Selesta Ingegneria S.p.A.
Attention: don't expose the RFIDat and RFIDock/M/S/AL products
to heat sources, direct solar light, humidity or rain. Avoid immersion
in water or other liquids. Don't tamper with pierce or burn the
system components. Don't leave the system components
unguarded and to the reach of children or animals.
Attention: in case of possible operational anomalies or accidental
damages to the system components, immediately interrupt its use
and turn to the local authorized Retailer to ask for assistance.
Warranty
The products are warranted against any defect in material and workmanship,
under normal use, for the designed warranty period. The warranty becomes
effective from the date of shipment. In the event these products are found to
be defectives within the warranty period, its will be repaired or replaced.
The warranty non cover wear and tear on covers or housing and batteries.
The warranty is void if the products :
• have been opened
• have been repaired, modified or altered or had work performed by not
authorized service centre.
• was subjected to abuse, neglect, electrical fault, improper packaging,
accident or acts of nature
• were installed improperly
No damage can be claimed for possible delays in repair time or replacement.
Every responsibility for possible damages that could, directly or indirectly,
derive to people, goods or animals as a consequence of not observing the
prescribed indications is declined.
Instruction Manual – Ver. 1.4 ‐16/10/2009 – pag. 10 of 12
Selesta Ingegneria S.p.A.
Components technical characteristics
RFIDat: hand held terminal
RFIDat reads, in Radio Frequency mode, the internal ID code of passive
trasponders (TAGs) and, at each reading, records in its memory: date, time,
TAG ID code and RFIDat identification code.
Instruction Manual – Ver. 1.4 ‐16/10/2009 – pag. 3 of 12
RFIDat Passive trasponder (TAG) reader
TAG reading mode Contactless in RF (Radio Frequency)
TAG type 125 kHz passive, class EM4102 (or compatible)
Memory capacity Up to 8.000 transactions
Display
LCD 128 x 64 points matrix for the visualization of:
‐Assigned name to RFIDat
‐Date and Time
‐Number of readings done
‐Battery level
Clock Self ‐powered quartz, max. drift: 10 sec . / month
(at 20 – 30 °C)
Power‐on With tactile retro‐lighted key
Reading done signal Buzzer and blue LED in the key
Data transmission to RFIDock/x In RF (Radio Frequency), two way
Modes of operation “single reading” ‐“continuous reading" ‐"Master"
See points a), b) and c)
Batteries Metalhydrated Nickel
Batteries autonomy Minimum 60 days (in single reading mode) or
3.000 readings (in continuous reading mode)
Complete battery
recharging time
At least 30 hours through lodging in RFIDock unit. When
the RFIDat readers are in storage, is required to perform
one complete recharging cycle at least every 5 months.
Mechanical resistance 50 cm. fall on concrete
Dimensions and weight 59 x 44 x 14 mm. ‐38 g
