ELECTRONICS

OWNER’S MANUAL

SGH-M100

MP3 Player

Printed in Korea

Code No.: GH68-xxxxxA

English. 07/2000. Rev. 1.0

World Wide Web

http://www.samsungmobile.com

Contents

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connecting the Remote Control . . . . . . . . . . . . . . 4

Connecting to External Audio Equipment . . . . . . 6

Installing the MP3 Software(for Windows 95/98) . . 7

Downloading MP3 Music Files . . . . . . . . . . . . . . . 8

Playing MP3 Music . . . . . . . . . . . . . . . . . . . . . . . 12

Using the Remote Control Keys . . . . . . . . . . . . . 13

Using the Phone Keys . . . . . . . . . . . . . . . . . . . . . 14

Selecting Repeat Options . . . . . . . . . . . . . . . . . . 16

Selecting the Sound Mode . . . . . . . . . . . . . . . . . 17

Answering a Call in MP3 Mode . . . . . . . . . . . . . 17

Making a Call in MP3 Mode . . . . . . . . . . . . . . . . 18

Using the MP3 Menus . . . . . . . . . . . . . . . . . . . . . 19

Accessing the MP3 Menus . . . . . . . . . . . . . . . . 19

Incoming Call (Menu 1) . . . . . . . . . . . . . . . . . . . . 20

Screen Mode (Menu 2) . . . . . . . . . . . . . . . . . . . . 21

File Delete (Menu 3) . . . . . . . . . . . . . . . . . . . . . . 21

Memory Inform (Menu 4) . . . . . . . . . . . . . . . . . . 21

Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . 22

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

More Information on MP3 . . . . . . . . . . . . . . . . . . 25

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Your SGH-M100 phone can be used as an MP3 player

and this manual provides information on how to:

• Download MP3 music files to your phone

• Play them on your phone

What is MP3?

MP3 is a standard audio file format enabling a sound

sequence to be compressed into about one-twelfth

the size of the original file with very little loss in

sound quality.

See the appendix at the end of this manual for

further details.

Notes:

• It is not permitted to copy and offer the software

supplied with the SGH-M100 phone for sale. It

is for your personal use only.

• All product names are trademarks or registered

trademarks of their respective owners.

GGeettttiinnggSSttaarrtteedd

Getting Started

Connecting the Remote Control

You can only listen to MP3 music through the remote

control supplied with your phone.

Note: You can use the clip on the remote control

to fix it to your pocket or lapel for example.

To connect the remote control to your phone, proceed

as follows.

1. Gently pull open the flap marked REMOTE on

the left side of the phone.

2. Rotate the flap so that it does not obstruct the

socket.

3. Plug the remote control connector into the socket.

Key Function

Starts or stops playing MP3 music.

Makes or answers a call.

When pressed, skips back to the beginning

of the current track or to the previous

track. When held down during playback,

searches backwards through the track.

When pressed, skips to the next track.

When held down during playback,

searches forwards through the track.

Allows you to select part of a track and

repeat it indefinitely.

Adjusts the earphone volume.

Locks the keys to prevent them from being

pressed unintentionally.

See the chapter entitled Playing MP3 Music for

further details.

Remote control keys

Earphone

Remote control

keys

Microphone

Front Rear

HOLD

Hold

Connector

(to your

phone)

GGeettttiinnggSSttaarrtteedd

Installing the MP3 Software

(for Windows 95/98)

To download MP3 files from your PC to your phone,

you must first install the MP3 Manager software on

your PC.

1. Start Windows.

2. Insert the software CD-ROM supplied with your

phone in the CD-ROM drive.

If Windows automatically runs the CD-ROM, go to

Step 4.

3. In the Windows Explorer, right-click the Samsung

CD-ROM and select Autorun in the popup menu

displayed.

Connecting to External Audio Equipment

Using the adapter cable supplied, you can connect

your phone to:

• External speakers

• An audio system

• A headset

1. Gently pull open the flap marked REMOTE on

the left side of the phone.

2. Rotate the flap so that it does not obstruct the

socket.

3. Plug the adapter cable into the socket.

4. Plug the other end of the adapter cable into the

RCA audio cable of your audio output equipment.

Note: When you connect the phone to external

audio equipment using the adapter cable,

you cannot use the remote control to play

music. Use the phone keys instead.

4. Click [Language] and select the flag corresponding

to the language version to be installed.

