Specify alarm input setting Master
With connection to an alarm system and peripheral
equipment sold separately, an alarm input signal can alter
the lock’s operation with one of the settings below:
Ignore input signal (Default)
Input signal remote blocks (Prevents the lock from being
opened)
Input signal overrides time delay
Input signal overrides dual mode
Command Menu >System >Input Signal > Select the
required option, press Enter to confirm
Audit Master, Manager, User
With licensed software and peripheral equipment sold
separately, an audit of the last 500 lock events can be
downloaded. The audit is stamped with time and date
information based on the clock time of the keypad, as such
it is vital to ensure correct clock time, with annual
updates.
Full instructions to take audit are available on our website.
PC link must be activated using the keypad to start
communication with the software.
To scroll through a list of audit event codes on the display:
Command Menu >Select Audits, press Enter to confirm
The display shows the following information
• Press Arrow Down to scroll through audit events
Event codes are available to view in the On-Screen audit
instructions available to download from our website.
Activate PC Link Authorised Users
To start communication with LA GARD 700 Series
software, PC Link must be activated.
Command Menu >Select PC Link, press Enter to confirm
Manage the Manager Master
In 702 Display locks supplied by Safelock Systems Ltd, a
Manager is installed with ID 01. To manage the Manager,
the process is the same as for users but only the Master
code is valid to perform the command.
Reset the Manager code Master
If the Manager code has been lost, it is possible to reset
the code.
Command Menu >Users >Edit >Reset combo> Enter
the ID to be reset
• Enter the new code, then repeat the new code to
confirm
Add the Manager Master
Generally, the Manager code can be Reset rather than
being deleted. If the Manager has been deleted, it can be
added again or assigned to a different ID.
When a Manager is added, by default the Manager has the
privilege to open and audit the lock. If the privilege to
override time delay* is required, it must be specified.
*If a Manager is defined as being able to override time delay (TDO Pin
Priv), the feature must be enabled.
Command Menu >Users >Add > Enter an ID to be added
• Select Manager, press Enter to confirm
• Enter a new code, then repeat the new code to confirm
A sub-menu is displayed with privilege options
> Add >
> Open Priv
> Audit Priv
> TDO Pin Priv
> Add User
• If open and audit privilege is all that is needed, select
Add User, press Enter to confirm
• If privileges must be edited, select each Priv option as
required, press Enter to access. The display shows
either 1 2 3 4 5 or _ _ _ _ _. Each digit or _ represents
a lock ID. 702 Display only uses one lock (ID 1). To
remove privilege from a lock, press a digit so that it
changes to _. To enable a privilege, press a digit so the
_ changes to a digit. When complete, press Enter to
confirm and return to the Add user menu.
• Select Add User, press Enter to confirm
Change Manager privilege Master
It is possible to redefine the Manager’s privilege to allow
or disallow opening, audit or time delay override for each
lock that may be connected to the keypad.
Command Menu >Users >Edit >Enter the ID to be
changed
• Select Privileges, press Enter
A sub-menu is displayed >Privileges
>Open Priv
>Audit Priv
>TDO Pin Priv
>Update User
• Select Open Priv, Audit Priv and TDO Pin Priv and
amend as required using the instruction in Add a User.
• Select Update User, press Enter to confirm
*Only the lock IDs that have been added to Open Priv are available
under TDO Pin Priv.
