Samsung YP-P3 Manuel utilisateur

SERVICE

Manual

YEPP

Model Name : YP-P3

Model Code : YP-P3JCB/XEE

YP-P3JCB/XEF

YEPP

Refer to the service manual in the GSPN (see the rear cover) for the more information.

CONTENTS

1. Precaution

2. Product Specification

3. Disassembly & Reassembly

4. Troubleshooting

5. Exploded View & Part List

6. PCB Diagram

7. Schematic Diagram

YP-P3

This Service Manual is a property of Samsung Electronics

Co.,Ltd. Any unauthorized use of Manual can be punished

under applicable International and/or domestic law.

GSPN (Global Service Partner Network)

Area Web Site

North America service.samsungportal.com

Latin America latin.samsungportal.com

CIS cis.samsungportal.com

Europe europe.samsungportal.com

China china.samsungportal.com

Asia asia.samsungportal.com

Mideast & Africa mea.samsungportal.com

Printed in Korea

Contents

1. Precaution

1-1 Safety Precautions...........................................................................................1-1

1-2 Static Electricity Precautions............................................................................1-2

2. Product Specification

2-1 Product Feature ...............................................................................................2-1

2-2 Specifications...................................................................................................2-2

2-3 Specifications Analysis.....................................................................................2-3

2-4 Accessories......................................................................................................2-5

3. Disassembly & Reassembly

3-1 Disassembly Method........................................................................................3-1

4. Troubleshooting

4-1 Checkpoints by Error Mode..............................................................................4-2

4-2 Upgrade Methods.............................................................................................4-12

5. Exploded View & Part List

5-1 Exploded View .................................................................................................5-2

5-2 Electrical Part List ............................................................................................5-4

6. PCB Diagram

6-1 MAIN PCB Top .................................................................................................6-2

6-2 MAIN PCB Bottom ...........................................................................................6-4

7. Schematic Diagram

7-1 Overall Block Diagram .....................................................................................7-2

7-2 Power Management.........................................................................................7-3

7-3 TCC7801 Power_Block....................................................................................7-4

7-4 TCC7801 I/O Setting........................................................................................7-5

7-5 Memory (SDRAM, NAND-flash).......................................................................7-6

7-6 Audio CODEC..................................................................................................7-7

7-7 24pin I/O, Interface...........................................................................................7-8

7-8 WQVGA LCD Interface ....................................................................................7-9

7-9 Blue-Tooth, FM.................................................................................................7-10

Samsung Electronics 1-1

Precaution

1. Precaution

1-1 Safety Precautions

1. Do not use liquid or an aerosol cleaner when wiping dirt from the case lid. Instead, use a dry cloth.

2. Do not use attachments which the company doesn’t recommend. This may cause danger or damage.

3. Do not use the product near a source of water, e.g., bathtub, bucket, sink, washing machine, swimming pool, or

lake.

4. Power: Use only the type of battery specified on the label.

5. Do not insert any objects or liquid into the product. This may cause failure or malfunctioning.

6. A technician must use standard parts when replacement is required. Using non-standard parts may cause

failure.

1-2 Samsung Electronics

Precaution

1-2 Static Electricity Precautions

Some semiconductor devices may easily be damaged by static electricity. In general these devices are called

Electro-static Devices (ESD). Representative examples of ESDs are IC, FET and semiconductor chips. The

following procedure must be performed to reduce damage to devices due to static electricity.

1. Ensure that all electric charges are discharged from your body by using grounded materials when dealing with

semiconductor devices or equipment with semiconductor devices. Another way is to use a commercialized

anti-static electricity bracelet. It must be removed, however, due to potential impact before applying power to

equipment under testing.

2. After removing an electronic device with an ESD, place it on a conductible surface, e.g., aluminum foil, to

prevent a build-up of electric charge, or exposure of the device.

3. Make sure to use a soldering iron with its end grounded to solder the ESD or to remove soldering.

4. Minimize movements of the body when dealing with an ESD which is not wrapped for replacement.

(Otherwise it may cause static electricity due to unconscious actions, e.g., friction between your clothing,

moving a foot on the carpet.)

Samsung Electronics 2-1

Product Specification

2. Product Specification

2-1 Product Feature

Stylish Slim Design

- 9.9mm Stylish Slim Design

- Tempered glass touch screen + beautiful metal design.

- Wide 3" screen with high portability and multi format playback.

Emoture™2.0 + Widgets + Haptic

- Offers a more convenient touch interface than Emoture™1.0

- Offers color icons and stylish GUI, and enables user to move icons freely.

- The menu screen can be neatly personalized with the widget function using Flash.

- A vibration motor maximizes the feeling of touching the product.

Supports an external speaker

- User can listen to music without earphones anywhere, as an external speaker is supported.

