Sealey CX102 Manuel utilisateur

INSTRUCTIONS FOR

EXTRA HEAVY DUTY GARAGE/WORKSHOP

TROLLEY

MODEL NO: CX102

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

MPORTANT:

PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. GENERAL SAFETY

WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this trolley.

9Always load evenly with the centre of gravity of the load as near centre of the trolley as possible.

8DO NOT overload the trolley - maximum weight per level is 80kg.

8Use the trolley in a suitable work area.

9Keep the work area clean, uncluttered and ensure there is adequate lighting.

9Keep the trolley clean and tidy in accordance with good workshop practice.

8DO NOT use the trolley for any purpose other than that for which it is designed.

8DO NOT stand on the trolley, use it as a ladder or allow others to ride on the trolley.

9Use the wheel locks to prevent the trolley from inadvertently moving.

8DO NOT leave unattended, especially when loaded, unless the wheels are locked, chocked or the trolley otherwise secured.

8DO NOT use trolley on uneven ground and do not run over curbs or steps - use a ramp.

8DO NOT use trolley if any part is significantly damaged, paying particular attention to the wheels.

9Keep children and unauthorised persons away from the work area.

2. iINTRODUCTIONt

Garage or workshop trolley with each shelf having a capacity of 80kg. Deep walled shelves, which may be installed base down or base up to give

either tool and component security or unobstructed access. Fitted with four wheels, two fixed and two locking castors.

3. iSPECIFICATION

Model no: ......................................................................CX102

Size (W x D x H):......................................760 x 410 x 900 mm

Capacity: .................................................................. 80kg/level

CX102 | Issue 5 10/01/17

Original Language Version

Refer to

Instruction

manual

4. iASSEMBLY

4.1. Mount tray (2) to the upper hole in the end frames (3) and loosely fix with four M6 x 32mm bolts (1). Make sure the dished holes on the

end frames are facing outwards.

4.2. Mount the other tray (2) to the lower hole in the end frames (3) and loosely fix with four M6 x 32mm bolts (1).

4.3. Tighten all bolts (1).

4.4. Turn the trolley over, install castors (4 & 5) into the bottom of the end frames and fix with the M6 x 12mm bolts (6).

4.5. Turn the trolley upright. The trolley is ready to use.

5. pPARTS LISTrts list

Item Part No: Description

1CX101D.01 BOLT M6 x 32mm

2CX101D.02 TRAY

3CX101D.03 HANDLE

4CX101D.04 CASTOR WHEEL c/w BRAKE

5CX101D.05 CASTOR WHEEL

6CX101D.06 BOLT M6 x 12mm

7CX101D.08 WASHER

8CX101D.09 SPRING WASHER

9CX101D.10 NUT

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.

IMPORTANT: No liability is accepted for incorrect use of this product.

WARRANTY:Guarantee is 12 months from purchase date, proof of which will be required for any claim.

Sole UK Distributor, Sealey Group.

Kempson Way, Suffolk Business Park,

Bury St. Edmunds, Suffolk.

IP32 7AR

www.sealey.co.uk

sales@sealey.co.uk

01284 757500

01284 703534

Web

CX102 | Issue 5 10/01/17

Original Language Version

Environmental Protection

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be

sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.

When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)

into approved containers and dispose of the product and the fluids according to local regulations.
