Seagate Barracuda ATA Series Manuel utilisateur

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

Barracuda ATA Family

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

ST328040A, ST327240A, ST320430A

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

ST313620A, ST310220A, ST36810A

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

Ultra ATA Interface Drives

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

Product Manual

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

...... ........ ........ ........ ........ .......

Barracuda ATA Family

. . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . .. . .

ST328040A, ST327240A, ST320430A

...... ........ ........ ........ ........ .......

ST313620A, ST310220A, ST36810A

...... ........ ........ ........ ........ .......

Ultra ATA Interface Drives

...... ........ ........ ........ ........ .......

Product Manual

...... ........ ........ ........ ........ .......

Publication Number: 20400144-001, Rev. B, December 1999

Seagate, Seagate Technology, the Seagate logo and Barracuda are

registered trademarks of Seagate Technology, Inc. Other product names

are registered trademarks or trademarks of their owners.

Seagate reserves the right to change, without notice, product offerings

or specifications. No part of this publication may be reproduced in any

form without written permission from Seagate Technology, Inc.

Barracuda ATA Family Product Manual, Rev. B iii

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Specification summary table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1.1 Default logical geometry . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.2 Physical organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.3 Recording and interface technology . . . . . . . . . . . . . . . . . . . . 6

1.4 Physical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.5 Seek time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.6 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.7 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.7.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.7.2 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.7.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.7.4 Power-management modes . . . . . . . . . . . . . . . . . . . . . 10

1.8 Environmental tolerances . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.8.1 Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.8.2 Temperature gradient . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.3 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.4 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.5 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.6 Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.9 Drive acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.10 Electromagnetic susceptibility . . . . . . . . . . . . . . . . . . . . . . . 14

1.11 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.12 Agency certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.12.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.12.2 Electromagnetic compatibility . . . . . . . . . . . . . . . . . . . 14

iv Barracuda ATA Family Product Manual, Rev. B

1.12.3 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . 17

2.1 Handling and static-discharge precautions . . . . . . . . . . . . . . 17

2.2 Jumper settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.2.1 Master/slave configuration . . . . . . . . . . . . . . . . . . . . . . 18

2.2.2 Cable-select option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2.3 Alternate capacity jumper . . . . . . . . . . . . . . . . . . . . . . . 19

2.2.4 Ultra ATA/66 cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.3 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.0 ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.1 ATA interface signals and connector pins . . . . . . . . . . . . . . 21

3.1.1 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . 23

3.1.2 Identify Drive command . . . . . . . . . . . . . . . . . . . . . . . . 24

3.1.3 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . 29

3.1.4 S.M.A.R.T. commands . . . . . . . . . . . . . . . . . . . . . . . . . 30

Barracuda ATA Family Product Manual, Rev. B v

Figures

Figure 1. Typical startup and operation current profile . . . . . . . . . . . . 9

Figure 2. Master/slave jumper settings . . . . . . . . . . . . . . . . . . . . . . . 18

Figure 3. Mounting dimensions—top, side and end view . . . . . . . . . 20

Figure 4. I/O pins and supported ATA signals. . . . . . . . . . . . . . . . . . 22

vi Barracuda ATA Family Product Manual, Rev. B

Barracuda ATA Family Product Manual, Rev. B 1

Introduction

This manual describes the functional, mechanical and interface specifi-

cations for the ST328040A, ST327240A, ST320430A, ST313620A,

ST310220A, and the ST36810A. These drives provide the following key

features:

•Low power consumption

•Quiet operation

•High instantaneous (burst) data-transfer rates (up to 66.6 Mbytes per

second) using Ultra DMA mode 4

•7,200-RPM and 512-Kbyte buffer combine for superior desktop per-

formance

•300 Gs nonoperating shock

•GMR recording heads and EPRML technology, which provide the

drives with increased areal density

•State-of-the-art cache and on-the-fly error-correction algorithms

•Full-track multiple-sector transfer capability without local processor

intervention

•Support for S.M.A.R.T. drive monitoring and reporting

•Support for Read Multiple and Write Multiple commands

•Support for autodetection of master/slave drives that use cable select

(CSEL)

2 Barracuda ATA Family Product Manual, Rev. B

Specification summary table

The specifications listed in this table are for quick reference. For details

on specification measurement or definition, see the appropriate section

of this manual.

Drive Specification ST328040A

ST327270A ST320430A ST313620A ST310220A ST36810A

Guaranteed Mbytes

(×106bytes) 28,520

27,333 20,520 13,666 10,242 6,833

Guaranteed sectors 55,704,096

53,385,552 40,079,088 26,692,776 20,005,650 13,346,235

Bytes per sector 512

Default sectors per

track 63

Default read/write

heads 16 16 16 16 15

Default cylinders 16,383 16,383 16,383 16,383 14,123

Physical read/write

heads 86432

Discs 43221

Recording density

KBPI (bits/inch max) 305

Track density

TPI (tracks/inch) 16,420

Areal density

(Mbits/inch2 max) 5,100

Spindle speed

(RPM) 7,200

Internal data-trans-

fer rate (Mbits/sec

max)

323

I/O data-transfer

rate (Mbytes/sec-

max)

66.6

ATA data-transfer-

modes supported PIO modes 0–4

Multiword DMA modes 0–2

Ultra DMA modes 0–4

Cache buffer

(Kbytes) 512

Height (mm max) 26.1
