Samsung UE46C Manuel utilisateur

LFD DISPLAY

User Manual

The colour and the appearance may differ depending on the

product, and the specifications are subject to change without

prior notice to improve the performance.

UE46C UE55C

BN46-00333A-03

Table of contents

Before Using the Product

Safety Precautions 8

Symbols 8

Cleaning 8

Storage 9

Electricity and Safety 9

Installation 10

Operation 12

Preparations

Checking the Contents 15

Removing the Packaging 15

Checking the Components 16

Parts 18

Control Panel 18

Reverse Side 19

Assembling the Holder-Wire stand 20

Anti-theft Lock 20

Remote Control 21

Connection Using an IR Stereo Cable

(sold separately) 24

Before Installing the Product

(Installation Guide) 25

Tilting Angle and Rotation 25

Ventilation 25

Dimensions 26

Installing the Wall Mount 27

Preparing before installing Wall-Mount 27

Installing the Wall Mount Kit 27

Wall Mount Kit Specifications (VESA) 28

Remote Control (RS232C) 29

Cable Connection 29

Connection 32

Control Codes 33

Connecting and Using a Source

Device

Before Connecting 42

Pre-connection Checkpoints 42

Connecting to a PC 43

Connection using the D-SUB cable

(Analogue type) 43

Connection using a DVI cable (Digital type) 43

Connection Using an HDMI-DVI Cable 44

Connection Using an HDMI Cable 44

Connection Using an DP Cable 45

Changing the Resolution 46

Changing the Resolution on Windows XP 46

Changing the Resolution on Windows Vista 46

Changing the Resolution on Windows 7 47

Changing the Resolution on Windows 8 47

Connecting to a Video Device 48

Connection Using the AV Cable 48

Connection Using the component Cable 48

Connection Using an HDMI-DVI Cable 49

Connection Using an HDMI Cable 49

Connecting to an Audio System 50

Connecting an External Monitor 50

Connecting the network box (Sold separately)51

MagicInfo 51

Changing the Input source 53

Source 53

Using MDC

Configuring Settings for Multi Control 54

Configuring settings for Multi Control 54

MDC Programme Installation/Uninstallation 55

Installation 55

Uninstallation 55

What is MDC? 56

Connecting to MDC 56

Connection Management 59

User Login 60

Auto Set ID 61

Cloning 62

Command Retry 63

Getting Started with MDC 64

Main Screen Layout 65

Menus 65

Screen Adjustment 67

Table of contents

Advanced features 70

Sound Adjustment 72

System Setup 72

Tool Settings 81

Other Functions 84

Group Management 85

Schedule Management 87

Troubleshooting Guide 89

Screen Adjustment

Picture Mode 91

If the input source is PC, DVI or DisplayPort 91

If the input source is AV, Component,

HDMI1, HDMI2 91

Backlight / Contrast / Brightness /

Sharpness / Colour / Tint (G/R) 92

Screen Adjustment 93

Picture Size 93

Position 95

Zoom/Position 95

PC Screen Adjustment 96

Resolution Select 96

Auto Adjustment 97

Rotation 97

Aspect Ratio 98

Advanced Settings 99

Dynamic Contrast 100

Black Tone 100

Flesh Tone 100

RGB Only Mode 100

Colour Space 100

White Balance 101

10p White Balance 101

Gamma 101

Expert Pattern 102

Motion Lighting 102

Picture Options 103

Colour Tone 104

Colour Temp. 104

Digital Noise Filter 104

MPEG Noise Filter 104

HDMI Black Level 105

Film Mode 105

Motion Plus 105

Calibrated value 106

Dynamic Backlight 106

Reset Picture 106

Sound Adjustment

Sound Mode 107

Sound Effect 108

Speaker Settings 109

Reset Sound 110

Network

Network Settings 111

Connecting to a Wired Network 111

Wired Network Settings 112

Connecting to a Wireless Network 113

Wireless Network Setting 114

WPS(PBC) 115

Network Status 116

Soft AP 117

AllShare Settings 117

Device Name 117

System

Multi Control 118

Configuring settings for Multi Control 118

Time 119

Clock Set 119

Sleep Timer 119

On Timer 120

Off Timer 121

Holiday Management 121

Menu Language 122

Rotate menu 123

Eco Solution 124

Energy Saving 124

Table of contents

Eco Sensor 124

No Signal Power Off 124

Auto Power Off 124

Safety Lock 125

Button Lock 125

Change PIN 125

PIP 126

Auto Protection Time 127

Screen Burn Protection 128

Pixel Shift 128

Timer 129

Immediate display 130

Side Grey 130

Ticker 131

Video Wall 132

Format 132

Horizontal 132

Vertical 133

Screen Position 133

Source AutoSwitch Settings 134

Source AutoSwitch 134

Primary Source Recovery 134

Primary Source 134

Secondary Source 134

General 135

Max. Power Saving 135

Game Mode 135

BD Wise 135

Menu Transparency 135

Sound Feedback 136

Auto Power 136

Standby Control 136

Lamp Schedule 137

OSD Display 137

Power On Adjustment 137

Temperature Control 137

Anynet+ (HDMI-CEC) 138

Auto Turn Off 139

Troubleshooting for Anynet+ 140

DivX®Video On Demand 142

Play Mode 142

Magic Clone 143

Reset System 143

Reset All 144

PC module power 144

Synced power-on 144

Synced power-off 144

Support

Software Update 145

By USB 145

Contact Samsung 146

Contents Home 146

MagicInfo Lite 146

MagicInfo Premium S 146

MagicInfo Videowall S 147

AllShare Play 147

Source 148

AllShare Play

What is AllShare Play? 149

Read the following before using AllShare Play

with a USB device 149

Using a USB device 151

Connecting to a PC over a network 152

Using the AllShare Play features 153

Using the Basic AllShare Play Features 154

Sorting the file lists 154

Playing Selected Files 155

Copying Files 155

Creating a Playlist 155

My list 156

My list options 156

Videos 157

