SYS-D14-MED

INSTALLATION, USE AND WARNINGS MANUAL

Edition: 11 - 2020

 SYS-D14-MED

1Preliminary information....................................................................................................................................... 3
 1.1 Device description........................................................................................................................................... 3

1.2 Recipients............................................................................................................................................................ 4

1.3 Warranty.............................................................................................................................................................. 4

2Identification............................................................................................................................................................. 5
 2.1 Manufacturer identification......................................................................................................................... 5

2.2 Device identification....................................................................................................................................... 5

2.3 Device identification plate ........................................................................................................................... 5

3Technical specifications ....................................................................................................................................... 6
 3.1 SYS-D14-MED device hardware specifications ................................................................................... 6

3.2 Software Specifications ................................................................................................................................. 7

3.3 CE reference directives .................................................................................................................................. 7

3.4 FCC disclaimer................................................................................................................................................... 8

3.5 IC disclaimer....................................................................................................................................................... 8

4Safety devices.........................................................................................................................................................10
 4.1 Warnings ...........................................................................................................................................................10

4.2 Safety pictograms affixed on the device and used in the manual............................................12

5Characteristics and components of the device........................................................................................14
 5.1 Measurement layout ....................................................................................................................................14

5.2 Components ....................................................................................................................................................15

6Permitted environmental conditions ...........................................................................................................17
 6.1 Transport and storage environmental conditions ...........................................................................17

6.2 Operating environmental conditions ....................................................................................................17

7Installation...............................................................................................................................................................19

Information subject to change. Please visit www.seco.com to find the latest version of this manual.
 Page.1 of 29

 SYS-D14-MED

7.1 Installing the device......................................................................................................................................19

7.2 Versions available..........................................................................................................................................23

8Maintenance...........................................................................................................................................................24

9Waste disposal.......................................................................................................................................................24

10 Electromagnetic Compatibility........................................................................................................................25

Information subject to change. Please visit www.seco.com to find the latest version of this manual. Page.2 of 29

SYS-D14-MED

1 Preliminary information

1.1 Device description

The SYS-D14-MED device is a gateway enclosed in a metal box with a heat sink.

The SYS-D14-MED allows the connection between the LAN (local area network) and the

device to which it is connected via ETH or WiFi, also implementing some cybersecurity

measures (such as antivirus and firewall).

Its purpose is to isolate the LAN (local area network) from the device to which it is connected.

The SYS-D14-MED give to the user the possibility to take log files from the system, analyze

them and upload them to a central repository, helping to create a remote inventory database.

The technology developed by SECO S.p.A. for the SYS-D14-MED device can be used and

applied in various fields, such as:

Digital Signage

Infotainment

Edge

Computing

Robotics

Information subject to change. Please visit www.seco.com to find the latest version of this manual.

Page.3 of 29

SYS-D14-MED

1.2 Recipients

This manual is intended for ordinary people and installers (expert users).

Important! The user must read this manual before start with any kind of operation.

1.3 Warranty

The warranty shall be voided in the event of:

•failure to comply with safety regulations;

•tampering with the device;

•changes to the safety conditions established by the Manufacturer in the device

management software;

•improper use of the device;

•use of the device by untrained and/or unauthorized personnel or failure to respect

duties, as indicated in the manual;

•changes or repairs carried out by the user without written authorization from the

Manufacturer;

•partial or total failure to comply with the instructions;

•defects in the mains power supply (electricity, power supply, etc.);

•poor maintenance;

•use of non-original spare parts;

•exceptional events such as floods, fires (if not triggered by the device).

The complete warranty terms are set out in the sales contract.

Important! The Manufacturer is not liable for improper use of the device.

Information subject to change. Please visit www.seco.com to find the latest version of this manual. Page.4 of 29

SYS-D14-MED

Identification

2.1

Manufacturer identification

MANUFACTURER

SECO S.p.A

Via Achille Grandi n°20

Address

52100 Arezzo –Italy

Tel: +39 0575 26979

Fax: +39 0575 350210

2.2

Device identification

Device

SYS-D14-MED

Serial number

YYMMXXXXX

Year of manufacturing

2020

2.3 Device identification plate

The device is equipped with an identification plate located on the side. The plate features the

device identification information to be reported to Seco S.p.A. if necessary.

