Samsung SP-A600B Manuel utilisateur

SP-A600B

DLP Projector

Owner’s Instructions

The appearance and the color may differ depending on the

model.

Table Of Contents

MAJOR SAFETY PRECAUTIONS

Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

INSTALLATION AND CONNECTION

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Installing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Leveling with Adjustable Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Zoom and Focus Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Screen Size and Projection Distance . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Lamp Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Connecting with a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Setting up the PC Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Supported Display Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Connecting the Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Connecting a DVD player/Cable/Satellite Box to HDMI/DVI . . . . . . . 2-11

Connecting a DVD player/Cable/Satellite Box via Component . . . . 2-12

Connecting to VCR/Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

USING

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Front, Upper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Using the Screen Adjustment Menu (OSD: On Screen Display) . . . . 3-5

TROUBLESHOOTING

Before Requesting Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

MORE INFORMATION

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

RS-232C Command Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Contact SAMSUNG WORLDWIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Correct Disposal - Europe only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Major Safety Precautions 1-1

1 Major Safety Precautions

1-1 Before You Start

Icons used in this manual

Using this Manual

• Make yourself fully aware of the safety precautions before using this product.

• If a problem occurs, refer to the 'Troubleshooting' section.

The contents of this manual are subject to change without prior notice for performance improvement.

The copyright of this manual is reserved by Samsung Electronics, Co., Ltd.

The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written

permission of Samsung Electronics, Co., Ltd.

1-2 Care and Maintenance

Cleaning the Surface and the Lens

Icon

NAME MEANING

Caution Indicates cases where the function may not work or the setting may be canceled.

Note Indicates a hint or tip to operate a function.

1-3 Major Safety Precautions

Cleaning Inside the Projector

1-3 Safety Precautions

Icons used for safety precautions

Meaning of Signs

Clean the projector using a soft dry cloth.

• Avoid cleaning the product with an inflammable substance such

as benzene or thinner or with a wet cloth. This may result in a

problem with the product.

• Avoid scratching the screen with your fingernails or a sharp

object.

This may result in scratches or damage to the product.

• Avoid cleaning the product directly by spraying water onto the

product.

If water enters the product, it may result in fire, electric shock or a

problem with the product.

• A white stain may be generated on the surface of the projector if

water gets on it.

The appearance and the color may differ depending on

models.

For cleaning the interior of the projector, contact a Service Center.

• Contact a Service Center if dust or other substances are inside

the projector.

Icon

NAME MEANING

Warning Failing to follow the precautions marked with this sign, may result in a serious injury or even a

fatality.

Caution Failing to follow the precautions marked with this sign may result in a personal injury or property

damage.

Do not perform. Must be followed.

Do not disassemble. The power plug must be unplugged from the

wall outlet.

Major Safety Precautions 1-3

Power Related

The following images are for your reference and may differ depending on models and countries.

Warning

Caution

Do not touch. Must be grounded to prevent electric shock.

Plug the power plug in firmly.

• Otherwise, it may result in fire.

Avoid connecting multiple electric appli-

ances to a single wall outlet.

• Otherwise, it may result in fire due to

overheating of the wall outlet.

Avoid using a damaged power cord or plug

or a loose power outlet.