Table of contents

Playing a Video 157

Photos 158

Viewing a Photo (or Slide Show) 158

Music 159

Playing Music 159

Videos / Photos / Music Play Option menu 160

Supported Subtitle and AllShare Play

file formats 162

Subtitle 162

Supported image resolutions 162

Supported music file formats 163

Supported Video Formats 163

MagicInfo Lite

File Formats Compatible with

MagicInfo Lite player 165

Read before using MagicInfo Lite player 165

Approving a connected device from the

server 170

MagicInfo Lite 172

MagicInfo Lite player 172

Local Schedule Manager 175

Content manager 182

Settings 184

When Content is Running 186

MagicInfo Premium S

File Formats Compatible with

MagicInfo Premium S Player 188

Read before using MagicInfo Premium S Player 188

Approving a connected device from the

server 194

MagicInfo Premium S 196

MagicInfo Premium S Player 196

Local Schedule Manager 199

Template Manager 206

Content manager 209

Settings 211

When Content is Running 213

MagicInfo Videowall S

File Formats Compatible with

MagicInfo Videowall S Player 215

Read before using MagicInfo Videowall S Player 215

MagicInfo Videowall S 218

Settings 218

When Content is Running 219

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Centre 220

Testing the Product 220

Checking the Resolution and Frequency 220

Check the followings. 221

Q & A 228

Specifications

General 230

PowerSaver 233

Preset Timing Modes 234

Appendix

Contact SAMSUNG WORLD WIDE 236

Responsibility for the Pay Service

(Cost to Customers) 245

Not a product defect 245

A Product damage caused by customer's

fault 245

Others 245

WEEE 246

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment) 246

Table of contents

Correct disposal of batteries in this product 246

Optimum Picture Quality and Afterimage

Burn-in Prevention 247

Optimum Picture Quality 247

Prevention of Afterimage Burn-in 248

Licence 250

Terminology 251

Before Using the Product

Chapter 01

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

•An administration fee may be charged if either

-(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

-(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

•The amount of such administration charge will be advised to you before any work or home visit is carried out.

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

•Do not use detergents that contain alcohol, solvent or

surface-active agents.

•Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used

nearby.

―Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be

charged).

Electricity and Safety

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•An electric shock or fire may result.

Do not use multiple products with a single power socket.

•Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock

may result.

Insert the power plug all the way in so it is not loose.

•An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

•An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the

power cord under a heavy object.

•Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with

a dry cloth.

•A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not

use the power cord with other products.

•A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•The power cord must be disconnected to cut off power to the product

when an issue occurs.

•Note that the product is not completely powered down by using only

the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

•An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF

THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•A fire may result.

Have a technician install the wall-mount hanger.

•Installation by an unqualified person can result in an injury.

•Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or

closet.

•An increased internal temperature may cause a fire.

Install the product at least 10cm away from the wall to allow ventilation.

•An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•Children may suffocate.

Autres manuels pour UE46C

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung HP-P5071 Manuel utilisateur

Samsung

Samsung SMT-2233 Manuel utilisateur

Samsung

Samsung SyncMaster 320P Guide d'installation

Samsung

Samsung SyncMaster 730MP Manuel utilisateur

Samsung

Samsung SyncMaster S24B750V Manuel utilisateur

Samsung

Samsung SyncMaster 2494HM Manuel utilisateur

Samsung

Samsung 2493HM - SyncMaster - 24" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 9 Series Manuel utilisateur

Samsung

Samsung PL-42D5S Manuel utilisateur

Samsung

Samsung 953BW - SyncMaster - 19" LCD Monitor Guide de l'utilisateur

Samsung

Samsung S24R352FHU Manuel utilisateur

Samsung

Samsung 910MP - SyncMaster 19" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 151P Manuel utilisateur

Samsung

Samsung S A33 Series Manuel utilisateur

Samsung

Samsung SyncMaster 2043SN Manuel utilisateur

Samsung

Samsung SyncMaster 551v Manuel utilisateur

Samsung

Samsung SyncMaster 400TSn-2 Manuel utilisateur

Samsung

Samsung QM85D Manuel utilisateur

Samsung

Samsung C49J892DK Series Manuel utilisateur

Samsung

Samsung S32A80 Series Manuel utilisateur

Samsung

Samsung SyncMaster 192B Manuel utilisateur

Samsung

Samsung QB43R Manuel utilisateur

Samsung

Samsung SyncMaster 2063UW Guide de l'utilisateur

Samsung

Samsung SyncMaster S22A650D Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
