Samsung YP-K5AB Manuel utilisateur
For Your Safety
Read this manual carefully to ensure proper use of the player and
to avoid any danger or physical damage.
2
WARNING
Product Use
Improper use can result in explosion,
fire or electric shock. To avoid your hearing damage
Do not disassemble, repair
or modify this player on
your own.
Do not get the player wet
or drop it in water.
If the player gets wet, do not
switch it on. Contact a Service
Center.
Do not place the player in
damp, dusty or sooty areas,
as it could result in fire or
electric shock.
Avoid using your player at
high volume levels, as it may
result in permanent
hearing damage.
If you experience ringing in
your ears while using the
earphone, remove the
earphone immediately and
lower the volume.
To avoid a risk of traffic accident
Do not use the earphones while you are
driving a bicycle, automobile or motorcycle.
It can cause a serious accident and furthermore,
is prohibited by law in some areas.
Using the earphones while walking, in particular,
on a crosswalk, can lead to a serious accident.
Take care not to tangle the earphone cable
around your arms or neighboring objects
while driving, working out or walking, as it
could result in a car accident or other
injuries.
Do not leave the player in
areas above 35°C(95°F)
(such as a sauna or inside
a parked car).
During hot weather, the
temperature inside a car may
rise up to 80°C(176°F).
Failing to heed the player instructions may cause serious injury.
Chapter 1. Preparation
3
CAUTION
Product Use
Management of Important Data Avoid malfunction
Be sure to back up
important data.
Please be aware that we
claim no responsibility for
damage from data loss due
to breakdown, repair or other
causes.
Avoid malfunction
Failure to follow all instructions lead to physical injuries or damage to the player.
Do not cause excessive
impact on the player by
dropping it. Do not place
heavy objects on top of the
player.
Prevent any foreign
particles or dust from
entering into the player.
Always use the accessories
provided by or approved by
Samsung.
Do not spray water on the
player. Never clean the
player with chemical
substances such as
benzene or thinner, as it may
cause fire, electric shock or
deteriorate the surface.
Do not place the player near
magnetic objects, as it may
cause a malfunction.
Basic Information .......................................6
Components...............................................6
Screen Display Information........................9
Button Functions......................................10
Charging the battery ................................12
Basic Use.................................................13
Contents
4
Chapter 1. Preparation
Chapter 2.
Loading Your Desired File
Loading Your Desired File......................16
Installing Samsung Media Studio ............16
Connecting to your PC.............................17
Adding Files/Folders in
Samsung Media Studio............................18
Transferring Files to the Player with
Samsung Media Studio............................20
Using as a Removable Disk ...................22
Disconnecting from your PC..................23
Chapter 3. Multimedia function
Listening to Music....................................24
Listening to Music....................................24
Creating a Playlist Using
Samsung Media Studio............................28
To Play a Playlist......................................30
Using the Music Option Menu..................31
Photo Viewing ...........................................33
Photo Viewing..........................................33
Using the Photo Option Menu..................34
Listening to FM Radio .............................35
Listening to FM Radio..............................35
Setting FM Presets ..................................38
To Delete Presets.....................................40
Setting FM Radio.....................................41
For Your Safety ..........................................2
Contents .......................................................4
5
Chapter 4. Setting
Settings.......................................................42
Setting Alarm............................................42
Setting Display.........................................44
Setting Time ............................................46
Setting Language.....................................48
Setting the System ..................................49
Chapter 5. Troubleshooting
Troubleshooting........................................51
Chapter 6. Appendix
Menu Tree...................................................53
Product Specifications............................54
6
Product Features
High-quality Stereo Speaker! Longer Play Time and Shorter
Downloading!
■
Slide the speaker unit to reveal it, with
which you can enjoy a dynamic music.
■
You can share your favorite music anytime
and anywhere.
■
A fully charged battery can play up to 30
hours of music (when using the earphone).
■
The player supports USB 2.0 capability,
much faster than USB 1.1 to enable faster
communication with the PC.
Touchpad Supporting Various File
Formats!
■
You can tap on the touch pad to navigate
through the menus.
■
Supports various file formats including
MP3, WMA and Ogg.
■
The image file is converted to JPG format
before transmitted to the player.
Easy & Simple Menu Structure Convenience
■
Easy to use with a simple menu structure.
■
You can set your own graphic display by
taking advantage of the screen saver and
user equalizer.
■
You can take advantage of a variety of
features including FM radio, alarming,
photo view, etc.
■
You can add your favorite music file to
the alarm melody list.
Chapter 1. Preparation
Product Features/Components
7
Front, Right Side and Top
Power &
Hold Switch
Speaker
Screen Display
Back Button
Play/Pause &
Select Button
Menu Button
Button
All buttons are 'Light-touch' buttons.
Components
Basic Information
8
Bottom/Rear
USB
Connection
Port
Earphone
Jack Reset Hole
Components (Continued)
Basic Information
[Rear]
[Bottom]
Checking the Accessories
Player Earphones USB Cable
Installation CD
■Design of accessories is subject to change for the purpose of improvement, without notice.
Chapter 1. Preparation
Components/Screen Display Information
9
Screen Display Information
Basic Information
NOTE
■ The screen pictures are for illustration purposes only. The actual screen may differ.
1Repeat Play Display
3Music Information
2Equalizer
4Play Status Bar
5Current Music Number/
Total Number Display
6Alarm Display
7Battery Status Display
8Play Time Indicator
9Play/Pause Display
Music
Normal
1.Life is cool
0002/0020
√
00:02:20
1
2
3
4
5
6
7
8
9
10
Button Functions
Basic Information
■
Slide and hold the button in the opposite direction of the arrow to turn the
power on/off.
■ Slide and release it in the arrow direction to lock the buttons.
■ Moving up, down, left and right and Function Selection.
Tap to move up or down by one selection.
Tap to move left or right by one selection.
Press and hold to move up or down continuously.
Short tap to select the play/pause and function, move to the
next screen.
■ Search for a track and control volume while listening to music.
Press and hold to scan to a point on the current track.
Tap to move to the previous track or to play the current track
from the start.
Press and hold to scan to a point on the current track.
Tap and release to move to the next track.
Tap to reduce/increase the volume.
■ Long tap to move to the main menu.
■
Short tap to move to the previous screen.
Buttons Functions and Use
■
Tap to display the option menu.
