SeaLevel ACB-232.LPCI Manuel utilisateur

Part # 5103

Sealevel Systems, Inc

P.O. Box 830

Liberty, SC 29657 USA

Phone: (864) 843-4343

FAX: (864) 843-3067

www.sealevel.com

CB-232.LPCI

USER MANUAL

Contents

INTRODUCTION.............................................................................................................................1

OVERVIEW ...................................................................................................................................................1

WHAT’S INCLUDED......................................................................................................................................1

INSTALLATION..............................................................................................................................1

OPERATION SYSTEM INSTALLATION ............................................................................................................1

SYSTEM INSTALLATION................................................................................................................................1

TECHNICAL DESCRIPTION............................................................................................................2

FEATURES ....................................................................................................................................................2

Internal Baud Rate Generator .................................................................................................................2

I/O REGISTERS DEFINITION -CONTROL AND STATUS...................................................................................2

25 PIN CONNECTOR SIGNAL LAYOUTS (DB-25 MALE)................................................................................3

RS-232 Signals .......................................................................................................................................3

SPECIFICATIONS ...........................................................................................................................4

ENVIRONMENTAL SPECIFICATIONS ..............................................................................................................4

POWER CONSUMPTION.................................................................................................................................4

MEAN TIME BETWEEN FAILURES (MTBF)...................................................................................................4

PHYSICAL DIMENSIONS................................................................................................................................4

APPENDIX A-TROUBLESHOOTING..............................................................................................5

APPENDIX B-HOW TO GET ASSISTANCE ...................................................................................6

APPENDIX C-ELECTRICAL INTERFACE......................................................................................7

RS-232 OR EIA/TIA-232............................................................................................................................7

APPENDIX D-SILK-SCREEN ........................................................................................................8

APPENDIX E-COMPLIANCE NOTICES.........................................................................................9

FEDERAL COMMUNICATIONS COMMISSION STATEMENT..............................................................................9

EMC DIRECTIVE STATEMENT......................................................................................................................9

WARRANTY...................................................................................................................................10

SL9075 Revision 7/2006

Introduction and Installation

Sealevel Systems ACB-MP.PCI Page1

Introduction

Overview

The ACB-232.LPCI adapter provides the PC with a single channel multi-protocol serial interface utilizing the Zilog

Z85230 (ESCC™), which is suitable for the most popular communication protocols including HDLC/SDLC, X.25,

Bi-Sync, Mono-Sync, and asynchronous.

The ACB-232.LPCI is compliant with EIA/TIA-232E.

What’s Included

The ACB-232.LPCI is shipped with the following items. If any of these items are missing or damaged, contact the

supplier.

•ACB-232.LPCI Adapter

•Sealevel Software

•Standard PCI Profile Bracket

Installation

Operation System Installation

Note: For the5103 to work properly in Windows 2000, Plug and Play OS must be turned off in the BIOS.

Choose Install Software at the beginning of the CD and select Install SeaMAC.

System Installation

The ACB-232.LPCI can be installed in any of the PCI expansion slots.

1. Turn off PC power. Disconnect the power cord.

2. Remove the PC case cover.

3. Locate an available PCI slot and remove the blank metal slot cover.

4. Gently insert the ACB-232.LPCI into the slot. Make sure the adapter is seated properly.

5. Replace the screw.

6. Replace the cover.

7. Connect the power cord.

Installation is complete.

Technical Description

Sealevel Systems ACB-MP.PCI Page 2

Technical Description

The ACB-232.LPCI utilizes the Zilog 85230 Enhanced Serial Communications Controller (ESCC). This chip

features programmable baud rate, data format and interrupt control. Refer to the ESCC Users Manual for details on

programming the 85230 ESCC chip.