External speakers

Adapter cable

GGeettttiinnggSSttaarrtteedd

6. From the Windows task bar, select Start-

Programs-MP3 Manager or double-click the

MP3 Manager icon on your desktop.

4. Switch on your PC and start Windows.

5. Switch on your phone and enter your PIN if

necessary.

The MP3 mode is activated and the following

message is displayed.

Note: You can only download files to your

phone when this message is displayed.

Note: If a printer is already connected to the

parallel port (LPTx), remove it from the

port and connect the download cable.

3. Insert the other end of the cable into the parallel

port on your PC.

Downloading

5. Select MP3 Manager and click INSTALL.

6. When the software has been correctly installed,

the MP3 Manager folder is added to the Program

Files folder and the MP3 Manager icon appears on

your desktop.

Downloading MP3 Music Files

Note: You must first download the MP3 music

files of your choice from an Internet site.

1. Make sure that your PC and phone are switched

OFF before connecting any cables.

2. Insert one end of the download cable (supplied

with the phone) to the connector on the bottom of

your phone.

Download

cable

GGeettttiinnggSSttaarrtteedd

The selected files are downloaded to your phone.

The downloaded MP3 files are saved in your

phone in the order in which you have downloaded

them.

9. To complete downloading, press

the key

disconnect the download cable from your phone.

Now, you can enjoy listening to MP3 music on your

phone.

Notes:

• You can download as many MP3 files as will fit

in the 32 MB of memory installed in your phone.

• If you have removed a printer cable to connect

the download cable to the parallel port, do not

forget to reconnect the printer cable to the port

after you have finished downloading.

• For more information on using MP3 Manager,

refer to the on-line help.

The MP3 Manager window is displayed.

Note: If an error message is displayed when you

start up MP3 Manager, refer to the chapter

entitled Solving Problems on page 22.

7. Select the folder in which you have saved the MP3

files downloaded from an Internet site. The files in

the folder are listed in the <PC> pane of the MP3

Manager window.

8. Select the file(s) to be downloaded and click .

You can also click and drag the file(s) to the

<Phone> pane.

<PC>

pane

<Phone>

pane

Explorer-type

pane

1312

Playing MP3 Music

Once you have downloaded some MP3 files to your

phone, you can listen to them whenever you want.

To play an MP3 file, you can use the remote control

or the keys on the phone.

Note: Before playing MP3 music, make sure that

you have disconnected the download cable

from the phone.

While playing MP3 music, the following information

is displayed on the phone.

Bass amplification

mode

Number

of current

track

Track title

Current operation:

Playback

Forward search

Number of tracks

downloaded Length of current track

01/08 04:05

I Want It That Way

Repeat Flat

Using the Remote Control Keys

Note: For information on how to use the phone

keys, see page 14.

To... Then...

Start playing a track Press .

Adjust the volume Turn .

Stop playing a track Press again.

Skip to the previous Press at the

track beginning of the track.

Skip to the beginning Press during

of the current track playback.

Search backwards Hold down until you

through a track reach the required point.

Note: You do not hear the

music while searching

through a track.

Skip to the next Press .

track

Search forwards Hold down until you

through a track reach the required point.

Note: You do not hear the

music while searching

through a track.

Backward search

Section repetition

PPllaayyiinnggMMPP33MMuussiicc

GGeettttiinnggSSttaarrtteedd

GGeettttiinnggSSttaarrtteeddPPllaayyiinnggMMPP33MMuussiiccPPllaayyiinnggMMPP33MMuussiicc

To... Then...

Repeat a section • Search for the start point.

of your choice •Press the key.

The symbol is displayed.

•Search for the end point.

• Press the key.

The symbol is

displayed and the section is

repeated indefinitely.

Stop repeating Press .

a section The track continues playing

normally.

Using the Phone Keys

The following keys on the phone can be used to play

MP3 music.

To... Then...

Enter the MP3 mode Hold down the key on

the left side of the phone for

a few seconds.

The number, size and name

of the current MP3 file are

displayed.

Start playing a track Press .

Adjust the volume Press and on the left

side of the phone.

To... Then...

Stop playing a track Press again.

Skip to the previous Press at the

track beginning of the track.

Skip to the beginning Press during

of the current track playback.

Search backwards Hold down until you

through a track reach the required point.

Note: You do not hear the

music while searching

through a track.

Skip to the next track Press .

Search forwards Hold down until you

through a track reach the required point.

Note: You do not hear the

music while searching

through a track.

