SEAWIN Electricals MG0201 Manuel utilisateur

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

KNX Multi-protocol Communication Control Gateway

Manual-Ver2.1

MG0201

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

Content

1 Overview ................................................................................................................................................................................................................ 1

2 Detailed parameters .......................................................................................................................................................................................... 1

3 Dimensional drawings and wiring diagrams ............................................................................................................................................. 2

4 Dimensional drawings and wiring diagrams ............................................................................................................................................. 2

5 Software introduction ....................................................................................................................................................................................... 3

5.1 Interface introduction ............................................................................................................................................................................ 3

5.1.1 New project interface ................................................................................................................................................................ 3

5.1.2 Basic information setting interface ....................................................................................................................................... 3

5.1.3 Gateway settings interface ....................................................................................................................................................... 4

5.2 Programming example .......................................................................................................................................................................... 6

5.2.1 Example of data conversion between different protocols ........................................................... 错误!未定义书签。

5.2.2 Timing setting example ........................................................................................................................... 错误!未定义书签。

6 Safe use and maintenance ............................................................................................................................................................................ 11

7 Contact ................................................................................................................................................................................................................ 12

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

1 Overview

This manual provides you with detailed technical information of the KNX multiprotocol communication control gateway

(SC-GW-2.1.1), including installation and programming details, and explains how to use the KNX multiprotocol

communication control gateway host based on actual examples (SC-GW-2.1.1). In order to facilitate installation to the

distribution box, the KNX multi-protocol communication control gateway host (SC-GW-2.1.1) is designed as a modular

installation device that can be installed on a 35 mm DIN rail.

Functions:

(1) With coupler function, coupling different KNX branches;

(2) KNX lines with the same group ID can be set to communicate with each other,

and KNX communication with different group IDs will not interfere with each other;

(3) It can communicate with the upper computer WINCONTROL intelligent lighting

system integrated control software;

(4) 4-way RS485 standard interface (customizable)

(5) 4-way dry contact I/O contact signal input interface;

(6) 3-way infrared IR emission;

(7) 2-way LAN network interface (built-in 8-way TCP/IP or UDP port, can be used as

server or client, 2-way LAN port with switch function);

(8) All interfaces can be mixed with each other for communication;

(9) All protocol or interface data are uniformly defined by the upper-layer software sub-action library, event library, and

time action execution library, and functional modules such as clock, timing, data processing, bus transceiver, and scene

are added to realize central control;

(10) With clock timing management function: you can freely define the clock management of the KNX branch line scene,

add time control for specific occasions, and switch the light timing through the schedule; the system comes with a

calendar, and you can choose the year, month, day, week and The setting of a specific day can set up to 128 event time

management;

(11) Scope of use: projector, air conditioning system, background music system, landscape lighting system, fire

emergency lighting system, I/O signal input system, security access control system, infrared equipment system,

geothermal heating system, lighting management control software , teaching platform software system, central control

system, warehouse management system, hospital medical management system;

(12) Open connection with third-party software platform systems;

2 Detailed parameters

Bus input 21-30V DC

Bus current ≤10mA

Auxiliary voltage 24 VDC

Auxiliary current ＜75mA

Function interface

4-way RS485（Custom Interface）

3-way IR interface

2-way LAN network（8-way TCP/IP/UDP）

4-way I/O ports

1-way KNX/EIB interface

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

Shell material PA66

Dimension (H x W x D) 90mmX144mmX64mm

Weight (approx.) 0.3KG

Installation method 35mm DIN rail mounting

Operating temperature -5°C- 45°C

Storage temperature -20°C- 70°C

Transportation temperature -25°C…+70°C

Relative humidity max 90%

3 Dimension diagram and wiring diagram

dimension diagram wiring diagram

4 Product Operating Instructions

①Description: RS485 terminal block: one in and one out, the aperture can be connected to φ4 wires;

②Description: IR terminal: one in and one out, the aperture can be connected to φ4 wires;

③Description: 12~24VDC power supply wiring port, the aperture can be connected to φ4 wire;

④Description: IO terminal: including 4-way IO, the aperture can be connected to φ4 wires;

⑤Description: Network LAN port, with switch function, can be connected with CAT6 network cable;

⑥Description: Reset button, press and hold for 10s to complete the reset operation;

⑦Description: Reset indicator light, when the reset operation is completed, the indicator light flashes red;

⑧Description: KNX terminal block, KNX bus connection, the red line is connected to "+", and the black line is connected

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

to "-";

⑨Explanation: Device power status indicator, when the indicator is green, the device bus power supply status is normal;

⑩Explanation: KNX bus status indicator light, the indicator light is green in normal state, and the indicator light is off in

abnormal state;

5 Software Introduction

5.1 Interface introduction

5.1.1 New project interface

Figure 5.1

（1）：Event setting area

（2）：Action library

（3）：Event action correlation setting area

5.1.2 Basic information setting interface

Figure 5.2

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

Figure 5.3

（1）：8-way socket settings. Click "Settings" in the lower right corner of the corresponding socket to pop up the

setting interface (as shown in Figure 4.3), check "Enable this socket", each socket has "TCP Client", "TCP Service" and

"UDP" three working modes, select the required mode and set the corresponding IP address, port and other

parameters;

（2）Heartbeat packet settings: To active the heartbeat packet, check "Enable heartbeat packet", set the heartbeat

packet execution cycle, and fill in the heartbeat packet data. After the setting is completed, the socket will continuously

send the set data according to the set heartbeat packet execution cycle.

