SelectBlinds Lift & Lock Manuel utilisateur

INSTALLATION INSTRUCTIONS

Lift & Lock™ for Horizontal Blinds

6/2016

Installating Your New Horizontal Blinds

Please take a moment to review the contents of your package. Your package

should contain the following:

1. Left and Right Box Style Mounting Brackets

2. Mounting Bracket Screws, Two per Blind are provided.

3. Valance Clips (valance attachment varies by product)

4. Center Support Brackets and Support Screws (included only when needed)

Mounting Brackets

The box style mounting brackets are designed to work in all possible

mounting applications. The diagram at the bottom of this page indicates

which screw holes should be used for each option. Mount brackets as shown

below. Always use all brackets supplied. All blinds over 48” wide require

the use of center support brackets - be sure to mount support bracket(s) in

position(s) that will not interfere with the lift mechanisms.

Ceiling Mount Inside Mount

Outside Mount

Important Note:

Always use at least two screws per bracket to ensure a strong,

secure mount.

Brackets Required

All blinds require two mounting brackets (included). All 2 on 1 blinds receive

one support bracket. All 3 on 1 blinds receive two support brackets. Center

support brackets for 2 on 1 and 3 on 1 blinds should be placed between blind

panels.

Blind Width: Number of Centter Support Brackets:

over 48” one support bracket

over 96” two support brackets

When using extension brackets (see page 5), certain widths require the use of

one or more support brackets.

Blind Width: Number of Support Brackets:

over 30” one support bracket

over 60” two support brackets

over 90” three support brackets

Installing the Headrail

Position the headrail in the box style mounting bracket as shown. Swing the

covers down and snap them closed. Secure headrail to center support bracket

with a tek screw.

If you received valance clips with your order, it is important to install the valance

clips prior to mounting the headrail into the installation brackets. See Valance

Installation for details.

Mounting

BracketBracket Bracket

Space Evenly Space Evenly

Mounting

Center Support

Center Support Bracket

Valance Installation

The type of valance attachment included in your package will vary depending

on the product you have ordered. Several products utilize the magnet system

which allows you to simply place the valance directly on to the headrail. No

clips are necessary.

To attach the valance clips to the front of the headrail, simply push down on the

clip to snap it into place. Install one bracket at each end of the headrail and

space others evenly. Do not place clips more than 48” apart.

Note: If the valance is outside mounted, attach the valance returns using the

provided “L” brackets. Simply slide the “L” bracket on to both slots in the back-

side of the valance and returns.

Tilt Wand Attachment

1. Attach wand to tip over the end of the tilter hook.

2. Slide the clear cover down to old the wand into place.

Optional Components

Spacer Blocks

Use spacer blocks or extension brackets to project the standard mounting

brackets out over obstructions (such as window moldings or ledges).

Align holes in back of bracket to holes in spacer block and secure to wall with

screws. Two spacer blocks per bracket may be used for additional projection.

Spacer Block with

Center Support

Spacer Block with

Mounting Bracket

Optional Components

Extension Bracket

Attach 2” or 4” extension brackets to the mounting surface in the same

locations where the end brackets and intermediate brackets would be

attached. Use the provided screws to mount each extension bracket.

IMPORTANT: The tops of the end brackets and intermediate bracket(s)

must align.

Optional Components

Hold Down Bracket

Use hold-down brackets to prevent blinds from swaying when mounted on

doors or exposed to the wind. Screw hold-down bracket into the lower corner of

window jam or sill. Drill a small hole in the center of the bottom rail to slip hold-

down pin (extending from hold-down bracket) into blind.

Sill

Mount

Outside Mount

Mounting

Bracket with

Extension Bracket

Center Support

Bracket with 2”

Extension Bracket

Center Support

Bracket with 4”

Extension Bracket

Raising and Lowering the Blind

To Raise the Blind:

- Prior to raising or lowering, tilt the slats to the open position using the tilt

mechanism on the left or right side of the blind.

- Grasp the bottom rail near the center with one hand while balancing the

bottom rail with your other hand.

- Fully press the center button with your thumb and gently lift the bottom rail.

- Allow the slats to stack evenly by gradually lifting the bottom rail while the

center button is fully depressed.

- Hold the rail still at the desired position while releasing the button.

For inside mount blinds: When raising the blind, pull the bottom rail slightly

toward you. Press the center button and gently raise the bottom rail. Once the

desired height is reached, hold the rail in place while releasing the button. Place

the blind back into the window opening and the blind will stay in that position.

To Lower the Blind:

- Prior to lowering the blind, fully press the center button with your thumb and

pull the bottom rail down to the desired height while the button is fully

depressed.

- Once the blind reaches the preferred position, hold it there while releasing the

button and the blind will stay in that position.

For inside mount blinds: When lowering the blind to the full-down position, pull

the bottom rail down and slightly toward you, approximately 1” beyond the sill.

Release the button, then lift and place the bottom rail up onto the sill.

Troubleshooting

Problem: The bottomrail is not level or the blind hangs crooked

Solution: Check that the headrail and installation brackets are level and

aligned. Shim the installation brackets if necessary.

NOTE: All skew adjustment features are located under the headrail.

To level the blind, raise the low side of the bottom rail by turning the screw

adjustment feature on the headrail clockwise with a coin or screwdriver while

lifting the weight from the bottom rail.

NOTE: Turn the scew sdjustment that is onthe same side as the low side of the

bottomrail.

If the blind height is too long, turn all the skew adjustment features clockwise to

raise the entire bottom rail to the desired height while lifting the weight from the

bottom rail. There is an adjustment range of approximately 1-1/4”.

Problem: The blind makes a ratcheting noise while the center button is

pushed in and the bottomrail is being raised.

Solution: Push harder on the center buttom. The button must be fully

depressed to raise or lower the blind.

Problem: When raising the blind, slats are not stacking evenly and falling over

the bottom rail.

Solution: The blind was raised too quickly. Gently raise the bottom rail to give

the lift cords time to retract. The slats will then stack evenly on the bottom rail.

Removing the Blind - if necessary

- Fully raise the blind

- Remove the valance.

- Push up on the bottom of the bracket to release the locking tab.

- Carefully pull the blind to remove it from the brackets.

Child Safety

Young children can STRANGLE in cord loops. They can also wrap cords around

their necks and STRANGLE. In addition, inner cords can pull out to form a loop,

which can STRANGLE a young child.

- Always keep cords out of the reach of children.

- Move cribs, playpens and other furniture away from

cords. Children can climb furniture to get to cords.

- Do not tie cords together. Make sure cords do not

twist together and create a loop.

Young children can STRANGLE in cord loops. They can also

wrap cords around their necks and STRANGLE. In addition,

inner cords can pull out to form a loop, which can STRANGLE

a young child.

Always keep cords out of the reach of children.

Move cribs, playpens and other furniture away from cords. Children can climb

furniture to get to cords.

Do not tie cords together. Make sure cords do not twist together and create a loop.

The cords on this product present

a potential strangulation hazard.

For child safety, consider cordless

alternatives or products with

inaccessible cords.

WARNING ADVERTENCIA

Los cordones de este producto representan

un peligro potencial de estrangulamiento.

Para la seguridad de los niños, utilice

alternativas sin cordón o productos cuyos

cordones sean inaccesibles.

MISE EN GARDE

Les câbles de ce produit représentent un

danger potentiel de strangulation.

Pour la sécurité des enfants, pensez au sans fil,

ou procurez-vous des produits dont les câbles

ne sont pas accessibles.
