Samsung YP-T5 yepp' Manuel utilisateur

- MP3 and WMA playback

- Removable Storage Device

- Encoding function

- FM reception

- 3D sound

- Upgradable

- 12 hours of continuous play

YP-T5

AH68-01567S (Rev 0.0)

SAMSUNG ELECTRONICS CANADA, INC.

HEADQUARTERS

7037 Financial Drive, Mississauga, Ontario, Canada L5N 6R3

TEL: 1-905-542-3535

www.samsung.ca

SERVICE DIVISION

7037 Financial Drive, Mississauga, Ontario, Canada L5N 6R3

1-800-SAMSUNG (1-800-726-7864)

T5_cover_eng_can0.0 11/11/04 14:2812:0 Page 1

Contents

Basic Usage

Playing Music and Turning Off the Device 26

Adjusting the Volume/Hold Function 27

Recording Voice 28

MP3 Encoding 29

Searching for Music/Voice Files 30

Listening to FM Radio 31

FM Encoding 33

Preparations

Safety Instructions 4

Features 6

Accessories 9

Location of Controls (yepp) 10

Connection to Computer

Connecting the yepp to a PC 12

Manual Installation of the USB Driver 16

Using the removable storage 20

●Downloading/Uploading files 20

●Disconnecting the USB cable 21

●Formatting 22

Installing yepp Studio 23

To View Help on yepp Studio 25

Loop Repeating 34

Using Navigation 35

Setting Playlist 36

Setting up MENU 37

Managing Files 38

●Deleting 38

●Formatting 39

Setting the Advanced Functions 40

Selecting the Playmode 41

Setting the EQ mode 42

DISPLAY 43

●Scroll Speed /Time 43

●Backlight 44

●Contrast 45

Power OFF Time 46

●Time / Sleep 46

ENCODE 47

●Bitrate / AutoSync Time 47

WOW LEVEL 48

●Adjusting SRS and TruBass LEVEL 48

●WOW Optimum 48

DEFAULT VOLUME 49

Appendix

MENU Table 50

Customer Support

Troubleshooting 52

Specifications 54

Warranty 55

Additional Usage

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 2

Safety Instructions Earphones

Follow Traffic Safety Instructions

●

Do not use the earphones while driving an automobile or riding a bicycle.

It’s not only dangerous, but also against the law.

●

An accident may result if you turn up the volume of the earphones too high while walking

down the street, especially when crossing at intersections.

Protect your ears

●

Do not turn the volume up too high.

Doctors warn against prolonged exposure to high volumes.

●

Stop using the device or turn the volume down if you get ringing in your ears.

●

Follow local guidelines for waste disposal when discarding packaging, batteries,and old

electronic appliances.

●

yepp packaging uses cardboard, polyethylene etc., and does not use

any unnecessary materials.

●

Ambient temperature : 5°C ~ 35°C (41°F ~ 95°F)

●

Humidity : 10% ~ 75%

Read and understand all the instructions to avoid injury to yourself and damage to the equipment.

✽

Please be aware that we claim no responsibility for damage from data loss

due to breakdown, repair or other causes.

Do not expose to extreme

temperatures (above 95°F or below

23°F). Do not expose to moisture.

Do not apply excessive pressure

to the device.

Do not expose to chemicals such

as benzene and thinners.

Remove batteries when the device

is left unused for a long period of

time.

Do not expose to direct sunlight

or heat sources.

Do not store in dusty areas.

Do not place heavy objects on top

of the device.

Do not let any foreign matter spill

into the device.

Do not try to disassemble and

repair the device yourself.

Ambient operating conditions

Environmental Information

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 4

MP3 & WMA Playback

●MP3 is an MPEG1 Layer3 audio format.

●WMA is a Microsoft Windows Media audio format.

Removable Storage Device

●You can easily copy and paste files to the yepp player using Windows Explorer.

Encoding Function

●You can make an MP3 file from an external source using the ENC jack

on the main unit.