（3）：Parameter setting of 4-way RS485 serial ports. "baud rate", "parity" and "stop bit" can be set.

5.1.3 Gateway settings interface

1）Click “IR Learning” to perform IR learning on IR1, IR2 and IR3 channels.

Example: IR learning for IR1_ID0.

（1）Connect the infrared learning device;

（2）Open the infrared learning interface;

（3）New infrared data;

（4）Select IR1;

（5）Select the corresponding ID;

（6）Click "Enter Learning (General)" or "Enter Learning (Air Conditioning)", and the LED on the infrared learning device

is blinking;

（7）Point the learned infrared device (such as a TV remote control) at the infrared learning device, press the button, the

LED on the infrared learning device stops flashing, and the "*" symbol appears in the upper right corner of the

corresponding ID (IR1_ID0), which represents the infrared Learning success

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

（8）Click on the infrared test;

（9）After the test is correct, enter the infrared learning of the next ID;

（10）After learning, click "Data Save";

（11）Unplug the infrared learning device. (Note: the gateway and infrared learning device cannot be inserted at the

same time)

2）Click "Network Module Settings"

：Click "Search for devices through the network", you can search all online devices on the same local area network.

Double-click the device you want to edit. You can change the parameters such as IP address and port in the "Gateway

Network Module Settings" . After completing the settings, click Set "Gateway Network Module" to change its

parameters

Network connection: Double-click the device you want to edit from the searched devices and click "TCP connection" in

the lower right corner to connect the devices。

：After the device is connected to the network, click "Get Gateway Clock", the current time of the gateway is

displayed in the lower left corner of the interface; click "Synchronize Gateway Clock" to synchronize the clock on the

gateway and the computer.

（3）Click on "KNX Gateway Settings"

After the network connection is successful, click "Get Device Information" to get the parameters in the setting of KNX

module , and you can also set the parameters of the KNX gateway network module. After setting all parameters, click

"Set". If you need to restart the KNX gateway, click "Device Restart".

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

（4）Click "Data Download"

：Communication port setting area

Download data commonly used internet connection.

：Program download area

Network download: After setting the IP address and port, click "Connect", after the "Network connection succeeded" is

displayed in the lower left corner, click "Download" directly.

：Infrared data download area

Export or import data selection ", optional: all, infrared group 1, infrared group 2, infrared group 3; path of import data,

click" execute import data "

5.2 Programming example

5.2.1 Example of data conversion between different protocols

1）Double-click to open the software , pop-up programming interface

2）"File" → "New Project";

3）Click "Basic Information Settings", if you need to use socket or RS485 port, first set the basic information of the

corresponding interface;

4）Click "Add event", empty folder appears, as shown below.

Double-click the folder, the following interface appears

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

Select the receiving source, fill in the receiving code and name, and click OK to finish. Example: Click “COM1”, and

enter “11” in the receiving code. When the data is hexadecimal, you need to select “HEX”.

5）Drag the port that needs to send data to "Data" in the table, for example: send port is "KNX_GA", drag "GA" to "Data"

in the table, and the following window pops up:

Fill in the group address, data length and data sent, and click OK. Appropriate data appears in the table

You can drag up to 30 sent data into the table. If you need to delete some, delete the data under "Data" corresponding

to the transmission instruction in the table.

The action library can also be set in advance, and all the actions to be used are written into the action library. When the

events and actions need to be associated, drag the corresponding action to the event action association setting table of

the corresponding event. The steps to build an action library are as follows:

(1) Pull down the "Library" in the menu bar to create a new action library;

(2) After the new action library is created, the newly created action library will be generated in the interface, as shown

below:

KNX/EIB BUS

GATEWAY ACTUATORS

Product Manual

(3) Select the action library and click "Add" above to pop up the newly added action "Action".

(4) Double click“Action” ，the action and event library window appears on the right , drag the action in you

want to set to the data in ，a data filling box pops up, after completing, click OK, the data and explanation of

this action will be displayed automatically in . Click Finish to save this action.

(5) Pull down the "Library" in the menu bar and click "Save Action Library" to save the entire action library.

6）After writing, open "Program" → "Basic Information Settings"

After setting the corresponding information, click OK

7）Click "Program" → "Gateway Settings", the following interface appears