Features

•One channel of synchronous or asynchronous communications using the Zilog Z85230 chip

•EIA/TIA-232 Signals supported TD, RD, CTS, RTS, DCD, DSR, DTR, TXC, RXC, TSET, RI

•Programmable options for Transmit clock as input or output

•Software programmable baud rate

Internal Baud Rate Generator

The baud rate of the ESCC is programmed under software control. The standard oscillator supplied with the board is

7.3728 MHz. However, other oscillator values can be substituted to achieve different baud rates.

I/O Registers Definition - Control and Status

The control and status registers occupy 16 consecutive locations. The following tables provide a functional

description of the bit positions.

X = do not care { }= always this value

Address Mode D7 D6 D5 D4 D3 D2 D1 D0

Base+4 RD {0} IRQST {0} {0} {0} {0} {0} {0}

Base+4 WR X X X XXXXX

Base+5 RD {0} {0} SYNCA_RTS SYNCA_CTS {0} {0} {0} {0}

Base+5 WR X X SYNCA_RTS SYNCA_CTS X X X X

Base+6 RD {0} {0} {0} TXOUT RIOUT DSROUT TSETSLA RXCOPTA

Base+6 WR X XXTXOUT RIOUT DSROUT TSETSLA RXCOPTA

Base+14 RD SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0

Base+15 RD SD15 SD14 SD13 SD12 SD11 SD10 SD9 SD8

Field Description

Base +4

IRQST SCC interrupt status: 1 = No interrupt pending on IUSC; 0 = Interrupt pending on IUSC.

Base +5

SYNCA_RTS SYNCA _RTS – 0 = SYNCA is high, 1 = SYNCA connected to RTS ( 0 on power up )

SYNCA_CTS SYNCA_CTS – 0 = SYNCA is high, 1 = SYNCA connected to CTS ( 0 on power up )

Base +6

TSETSLA CHAN A – TSET clock source 0 = TRXCA as source, 1= received TXC as source ( 0 on power up )

RXCOPTA RXCOPTA – 0 = selects received RXC for RTXCA, 1 = selects SCC PCLK for RTXCA ( 0 on power up )

DSROUT DSROUT – 0 = DSR not routed to SCC 1 = DSR routed to SCC DCDB (0 on power up)*

RIOUT RIOUT – 0 = RI not routed to SCC 1 = RI routed to SCC CTSB (0 on power up)**

TXOUT TXOUT – 0 = TXD routed from SCC to 1488 1 = Forces TXD always a high (for idle mark bug in ESCC)***

Base +14 and 15

SD0-SD15 Optional security feature. Unique value per customer or application. ( default value = FFFF)

* DSR- is connected to Port B DCD on the 85230 only when this bit is set to a 1. If 9015 compatibility is

required, this bit must be set as part of the SCC initialization.

** RI- is connected to Port B CTS on the 85230 only when this bit is set to a 1. If 9015 compatibility is required,

this bit must be set as part of the SCC initialization.

Technical Description

Sealevel Systems ACB-MP.PCI Page 3

25 Pin Connector Signal Layouts (DB-25 Male)

RS-232 Signals

Signal Name Pin # Mode

GND Ground 7

RD Receive Data 3 Input

CTS Clear To Send 5 Input

DSR Data Set Ready 6 Input

DCD Data Carrier Detect 8 Input

TXC Transmit Clock 15 Input

RXC Receive Clock 17 Input

RI Ring Indicator 22 Input

TSET Transmit Signal Element Timing 24 Output

DTR Data Terminal Ready 20 Output

TD Transmit Data 2 Output

RTS Request To Send 4 Output

RI- is connected to Port B CTS on the 85230 and the enable bit is set in Base+6.

DSR- is connected to Port B DCD on the 85230 the enable bit is set in Base+6.

Technical Note: Please terminate any control signals that are not going to be used. The most common way to do this

is connect RTS to CTS and RI. Also, connect DCD to DTR and DSR. Terminating these pins, if not used, will help

insure you get the best performance from your adapter.

