Samsung Xpress M2675FN Manuel utilisateur

M267x series

M287x series

M288x series

BASIC

User’s Guide

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on Windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 5

Features by model 7

Useful to know 13

About this user’s guide 14

Safety information 15

Machine overview 21

Control panel overview 24

Turning on the machine 28

Installing the driver locally 29

Reinstalling the driver 31

2. Menu Overview and Basic Setup

Menu overview 33

Machine’s basic settings 37

Media and tray 39

Basic printing 54

Basic copying 60

Basic scanning 65

Basic faxing 66

3. Maintenance

Ordering supplies and accessories 71

Available supplies 72

Available maintenance parts 73

Storing the toner cartridge 74

Redistributing toner 76

Replacing the toner cartridge 79

Replacing the imaging unit 82

Monitoring the supplies life 84

Setting the toner low alert 85

Cleaning the machine 86

Tips for moving & storing your machine 93

4. Troubleshooting

Tips for avoiding paper jams 95

Clearing original document jams 96

Clearing paper jams 99

Understanding the status LED 107

Understanding display messages 110

BASIC

5. Appendix

Specifications 116

Regulatory information 126

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 5

• Features by model 7

• Useful to know 13

• About this user’s guide 14

• Safety information 15

• Machine overview 21

• Control panel overview 24

• Turning on the machine 28

• Installing the driver locally 29

• Reinstalling the driver 31

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature.

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 232).

• To save paper, you can print on both sides of the paper (double-sided

printing) (see "Using advanced print features" on page 232).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print with a resolution of up to 4,800 x 600 dpi effective (600 x 600

x 3 bit) output.

• Fast, on-demand printing.

M267x series:

- For single-side printing, up to 26 ppm (A4) or up to 27 ppm (Letter).

M287x/M288x series:

- For single-side printing, up to 28 ppm (A4) or up to 29 ppm (Letter).

Convenience

• Simply touch your mobile device on the NFC tag on your printer and get the

print job done (see "Using the NFC feature" on page 197).

• You can print on the go from your smartphone or computer using Google

Cloud Print™ enabled apps (see "Google Cloud Print™" on page 205).

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 263).

Key benefits

• Samsung Easy Printer Manager and Printing Status is a program that

monitors and informs you of the machine’s status and allows you to

customize the machine’s settings (see "Using Samsung Printer Status" on

page 273or "Using Samsung Easy Printer Manager" on page 270).

• Samsung Easy Document Creator is an application to help users scan,

compile, and save documents in multiple formats, including .epub format.

These documents can be shared via social networking sites or fax (see

"Using Samsung Easy Document Creator" on page 269).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 264).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 118).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 232).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 232).

• You can print in various operating systems (see "System requirements" on

page 121).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or

Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 166.

Features by model

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For Windows, select the printer driver and software in the Select Software to Install window.

Operating System M267x series M287x series

M288x series

Windows ● ●

Mac ● ●

Linux ● ●

Unix ●

Software M267x series M287x series

M288x series

SPL printer drivera● ●

PCL printer driver ●

PS printer drivera

Features by model

XPS printer driverb● ●

Direct Printing Utilityb

Samsung Easy Printer

Manager

Scan to PC settings ● ●

Fax to PC settings ●

(M267xF/M267xFN/M267xFH/M267xHN only)

●

(M287xFD/M287xFW/M287xHN/M288xFW/

M288xHW only)

Device settings ● ●

Samsung Printer Status ● ●

Samsung AnyWeb Printb● ●

Samsung Easy Document Creator ● ●

Easy Capture Manager ● ●

SyncThru™ Web Service ●

(M267xN/M267xFN/M267xHN only)

●

SyncThru Admin Web Service ●

(M267xN/M267xFN/M267xHN only)

●

Easy Eco Driver ● ●

Easy Capture Manager ● ●

Software M267x series M287x series

M288x series

Features by model

(●: Included, Blank: Not available)

Fax Samsung Network PC Fax ●

(M267xF/M267xFN/ M267xFH/ M267xHN

only)

●

(M287xFD/M287xFW/M287xHN/M288xFW/

M288xHW only)

Scan Twain scan driver ● ●

WIA scan driver ● ●

a. Depending on the operating system you use, the installed printer driver may differ.

b. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Download). Before installing, check whether your

computer’s OS support the software.

Software M267x series M287x series

M288x series

Features by model

Variety feature

Features M267x series M287x series

M288x series

Hi-Speed USB 2.0 ● ●

Network Interface Ethernet 10/100 Base TX

wired LAN

●

(M267xN/M267xFN/M267xHN only)

●

Network Interface 802.11b/g/n wireless LANa●

(M287xDW/M287xFW/M288xFW/M288xHW only)

NFC (Near Field Communication) ●

(M288xFW/M288xHW only)

Google Cloud Print™ ●

(M267xN/M267xFN/M267xHN only)

●

AirPrint ●

(M267xN/M267xFN/M267xHN only)

●

Eco printing ● ●

Duplex (2-sided) printing ●

Duplex (2-sided) printing (manual)bc ●

Document Feeder Automatic Document

Feeder (ADF)

● ●