Repeat a section of • Search for the start point.

your choice •Press the key.

The symbol is displayed.

•Search for the end point.

• Press the key.

The symbol is displayed

and the section is repeated

indefinitely.

Stop repeating a Press .

section The track continues playing

normally.

Selecting the Sound Mode

You can set the sound mode by pressing the right

soft key. Each time you press the key, your phone

indicates the selected mode.

The available modes are Flat, Disco, Rock, Jazz,

Metal and Classic.

Answering a Call in MP3 Mode

In MP3 mode you can answer a call at any time.

When a call comes in, press the key on the

remote control or answer the call in the normal way:

•Open the flip

•Press the key or the Accept soft key on the

phone

If you do not want to answer the call, press the

Reject soft key.

See the SGH-M100 User’s Guide for further details.

Note: If a call comes in during playback, your

phone will alert you, depending on the

Incoming Call menu setting. For further

details, see page 20.

PPllaayyiinnggMMPP33MMuussiiccPPllaayyiinnggMMPP33MMuussiicc

To... Then...

Amplify the bass Press one or more

sound times to select one of the

settings:

• MBB1 ( is displayed)

• MBB2 ( is displayed)

• OFF (no icon is displayed)

Note: This function is only

available when the

remote control is

connected.

Selecting Repeat Options

You can set the Repeat mode by pressing the left

soft key. Each time you press the key, your phone

indicates the selected option.

The following options are available.

Repeat: Repeats the selected track.

R.All (Repeat All): Repeats all the tracks in the

phone in the order in which they were downloaded.

Shuffle: Plays all the tracks in random order.

R.Shuf (Repeat Shuffle): Repeats all the tracks in

random order.

Normal: Plays each track in turn.

MBB

1918

Using the MP3 Menus

A menu structure is available to set the various MP3

options available on your phone.

For details on how to use the navigation keys and the

menu index system, refer to the SGH-M100 User’s

Guide.

Accessing the MP3 Menus

In the MP3 mode, a screen similar to the one

illustrated below is displayed.

1. Press the Menu soft key.

Menu 1 (Incoming Call) is displayed.

2. Scroll through the menus using the or

keys until the required menu is displayed, then

press the Select soft key or the key.

3. Select the required setting using the or

keys, then press the Select soft key.

PPllaayyiinnggMMPP33MMuussiicc

Making a Call in MP3 Mode

You can use the remote control to call the last

number dialled.

1. If you are playing music, press the key.

2. To view the last number dialled, press the key.

3. To call the number displayed, press the key

again.

4. End the call by closing the flap or pressing

the key on the phone.

01/08 4.03MB

I Want It That Way

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Lecteur MP3

Samsung

Samsung YH-820 Manuel utilisateur

Samsung

Samsung Yepp YP-U3 Manuel utilisateur

Samsung

Samsung Yepp YP-700 Manuel utilisateur

Samsung

Samsung YP-P3JES Manuel utilisateur

Samsung

Samsung yePP YP-Q1 16GB Manuel utilisateur

Samsung

Samsung YP-Q3 Manuel utilisateur

Samsung

Samsung YPF1X - YEPP 512 MB Digital Player Manuel utilisateur

Samsung

Samsung MCD-SF75 - CD YEPP Manuel utilisateur

Samsung

Samsung YP-20T - YEPP Digital Player Manuel utilisateur

Samsung

Samsung YP-T10JABY Manuel utilisateur

Samsung

Samsung YP-C1 Manuel utilisateur

Samsung

Samsung YP-U6 Manuel utilisateur

Samsung

Samsung YP S3JCW - 8 GB Digital Player Manuel utilisateur

Samsung

Samsung YP-R1 Manuel utilisateur

Samsung

Samsung YP-U2 Manuel utilisateur

Samsung

Samsung YP-55I Manuel utilisateur

Samsung

Samsung YP-T8 Manuel utilisateur

Samsung

Samsung YEPP YP-Q1 Manuel utilisateur

Samsung

Samsung Napster YH-920GS Manuel utilisateur

Samsung

Samsung YP-K3JAB - 4 GB, Digital Player Manuel utilisateur

Samsung

Samsung YP-R1 Manuel utilisateur

Samsung

Samsung YP-U4 Manuel utilisateur

Samsung

Samsung YP-T5H YP-T5V YP-T5X YP-520H Manuel utilisateur

Samsung

Samsung YH-925GS Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