Specifications

Sealevel Systems ACB-MP.PCI Page 4

Specifications

Environmental Specifications

Specification Operating Storage

Temperature Range 0 to 50 º C

(32 to 122 º F) -20 to 70 º C

(-4 to 158 ºF)

Humidity Range 10 - 90% R.H. Non Condensing 10 - 90% R.H. Non Condensing

Power Consumption

Supply line +12VDC -12VDC +5 VDC

Rating 50mA 50mA 350 mA

Mean Time Between Failures (MTBF)

Greater than 150,000 hours. (Calculated)

Physical Dimensions

Board length 4.721 inches (11.99 cm)

Board Height including Goldfingers 2.536 inches (6.44 cm)

Board Height excluding Goldfingers 2.211 inches (5.62 cm)

Appendix A - Troubleshooting

Sealevel Systems ACB-MP.PCI Page 5

Appendix A - Troubleshooting

The Sealevel Software is supplied with the Sealevel Systems adapter and will be used in the troubleshooting

procedures. Using this software and following these simple steps can eliminate most common problems without the

need to call Technical Support.

1. Identify all I/O adapters currently installed in your system. This includes the on-board serial ports, controller

cards, sound cards etc. The I/O addresses used by these adapters, as well as the IRQ (if any) should be

identified.

2. Make sure the Sealevel Systems adapter is securely installed in a PCI slot.

3. Use the supplied software and User Manual to verify that the Sealevel Systems adapter is configured correctly.

4. Windows users can use the installed programs in the SeaMAC folder to verify operation.

Appendix B - How To Get Assistance

Sealevel Systems ACB-MP.PCI Page 6

Appendix B - How To Get Assistance

Please refer to Troubleshooting Guide prior to calling Technical Support.

1. Begin by reading through the Trouble Shooting Guide in Appendix A. If assistance is still needed

please see below.

2. When calling for technical assistance, please have your user manual and current adapter settings. If

possible, please have the adapter installed in a computer ready to run diagnostics.

3. Sealevel Systems provides an FAQ section on its web site. Please refer to this to answer many

common questions. This section can be found at http://www.sealevel.com/faq.htm .

4. Sealevel Systems maintains a Home page on the Internet. Our home page address is

www.sealevel.com. The latest software updates, and newest manuals are available via our FTP site

that can be accessed from our home page.

5. Technical support is available Monday to Friday from 8:00 a.m. to 5:00 p.m. eastern time. Technical

support can be reached at (864) 843-4343.

RETURN AUTHORIZATION MUST BE OBTAINED FROM SEALEVEL SYSTEMS BEFORE

RETURNED MERCHANDISE WILL BE ACCEPTED. AUTHORIZATION CAN BE OBTAINED BY

CALLING SEALEVEL SYSTEMS AND REQUESTING A RETURN MERCHANDISE

AUTHORIZATION (RMA) NUMBER.

Appendix C - Electrical Interface

Sealevel Systems ACB-MP.PCI Page 7

Appendix C - Electrical Interface

RS-232 Or EIA/TIA-232

Quite possibly the most widely used communication standard is RS-232. This implementation has been defined and

revised several times and is often referred to as RS-232 or EIA/TIA-232. It is defined by the EIA as the Interface

between Data Terminal Equipment and Data Circuit- Terminating Equipment Employing Serial Binary Data

Interchange. The mechanical implementation of RS-232 is on a 25-pin D sub connector. RS-232 is capable of

operating at data rates up to 20 Kbps at distances less than 50 ft. The absolute maximum data rate may vary due to

line conditions and cable lengths. RS-232 often operates at 38.4 Kbps over very short distances. The voltage levels

defined by RS-232 range from -12 to +12 volts. RS-232 is a single ended or unbalanced interface, meaning that a

single electrical signal is compared to a common signal (ground) to determine binary logic states. A voltage of +12

volts (usually +3 to +10 volts) represents a binary 0 (space) and -12 volts (-3 to -10 volts) denotes a binary 1 (mark).

The RS-232 and the EIA/TIA-574 specification defines two type of interface circuits, Data Terminal Equipment

(DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface.

Appendix D - Silk-Screen

Sealevel Systems ACB-MP.PCI Page 8

Appendix D - Silk-Screen

2.536"

4.721"