●You can also convert an FM radio program into an MP3 file in real time.

FM Reception

●Listening to an FM program is made easy with Auto Search and Frequency

Memory functions.

3D Surround Sound

●The 3D surround feature adds spaciousness to the sound.

Upgradable

●You can upgrade the built-in programs when available.

Add functions, CODEC, etc. Please check the yepp home page

(http://www.samsungyepp.com)for upgrades.

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 6

12-Hour Continuous Play

●This unit uses one AAA/LR03 alkaline battery. Operation can last up to 12hours.

Actual playing time may vary according to the type and capacity of the battery.

Voice Recording Function

●You can make high quality voice recordings.

●

The capacity of the useable built-in memory is less than indicated as the internal firmware

uses a part of the memory as well.

●

Design of accessories is subject to change, for the purposes of improvement, without notice.

Accessories

Player Earphones

AH30-00064D

USB cable

AH39-00589A

User manual

AH68-01475A

Installation CD

AH80-00063D

One Battery

(1.5V AAA/LR03 type)

4301-000115

Neck Strap

AH61-01619A

Carrying case

AH61-01618A

Direct Connect

USB Adaptor

AH39-00590A

Line In Cable

AH39-00567A

Model

Built-in memory

YP-T5 H

128MB

YP-T5 V

256MB

YP-T5 X

512MB

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 8

Location of Controls (yepp)

Playtime indicator

Mode indicator

Bit rate indicator

Play mode indicator

Equalizer, SRS indicator

Play/Stop/Pause indicator

Remaining Battery Power indicator

Track Number indicator

Title (track & artist) indicator

Display

Inserting a Battery

Recording Button

Play/Pause Button

Hold Switch

Loop Repeating Button

USB Cable

Connection Port

ENC Jack

Microphone

Neck strap Hook

MENU, Navigation button/Joystick

Move to Track/Speed Search/

Volume Button

Display

Earphone Jack

Battery Cover

Slide the cover in the

direction of the arrow to open.

Insert a battery to the right poles

+ , – and push-close the cover in the

direction the arrow as indicated.

NNoo

oott

ttee

●

Do not place heavy objects on the cover.

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 10

Connecting the yepp to a PC

Before connecting yepp to PC, make sure to install

USB driver. If “Add New Hardware Wizard”appears,

press the [Cancel] button and install the USB driver.

System

Requirements.

The PC system must meet the

following specifications:

●

Pentium 133MHz or greater.

●

Windows 98 SE/ME/2000/XP.

●

40MB of available hard disk space

●

CD-ROM drive.

(double speed or greater)

●

USB port (1.1) supported.

●

DirectX 8.0 or above.

Continued...

NNoo

oott

ttee

●

Install the operating system in

Administrator Account mode for Windows

2000 or XP. Otherwise, installation will not

be completed.

●

Windows ME, 2000 and XP can recognize

the driver without installing the provided

program. However, you must install the

program in order to format yepp and

upgrade firmware.

●

If the YP-T5 program has not been

installed in Windows 98, then it will not

communicate with your removable disk.

You must install the USB driver file first.

Installing software

1Insert the Installation CD into the CD-ROM drive.

The picture shown below appears.

Select [yepp USB Driver] 2Click [Next] in the series of windows that appear.

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 12

Connect a USB cable to the USB port on the

computer.

Connect the other end of a USB cable to the USB cable

connection port on the bottom of the yepp, and press

the button on the main unit.

●

If you disconnect the USB cable from your PC while

implementing a command or initializing during USB

driver installation, your PC may not function correctly.

Upon installation of the USB driver

"Samsung yepp YP-T5" will appear in the

[System Properties]

→

[Device Manager].

The USB driver is installed with a message saying that

it is searching for a new device. You may not see the

display screen during installation.

Go to the device manager to check that

installation has been successfully completed.

