Samsung M2 Portable Series Manuel utilisateur

M2 Portable

·HX-M250UAB

·HX-M250UAE

·HX-M250UAA

·HX-M250UAY

·HX-M320UAB

·HX-M320UAE

·HX-M320UAA

HX-M320UAY

HX-M500UAB

HX-M500UAE

HX-M500UAA

HX-M500UAY

HX-M640UAB

HX-M640UAE

HX-M640UAA

HX-M640UAY

HX-M750UAB

HX-M750UAE

HX-M750UAA

HX-M750UAY

HX-M101UAB

HX-M101UAE

HX-M101UAA

HX-M101UAY

HX-M250TAB

HX-M250TAE

HX-M250TAA

HX-M250TAY

HX-M320TAB

HX-M320TAE

HX-M320TAA

HX-M320TAY

HX-M500TAB

HX-M500TAE

HX-M500TAA

HX-M500TAY

HX-M640TAB

HX-M640TAE

HX-M640TAA

HX-M640TAY

HX-M750TAB

HX-M750TAE

HX-M750TAA

HX-M750TAY

HX-M101TAB

HX-M101TAE

HX-M101TAA

HX-M101TAY

M2 Portable 3.0

USER MANUAL

M2 Portable Series

External Hard Drive

M2 Portable Series External Hard Drive 2

Read Me First

Software and user’s manuals are available for download at the Samsung External Hard Drive website (www.samsunghdd.com).

The content of this User’s Manual may change without prior notice for product improvement purposes.

About this Manual

Your product comes with a quick start guide and a user’s manual.

Following the instructions and precautions of this manual will ensure easier and more enjoyable use of your

M2 Portable Series External Hard Drive.

Quick Start Guide

A start guide is provided with the purchase of M2 Portable Series External Hard Drive.

The quick start guide explains product components and provides simple instructions on how to install the product.

User’s Manual

Using this Manual

Carefully read and understand the “Handling Precautions” section before using the product.

Failure to follow all the instructions as outlined in the Handling Precautions section could result in damage to

you or to your M2 Portable Series External Hard Drive.

User Manual

Icon Guide

Icon Meaning

These must be read thoroughly before using any of the functions.

Precautions

Caution

Note

This contains must-know information about functions. User must be careful.

This contains useful information about the functions.

Refer to the Troubleshooting section first if you experience a problem with the product.

The User’s Manual contains detailed information about features and instructions on using your

M2 Portable Series External Hard Drive.

Handling Precautions

The following information serves to ensure user’s safety and prevent damage to user’s properties.

Carefully read the information provided and use your product correctly.

Data Cable Usage

Shock

Do not unplug the data cable by

severely pulling the cable.

This may damage connector on the product

and may cause a problem with the product.

Supplied with the rated USB BUS Power

M2 Portable Series must use the USB Bus Power. Please connect to the USB Port supplied with the rated USB BUS Power.

Use the product on a flat surface.

Do not sit on the product and

do not place a heavy object over

the product.

Product case or connector can be damaged

and may cause a break down.

Standardized data cable.

This may increase the wrong operation and

may cause a malfunction.

Do not severely bend the data

cable and do not place a heavy

object over the data cable.

If the data cable is damaged, it may cause a

malfunction.

Installation Related

The external drive is very portable and you may easily drop it. Take care not to drop and tip the product while

carrying the External Hard Drive. If you make an impact on the External Hard Drive, it may cause bad sectors on the disk.

Bad sectors can cause various and potentially read/write errors.

Humidity

If you use the product in places exposed to humidity, it may danger of electric shock. In addition, prolonged exposure to

moisture can corrode various parts and components.

M2 Portable Series External Hard Drive 3

User Manual

Magnets

Disassembly and Label Removal

For repair, please visit the designated (samsung) customer service center.

Unauthorized disassembly, repair, or reform of the product and unauthorized removal

of the labeling will void your warranty.

Safely Remove Hardware

Always use the Safely Remove Hardware feature before shutting down the External Hard Drive or disconnecting the USB cable and power cable.

Regular Virus Scanning

Frequently scan the device for viruses and protect the External Hard Drive from virus infection.

Cleaning the product

Never use cleaning fluid or similar chemicals.

Do not spay cleaner directly on the product.

It may cause discoloration and deformation of the product.

Custody Related

Keep the product and accessories out of the reach of children. It may cause personal injuries and problem.

Always Backup your Important Data

The external drive manufacturer does not guarantee data stored in the External Hard Drive

and will not assume responsibility for any mental or material damage incurred during data recovery.

