The control unit is pre-set with the default settings, to start the control unit with the
DEFAULT settings just keep pressed the UP and DOWN buttons at the same time
power supplying the control unit the display shows the message “Init”. The DEFAULT
settings are shown in the Menues table.
WORKING TIMES SELF LEARNING
WORKING TIMES SELF-LEARNING THROUGH ENCODER/POTENTIOMETER
When the potentiometer is installed, it is necessary to select “Potentiometer” in the 32-ENCODER menu.
Start programming and make sure that leaf starts as first in closing. With potentiometer, the gate will
automatically execute the following cycle: CLOSE - OPENING -CLOSE - OPENING and CLOSING with
SLOW-DOWN
Note1: For the stop detection sensitivity settings refer to the special menu.
Note 2: With the potentiometer you can also make the self-learning giving impulses on favourite
opening or closing points; In this case it is alson possible to modify the parameters I.AP.M1, I.CH.M1,
I.AP.M2, I.CH.M2 of + 100 impulses, if you need to optimize the initial and the final position.
Note 3: in case of self-learning through impulses or mixed procedure with potentiometer (detection
of AUTOMATIC STOP in closing and MANUAL impulsion in opening), the new cycle will be
CLOSE-OPEN-CLOSE
LEARNING WITH LIMIT-SWITCH (only for version with limit-switch)
When limit switches are mounted, the gate executes automatically the follwing cycle: CLOSING M2 -
CLOSING M1 - OPENING M1 - OPENING M2 - CLOSING M2 - CLOSING M1.
Before starting the learning, make sure( through the test menu), that the relative limit switches of every leaf
and every opening are employed.
Exemple: For the M2 motor closing the limit switch M2 in closing must be employed.
WORKING TIMES SELF-LEARNING THROUGH IMPULSES
ATTENTION: This procedure is potentially dangerous and should only be performed by qualified
people in safety conditions.
NOTE: The card is preset with the standard working times, therefore the automation can be started
even without the times programming, simply by adjusting the timing on the display (see default
times). In this procedure all used N.C. contacts must be kept closed.
1) Turn off electricity, release the motors and manually position the leaves on halfway.
Reset the mechanical lock.
2) Connect the control board to the power supply
3) Select on the on-board display or JOLLY 3 programmer, the type of motor that you are using as indicated in
the dispaly management (“Mechanic-Hydraulic”, etc).
4) If necessary also set the operation logic and the other parameters. If you want to program with a
transmitter, store a transmitter before programming.
5) Select 9-PROGRAMMING on the display, press OK and than one of the UP or DOWN buttons.
(If the motor starts in opening, remove and re-put power supply, select on the display 5-REVERSE MOTOR.
And through the UP and DOWN button put it on ON, or if you have the Jolly 3 programmer, activate the motor
exchange function. )
6) At this point the gate will start the following cycle: CLOSING M2 - CLOSING M1 - OPENING M1 -
OPENING M2 - CLOSING M2 - CLOSING M1. During cycle, to store the respective stops, press UP or
DOWN or START at every point of stop of the leaf.
7) The self-learning is done.
