Sena SR10 Manuel utilisateur
Users Guide
www.senabluetooth.com
INTRODUCTION
PACKAGE CONTENTS
INSTALLING THE SR10
POWERING ON/OFF AND CHARGING
• Powering On
• Powering Off
• Charging
• Low Battery Warning
PAIRING THE SR10 WITH BLUETOOTH DEVICES
• Bluetooth Headset Pairing
• Bluetooth Mobile Phone Pairing
USING THE SR10
• Using Two-way Radios
• Installing Wired PTT Button
• Ports and Cables
• Using Mobile Phone
• Audio Channel Open and Close
• Reset to Factory Default Settings
CONTENTS
4
7
9
10
10
10
11
11
12
12
12
13
13
13
14
15
15
17
English
• Fault Reset
QUICK REFERENCE
BATTERY INFORMATION
MAINTENANCE AND CARE
DISPOSAL
CERTIFICATION AND SAFETY APPROVALS
• FCC Compliance Statement
• FCC RF Exposure Statement
• FCC Caution
• CE Declaration of Conformity
• Industry Canada Statement
• Bluetooth License
WAIVER AND GENERAL RELEASE
• Two-Year Limited Warranty
• Limitation of Liability
• Return for Full Refund
WARNING
17
18
19
20
21
22
22
23
23
24
24
25
26
30
31
32
33
4
INTRODUCTION
Thank you for choosing the SENA SR10. The SR10 is a Class 1
Bluetooth two-way radio adapter and mobile phone hands-free
gateway based on Bluetooth 2.1+EDR technology. Users can
connect various two-way radios in the market with the SR10 and
connect wirelessly to a variety of Bluetooth communication headsets.
At the same time, as a Bluetooth mobile phone hands-free gateway, the
SR10 lets users connect Bluetooth headsets to mobile phones
as well. With the SR10, users can use a hand held two-way radio
and a Bluetooth mobile phone simultaneously with a single Bluetooth
headset.
The SR10 has two AUX input ports for wired connection of
non-Bluetooth devices such as GPS, radar detector, laser
detector, or non-Bluetooth mobile phone. Along with the SR10,
users can talk by phone or by two-way radio at the same time,
listen to the radar detector alarm or GPS voice guidance.
English
5
The SR10 can cover such a variety of applications including motorcycle
CB communications, outdoor sports activities, event security, hunting,
motorsports pit crew and other forms of intercom communications.
Please read this user’s guide carefully before using the SR10. Also
refer to www.senabluetooth.com for the latest version of the user’s
guide and additional information related to SENA Bluetooth
products.
Features:
•Bluetooth hands-free adapter for two-way radios
•Bluetooth hands-free gateway for Bluetooth mobile phones
•Connect 1 two-way radio and 1 mobile phone simultaneously
•Compatible with standard stereo or mono Bluetooth headsets
•Two AUX inputs for wired connection of non-Bluetooth devices;
GPS, radar detector, laser detector or non-Bluetooth mobile phone
•Motorcycle handlebar mount and belt clip
•Optional 12V bike-powered kit with on/off control by ignition switch
•Water resistant for use in inclement weather
•Firmware upgradeable
•Two-year limited warranty
Technical Specifications:
•Bluetooth v2.1+EDR, Class1
•Supporting profiles: Headset Profile, Hand-Free Profile (HFP)
•Operation time: 12 hours
•Standby time: 10 days
•Batter charging time: 3.5 hours
•Lithium polymer battery
•Dimensions: 108 mm x 52 mm x 29 mm (4.3 in x 2.0 in x 1.1 in)
•Weight: 81g (2.86 oz)
•CE, FCC, TELEC, IC
6
English
PACKAGE CONTENTS
Pairing Button
• Bluetooth Headset Pairing Mode
• Mobile Phone Pairing Mode
AUX1
• GPS Navigation or Radar/Laser Detector
2.5mm jack for wired PTT Button
AUX2
• Mobile Phone, GPS Navigation,
Radar/Laser Detector
PTT Button
• Two-way Radio Activation
• Audio channel forced open
DC Power Charging &
Firmware Upgrade Port
Mini-DIN port
for two-way radio devices
7
• Main Unit
8
• DC Power Charger
• USB Power Cable
• 3.5mm Audio Jack Cable
• Wired PTT Button Extension
• Belt Clip Kit
• Handlebar Mounting Kit
English
9
INSTALLING THE SR10
• Installing on the Handle Bar
1. Place the rubber on the back of the main unit.
2. Put the joint pad on top of the rubber, and tighten the screw.
3. Place the main unit on the handle bar, wind the rubber band,
and hang it on the hook.
• Placing on the Belt / Pocket
1. Place the belt-clip on the back of the main unit, and tighten the screw.
2. Place the main unit on the belt with belt-clip.
10
POWERING ON/OFF AND CHARGING
To power on and off the adapter, you don’t need to press and
hold any button for several seconds. Just short press the Pairing
Button and the PTT Button simultaneously, and you will get quick
on-and-off convenience.
• Powering On
Press and hold the pairing and the PTT button at the same time
for about 1 second to turn the power on. When the power is on,
the blue LED light turns on.
• Powering Off
Press pairing button and PTT button at the same time for about 1
second to turn the power off. The Red LED light turns on for about
3 seconds. The SR10 is now powered off.