Caution! It is strictly forbidden to remove the identification plate and/or replace it

with other plates.

Information subject to change. Please visit www.seco.com to find the latest version of this manual. Page.5 of 29

SYS-D14-MED

3 Technical specifications

3.1 SYS-D14-MED device hardware specifications

The table below features the board hardware specifications:

Processor

Memory

Mass Storage

Network connection

USB

Video

Power Supply model

Atom E39xx

Up to 8 GB RAM

Up to 64 GB eMMC

•3x GBE

•Wi-Fi + Bluetooth module on M.2 Key E (INTEL® WIRELESS-

AC 9260, 2230) - Hot Spot e Access Point functionality

•WiFi/BT Antennas PULSE W1043

2x USB 3.0 Host ports, Type A

2x Mini DP connector (only used to set-up the BIOS and

debugging)

Manufacturer: EDAC Power Electronics Co., Ltd.; P/N: EM10681V

(22) (class.1)

Power connector

Jack 3.5mm

RTC Battery

Not rechargeable Lithium battery CR2032

Operating System

Edgehog OS

Linux

Operating temperature

0 °C ÷ +40 °C**

in user environment

Operating humidity in

5 % ÷ 85 %

user environment

Transport / storage room

- 10 °C ÷ + 50 °C

temperature range

Transport / storage

5 % ÷ 90 %

relative humidity range

Atmospheric Pressure

70 kPa ÷ 106 kPa

Altitude

Up to 2000 m

Max Freq. Oscillators

32.678 KHz; 19.2 MHz; 25 MHz; 1.8 GHz

Information subject to change. Please visit www.seco.com to find the latest version of this manual. Page.6 of 29

SYS-D14-MED

IP insulation grade

IP20

Type of installation

Fastening with screws

Attention! **The values indicated refer to the maximum temperature of the

environment of use of the device. It is the customer’s responsibility to verify that the

temperature remains within the admissible range indicated in this manual and, if

necessary, adopt any passive cooling solution together with an application-dependent

cooling system that can ensure that the heat sink temperature will not damage the

device itself and/or the connected mechanical parts.

3.2 Software Specifications

D14XXXYY.BBB software version, where:

-XXX is 000 in standard version and assumes other values in customized versions

-YY is the revision

-BBB is the BIOS version

Software version is released on the SECO website https://www.seco.com and is always updated

and available, even in later versions.

3.3 CE reference directives

SECO S.p.A. places the device on the market, equipping and providing it with:

-CE marking as IT device

-Declaration of Conformity

-User manual

Please also note that the device has been designed according to the following Directives:

-2014/30/EU Electromagnetic Compatibility Directive

-2014/53/EU (RED) (Where applicable, depending on the versions)

-2012/19/EU (WEEE)

-2011/65/EU (RoHS)

the device also meets the requirements of the following standards:

-IEC 62368-1 ed. 3.0

-IEC 60601-1 ed. 3.1

-IEC 60601-1-2 ed. 4

-IEC 60601-1-6:2010 + A1:2013

Information subject to change. Please visit www.seco.com to find the latest version of this manual. Page.7 of 29

SYS-D14-MED

-IEC 62366:2007 + A1:2014

During the IEC 60601-1-2 ESD test it might be happening monitor DP video interface splash. It

is normal because DP video interface will be used only for maintenance and updating.

3.4 FCC disclaimer

This device complies with the FCC Rules and Contains Transmitter Module FCC ID: 2ALZB-D14MED

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

-This device complies with Parr 15 of the FCC Rules. Operation is subject to the

following two conditions.

-(1) this device my not casue harmful interference, and

-(2) this device must accept any interference received, including interference that may

cause undesired operation.

3.5 IC disclaimer

This device complies with the IC Rules and Contains Transmitter Module IC: 22688-

D14MED This Class B digital apparatus complies with Canadian ICES-003.

Operation is subject to the following two conditions: (1) this device may not cause harmful

interference and (2) this device must accept any interference received, including interference that

may cause undesired operation.

CAN ICES-3(B)/NMB-3(B)

Information subject to change. Please visit www.seco.com to find the latest version of this manual. Page.8 of 29
