.2 Factory Reset 28

Expand Mesh Bluetooth®Headset with Mesh Intercom™ | 5

1. ABOUT THE EXPAND MESH

1.1 Product Features

Bluetooth®5.2

Mesh Intercom up to 0.4 km (0.2 mi)*

Audio Multitasking™

* in open terrain

CHAPTER

Expand Mesh Bluetooth®Headset with Mesh Intercom™ | 6

1 ABOUT THE EXPAND MESH

1.2 Product Details

DC Power Charging &

Firmware Upgrade Port

Status & Charging LED

Microphone

Center

Button

Speakers

Mesh Intercom Button

(-) Button

Center Button

(+) Button

Left Side

Expand Mesh Bluetooth®Headset with Mesh Intercom™ | 7

1 ABOUT THE EXPAND MESH

1.3 Package Contents

Headset Speaker Pads USB Power & Data Cable

(USB-C)

1.4 Wearing the Headset

Right Left

Left Side Front

1. Check that the speaker with microphone is placed on the left ear.

2. Adjust the microphone to be located at a proper distance from your

mouth.

Note: Proper ﬁt on your ear and head is important both for comfort

and optimal noise-reduction performance.

Expand Mesh Bluetooth®Headset with Mesh Intercom™ | 8

2. GETTING STARTED

2.1 Downloadable Sena Software

2.1.1 Sena Outdoor App

By simply pairing your phone with your headset, you can use the Sena

Outdoor App for quicker, easier set up and management.

Sena Outdoor

• Download the Sena Outdoor App on Google Play Store or App

Store.

2.1.2 Sena Device Manager

The Sena Device Manager allows you to upgrade firmware and

configure settings directly from your PC.

Sena Device Manager

• Download the Sena Device Manager at sena.com.

2.2 Charging

Charging the Headset

Depending upon the

charging method, the

headset will be fully

charged in about 2.0 hours.

CHAPTER

Expand Mesh Bluetooth®Headset with Mesh Intercom™ | 9

2 GETTING STARTED

Note:

• Please make sure to take off your headset while charging. The

headset automatically turns off during charging.

• Any 3rd party USB charger can be used with Sena products if the

charger is approved by either the FCC, CE, IC or other locally

approved agencies.

• Use of a non-approved charger may cause ﬁre, explosion,

leakage, and other hazards which may also reduce the life time or

performance of the battery.

• The headset is compatible with 5 V input USB-charged devices

only.

2.3 Legend

TAP Tap button the speciﬁed

number of times 10s

HOLD Press and Hold button for

the speciﬁed amount of time

“Hello” Audible prompt

2.4 Powering On and Off

Powering On

=1s

HOLD

Powering Off

=1x

TAP

2.5 Checking the Battery Level

Instructions are for when powering the headset on.

Powering On

=1s

HOLD

Note: When the battery is low while in use, you will hear a voice

prompt saying “Low battery”.

Expand Mesh Bluetooth®Headset with Mesh Intercom™ | 10

2 GETTING STARTED

2.6 Volume Adjustment

You can raise or lower the volume by tapping the (+) Button or the

(-) Button. Volume is set and maintained independently at different

levels for each audio source (i.e., phone, intercom), even when the

headset is rebooted.

Volume Up

=1x

TAP

Volume Down

=1x

TAP