2-2 Samsung Electronics

Product Specification

2-2 Specifications

Basic Specification

Rating DC 5.0V / 1A

Built-in Battery Power 610mAh / DC 3.7V

File Compatibility

AUDIO: MPEG1/2/2.5 Layer3 (8kbps ~ 320kbps, 22kHz ~ 48kHz),

WMA(8kbps ~ 320kbps, 8kHz ~ 48kHz), Ogg (Q-1 ~ Q10),

FLAC (Free Lossless Audio Codec),

AAC-LC (16kbps ~ 256kbps, 8kHz ~ 48kHz),

AAC-Plus (16kbps ~ 256kbps, 16kHz ~ 44.1kHz),

Enhanced-AAC-Plus (16kbps ~ 56kbps, 32kHz ~ 44.1kHz)

VIDEO: AVI/SVI: MPEG-4 Video (480x272) Simple Profile,

MP3 Audio (44.1KHz, 128kbps), WMV: WMV9 Video (480x272)

Simple Profile, WMA Audio, Max bitrate 860kbps

MP4: H.264/AVC Video (480x272) Baseline Profile @ Level 1.3,

AAC/AAC+ Audio

IMAGE: JPEG (Baseline, Progressive), BMP (Max 32bit), PNG,

GIF (89a/87a)

Earphone Output 20mW/Ch. (based on 16Ω)

Output Frequency Range 20Hz ~ 20kHz

Signal to Noise Ratio 89dB with 20kHz LPF (based on 1kHz 0dB)

Play Time

Music: Max. 30hours

(MP3 128kbps, Volume: 15, Normal Sound Mode, LCD Off)

Video : Max. 5hours (Brightness 5, Volume: 15, Normal Sound Mode)

Temperature Range for

Operation -5 ~ 35˚C (23 ~ 95˚F)

Case Tempered glass, Plastic, Aluminum

Weight 96g

Dimensions (WxHxD) 52.7 x 102 x 9.9 mm

Speaker

Rated Output 0.8W Mono

Impedance 8Ω

Frequency

Range 400Hz ~ 20kHz

FM Frequency 87.5 ~ 108.0MHz

FM Signal to

Noise Ratio 45dB

FM T.H.D 0.8%

FM Useable

Sensitivity 5dB

Samsung Electronics 2-3

Product Specification

2-3 Specifications Analysis

Model Name YP-P3 YP-P2


Basic

Storage Type Flash Memory (MLC) Flash Memory (MLC)

LCD Display

Size: 3.0" 16.7M WQVGA

Display Color: 16.7M LCD

(Dot pitch: 0.0455(H) x 0.1365(V))

Resolution: 480RGB(H) x 272(V)

Size: 3.0" 16.7M WQVGA

Display Color: 16.7M LCD

(Dot pitch: 0.0455(H) x 0.1365(V))

Resolution: 480RGB(H) x 272(V)

Platform TCC79x (Telechips) TCC78x (Telechips)

Battery Type Li-Polymer rechargeable battery Li-Polymer rechargeable battery

Battery Capacity Built-in rechargeable battery capacity 610 mAh Built-in rechargeable battery capacity 830 mAh

Playing Time

35 hrs when using the earphones

(MP3 128 kbps, Volume 20, Normal Sound

Mode), Play Movies for 5 hrs

35 hrs when using the earphones

(MP3 128 kbps, volume 20, normal sound

mode), play movies for 5 hrs

Color Black/Silver Black/White/Red Wine

Capacity 4G/8G/16G/32G 2G/4G/8G/16G

Case Tempered glass, Plastic, Aluminum Plastic, Aluminum

Widgets X

Colorful +

Moving GUI

X

HAPTIC X

Speaker Output (Mono) X

Files

Supported

MP3  

WMA  

OGG (up to Q10) (up to Q10)

WAV X X

AAC X

Audible X X

JPEG  

FLAC X

APE X X

WMV  

MPEG4 (SVI)  

SWF X

Others X X

DRM

Netsync (Korea)  

SKT Melon (Korea) X X

WMA DRM  

Janus  

: application, X: non-application

2-4 Samsung Electronics

Product Specification

Model Name YP-P3 YP-P2


Sound

Field

DNSE

DNSE 3.0

(General, Studio, Rock, Classical, Jazz, Ballad,

Club, R&B, Dance, Cafe, Concert, Cathedral)

DNSE 2.0

(General, Studio, Rock, Classical, Jazz, Ballad,

R&B, Dance, Concert)

User EQ (9 Band Control) (9 Band Control)

Street Mode  

Sound Feedback (AUI) (AUI)

High-pitched Sound

Recovery

X

Playlist DNSE X

Speed Control (MP3 file play 0.75~1.3X) (MP3 file play 0.75~1.3X)

Output Power

(Earphone) 20mW/CH 20mW/CH

Output Power

(Speaker) 800mW (Mono) X

Tuner

FM  

RDS  

ETC X X

Additional

Functions

Alarm  

Bluetooth  

Photo Viewer (Slideshow Effect) 

Text Viewer  

Game  

Dictionary  

Wallpaper  

World Clock (Support More) 

Voice Recording  

FM Recording  

Wise Volume

(Hearing Protection)

X

Address Book  

Data Cast  

Flash Player X

Calculator  

TTS (Text to Speech) X

Calendar  

MEMO X

Bookmark TEXT, VIDEO, TTS TEXT, VIDEO

Vive Woofer

(Using Haptic)

(Music, Video) X

Quick Tray (Home Key, Hold, Sound Output, Bluetooth) X

Mini Player (Music, FM) X

: application, X: non-application

Samsung Electronics 2-5

Product Specification

2-4 Accessories

2-4-1 Supplied Accessories

Accessories Item Item code Remark

Earphones AH59-01884A

Samsung Service CenterUSB Cable AH39-00899A

Program Installation CD

XEE AH46-00088C

XEF AH46-00088D