How to check the USB driver

●

Windows 98/ME:

Control Panel

→

System

→

Device Manager

→

Disk Drives

→

Samsung yepp YP-T5

●

Windows 2000:

Control Panel

→

System

→

Hardware

→

Device Manager

→

Disk Drives

→

Samsung yepp YP-T5

USB Device

●

Windows XP:

Control Pane

→

System

→

Hardware

→

Device Manage

→

Disk Drives

→

Samsung yepp YP-T5

USB Device

When the USB driver is not installed automatically,

refer to the next page.

Connecting the yepp to a PC with a USB cable

Connecting the yepp to a PC

USB connect cable

YPT5_Eng_Can_Rev0.0 11/11/04 14:1112:0 Page 14

Manual Installation of the USB Driver

Go to “Downloading/Uploading files” on page 20 if the USB driver is in place.

Follow these steps if the USB driver is not in place :

Check the device manager.

●

Windows 98/ME:

Control Panel

→

System

→

Device Manager

●

Windows 2000 (Professional):

Control Panel

→

System

→

Hardware

→

Device Manager

●

Windows XP (Professional):

Control Panel

→

System

→

Hardware

→

Device Manager

Check if there is a device listed with an

exclamation point or a question mark

(displayed as unknown device or USB device).

Double click on the device listed with an exclamation

point or a question mark.

After selecting the driver,

click on [Update Driver].

4Select a compatible driver,

click on [Next] to finish.

NNoo

oott

ttee

●

If you are using Windows 2000 and your version of Windows does not recognize the USB driver,

please download and install the latest service pack from windowsupdate.microsoft.com

●

The installation method may vary depending on the type of PC or operating system.

Contact your PC dealer or service center for installation information.

●

If errors occur continuously when you install the USB driver,

reconnect the USB cable after rebooting your system.

When an error occurs during installation of the USB driver

YPT5_Eng_Can_Rev0.0 11/11/04 14:1212:0 Page 16

In Windows 98

Manual Installation of the USB Driver

●

You must reboot your computer to

complete the installation.

USB driver location

[CD ROM]\setup\Drivers

NNoo

oott

ttee

●

You cannot use it as a removable disk in Windows 98 if the YP-T5 program is not installed.

Make sure to install the USB driver file first.

Click [Next] button in the series of windows that appear.

YPT5_Eng_Can_Rev0.0 11/11/04 14:1212:0 Page 18

Autres manuels pour YP-T5 yepp'

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Lecteur MP3

Samsung

Samsung YP-S5 Manuel utilisateur

Samsung

Samsung YP-55I Manuel utilisateur

Samsung

Samsung YP-P2 Manuel utilisateur

Samsung

Samsung YP-R0 Manuel utilisateur

Samsung

Samsung YP S3JCW - 8 GB Digital Player Manuel utilisateur

Samsung

Samsung Yepp YP-300S Mode d’emploi

Samsung

Samsung Yepp YP-T6H Guide de démarrage rapide

Samsung

Samsung Yepp YP-35 Manuel utilisateur

Samsung

Samsung YP-60V - YEPP Sports 256 MB Digital Player Manuel utilisateur

Samsung

Samsung YP-P2 Manuel utilisateur

Samsung

Samsung YP-S3AG Manuel utilisateur

Samsung

Samsung YP-T7FV Manuel utilisateur

Samsung

Samsung YP-K5 Manuel utilisateur

Samsung

Samsung Yepp YP-35 Manuel utilisateur

Samsung

Samsung YPT9JABXAA Manuel utilisateur

Samsung

Samsung YP-U3JAW Manuel utilisateur

Samsung

Samsung YP-55H Manuel utilisateur

Samsung

Samsung Napster YH-920 Manuel utilisateur

Samsung

Samsung YP-F3AL Manuel utilisateur

Samsung

Samsung YP-U5 Manuel utilisateur

Samsung

Samsung YP-T5V - YEPP 256 MB Digital Player Manuel utilisateur

Samsung

Samsung YH-925GS Manuel utilisateur

Samsung

Samsung YH-820 Manuel utilisateur

Samsung

Samsung YP-Z5Z - 1 GB Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