Backup : Storing the original and a copy on two or more separate and accessible storage media.

Actual accessible capacity may vary from advertised capacity due to formatting and partitioning of the hard drive, as well as due to your computer's

operating system.

1MB=1,000,000bytes / 1GB=1,000,000,000bytes / 1TB=1,000,000,000,000bytes

Magnetic objects can cause various types of damage to the External Hard Drive, including data damage. Keep magnets and

magnetic objects away from the external drive.

M2 Portable Series External Hard Drive 4

User Manual

Read Me First

Table of Contents

2About this Manual

2Quick Installation Guide

2User’s Manual

2Using this Manual

2Icon Guide

Specifications

6Introduction

7M2 Portable

8M2 Portable 3.0

9Installation

11 Windows

Connecting your M2 Portable Series

Using your M2 Portable Series

13 Copying / Moving Files

13 Removable Disk Method

15 Safely Removing your M2 Portable Series

15 For Windows

16 For Macintosh

17 FAQ

Troubleshooting

Appendix

18 Partitioning and Changing File System Type

18 Reformat to FAT32

18 Reformat to NTFS32

18 Format in Macintosh

19 Product Certifications

19 FCC

20 Warranty Information

12 Macintosh

3Supplied with the rated USB BUS Power

3Installation Related

3Data Cable Usage

3Shock

3Humidity

4Magnets

4Disassembly and Label Removal

4Always Backup your Important Data

4 Regular Virus Scanning

4Cleaning the product

4Custody Related

4Safely Remove Hardware

Handling Precautions

Introduction

M2 Portable Series External Hard Drive 5

User Manual

Introduction

User’s Manual

M2 Portable Series External Hard Drive 6

The M2 Portable Series External Hard Drive is a high-performance external hard drive that supports USB *.

Unlike conventional desktop disk drives, the M2 Portable Series External Hard Drive makes it possible for you to

instantaneously add greater storage capacity to your system without having to take the computer apart.

This means that your M2 Portable Series External Hard Drive comes fully partitioned and formatted for your

use and you can instantly access to the drive by simply plugging it into your computer through a USB port.

* M2 Portable : USB 2.0

M2 Portable 3.0 : USB 3.0

Specifications (M2 Portable)

User Manual

M2 Portable Series External Hard Drive 7

Overview

Some computers supply limited USB bus power. If your drive doesn't power on after connecting the USB cable, you may

need to purchase a USB Y-cable from retailers or online shops.

LED Description

System Requirements

PC : Windows XP / Vista / 7

Macintosh : Mac OS X 10.4.8 or Later

Upgrade your operating system to the latest version to enjoy better performance and reliability.

1) Standby Status : Steadily lit LED

2) Read/Write in Progress : Blinking LED

Components

When you purchase a M2 Portable External Hard Drive, make sure that all components have been included in your

product package.

Mist Gray, Noble Beige, Brown Black, Clay Orange

USB 2.0

480 Mbps Max.

USB Host Power

Windows XP / Vista / 7

Mac OS X 10.4.8 or Later

81.90mm X 111.00mm X 17.60mm

NTFS

M2 Portable

250GB / 320GB / 500GB / 640GB / 750GB / 1TB

Category

Interface

Transfer Rate

Power

Operating System

Hard Disk Capacity

Dimensions (W x H x L)

Color

Format System

Overview

LED Description

1) Standby Status : Steadily lit LED

2) Read/Write in Progress : Blinking LED

Components

Quick Start GuideM2 Portable 3.0

M2 Portable Series

USB 3.0 Micro-B Cable

LED

USB Port

Connecting your M2 Portable

User Manual

M2 Portable Series External Hard Drive 9

Installation

Verify that the computer meets the minimum system requirements as outlined in #System Requirements.

Insert the USB cable to the desktop/laptop computer as shown in Figures 1 and 2:

Connecting to a Desktop Computer

M2 Portable Series External Hard Drive will automatically activate once connected to the computer.

Connecting to a Laptop Computer

Connecting your M2 Portable 3.0

User Manual

M2 Portable Series External Hard Drive 10

Installation

Verify that the computer meets the minimum system requirements as outlined in #System Requirements.

Insert the USB cable to the desktop/laptop computer as shown in Figures 3 and 4:

Connecting to a Desktop Computer

Connecting to a Laptop Computer

To use the M2 Portable 3.0 model at its maximum speed, you need a PC or a Host Card that supports USB 3.0 interface.
