Sena +MESH Manuel utilisateur
+MESH
BLUETOOTH TO MESH INTERCOM ADAPTER
2.2.0
QUICK START GUIDE
ENGLISH
2
RIDE CONNECTED
The +Mesh features Sena’s Mesh Intercom
technology allowing your group to seamlessly
communicate, even if a rider falls out of range.
Pair your headset or helmet from Sena to the
+Mesh to start talking with other riders using
Mesh Intercom. With built-in Bluetooth®, HD
Intercom™, technology has never felt so minimal
or freeing.
Mesh Intercom™
800 meters/880 yards*
Bluetooth®4.1
* in open terrain
3
GETTING STARTED
1. Update this product for free with the latest
firmware to fully enjoy the new advanced
features built into this product. Visit sena.com
to see how to update your product.
2. Users can follow Sena on Facebook, YouTube,
Twitter and Instagram to receive the most up
to date information on products, helpful tips
and all other announcements regarding Sena
products.
SENA Technologies, Inc.
sena.com
Customer Support: support.sena.com
4
TABLE OF CONTENTS
1. ABOUT THE +MESH 6
1.1 Product Details 6
1.2 Package Contents 6
1.3 Installing the +Mesh 7
1.3.1 Using the Handlebar Mounting Kit 7
1.3.2 Placing on the Mounting Cradle 7
2. BASIC OPERATION 8
2.1 Downloadable Sena Software 8
2.1.1 Sena +Mesh App 8
2.1.2 Running the Sena +Mesh App 8
2.1.3 Sena Device Manager 9
2.2 Powering On and Off 9
2.3 Charging 9
2.4 Checking the Battery Level 9
3. MESH INTERCOM 10
3.1 What is Mesh Intercom 10
3.1.1 Open Mesh 10
3.2 SENA Products That Can Communicate with
+Mesh via Mesh Intercom 11
5
3.3 Using the Mesh 11
3.3.1 Bluetooth Pairing with a Sena Headset
or Helmet 12
3.3.2 Mesh Intercom On and Off 12
3.3.3 Mesh Intercom Reconnection 13
3.4 Using the Mesh in Open Mesh 14
3.4.1 Channel Setting (Default: channel 1) 14
4. TROUBLESHOOTING 15
4.1 Firmware Upgrade 15
4.2 Fault Reset 15
4.3 Factory Reset 15
QUICK REFERENCE 16
6
1. ABOUT THE +MESH
1.1 Product Details
Mesh Intercom
Antenna
Status LED
Multi-function Button
DC Power Charging &
Firmware Upgrade Port
1.2 Package Contents
Main Unit Mesh Intercom
Antenna
Handlebar
Mounting Kit
Mounting
Cradle
USB Power &
Data Cable
7
ABOUT THE +MESH
1.3 Installing the +Mesh
Install the +Mesh where the antenna is not blocked by the
human body as much as possible.
When the human body is blocking the antenna, the Mesh
intercom signal strength will be weakened.
1.3.1 Using the Handlebar Mounting Kit
1. Place the handlebar mounting kit on the handle bar, wind
the rubber band around the handle bar, and hang it on
the hook.
2. Attach the handlebar mounting kit on the back of the
main unit along the guide rail until you hear a click.
1.3.2 Placing on the Mounting Cradle
1. Locate a proper surface on your motorcycle body, clean
the body surface location with a moistened towel, and
allow to dry thoroughly.
2. Peel off the cover of the adhesive tape of the mounting
cradle and attach the unit on the proper surface of your
motorcycle.
3. Attach the mounting cradle on the back of the main unit
along the guide rail until you hear a click.
Note: Make sure that the main unit sticks on your
motorcycle body firmly. Maximum adhesion occurs after
24 hours.
8
2.1 Downloadable Sena Software
2.1.1 Sena +Mesh App
You can use the Sena +Mesh App without pairing your
Smartphone to the +Mesh.
• Download
– Android: Google Play Store > Sena +Mesh App
– iOS: App Store > Sena +Mesh App
2.1.2 Running the Sena +Mesh App
1. Turn on the product.
2. Press and hold the Multi-function Button for 5 seconds
to enter Bluetooth Pairing.
3. Launch the Sena +Mesh App on your Smartphone.
4. Scan the product in the app.
• When you launch the app, the product is automatically
scanned.
• Tap the Scan icon ( ) to manually scan the product.
5. After scanning is complete, select the scanned product in
the app.
Note:
• If the product has not been scanned in the app, please
update the product to the latest firmware.
• How to identify the scanned product in the app
You can identify the product by the
six-letter code on the label on the
back of your product. XXXX
XXXX
XXXXXX
XXXXX
2. BASIC OPERATION
9
BASIC OPERATION
2.1.3 Sena Device Manager
The Sena Device Manager allows you to upgrade the
firmware from your PC or Apple computer. Download the
Sena Device Manager from sena.com.
2.2 Powering On and Off
To power on the +Mesh, press and hold the
Multi-function Button for 1 second.
To power off the +Mesh, press and hold the
Multi-function Button for 1 second.
2.3 Charging
The +Mesh can be charged using many common methods
via the supplied USB power & data cable. The LED turns
red while the headset is charging and turns blue when it is
fully charged. Depending upon the charging method, the
headset will be fully charged in about 2 hours.
Note: The +Mesh is compatible with 5 V input USB-
charged devices only.
2.4 Checking the Battery Level
When the +Mesh is powering on, the red LED flashes
rapidly indicating the battery level.
4 flashes = High, 70~100%
3 flashes = Medium, 30~70%
2 flashes = Low, 0~30%
10
3.1 What is Mesh Intercom
Sena proposes using Mesh Intercom™, which provides
instant and effortless bike-to-bike communication without a
pre-grouping process.
Mesh Intercom allows riders to connect and communicate
with nearby users without the need to pair each headset
together.
The working distance between each +Mesh in Mesh
Intercom can be up to 800 meters (880 yards) in open
terrain. In open terrain, the Mesh can be extended up to 3.2
km (1.9 miles) between a minimum of 6 users. 6 users can
talk at the same time for an optimized, open group intercom
conversation. Users can freely connect with each other.
3.1.1 Open Mesh
Open Mesh is an open group intercom function. Users
can freely communicate with each other in the same Open
Mesh channel and select which channel (1-9) to use through
the Sena +Mesh App.
It can connect with a virtually unlimited number of users in
each channel.
C
E
F
DB
A
3. MESH INTERCOM
