Samsung SyncMaster 152 V Manuel utilisateur

SyncMaster 153V/173V/152V/172V/193V/192V/153S/173S/153B/173B

Main Page On-Screen Display

Safety Instructions Troubleshooting

Notational Check List

Power Q & A

Installation Self-Test Feature Check

Cleaning

Other

Introduction Specifications

Unpacking General Specifications

Front PowerSaver

Rear Preset Timing Modes

Setup Information

Connecting the Monitor Service

Installing the Monitor Driver Terms

Automatic Regulatory

Manual Natural Color

Installing VESA compliant mounting For Better Display

Authority

English > Main > Safety Instructions > Notational

Notational

Power

Installation

Clean

Other

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

English > Main > Safety Instructions > Power

Notational

Power

Installation

Clean

Other

When not used for extended periods of time, set your computer to DPMS. If

using a screen saver, set it to the active screen mode.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet

hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment

damage.

Do not excessively bend the plug and wire nor place heavy objects

upon them, which could cause damage.

zThis may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause a fire.

English > Main > Safety Instructions > Installation

Notational

Power

Installation

Clean

Other

Put your monitor in a location with low humidity and a minimum of

dust.

zAn electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor can cause injury by falling.

Set down the monitor carefully.

zIt could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

Installing a wall bracket must be done by a qualified professional.

zInstallation by unqualified personnel may result in injury.

zAlways use the mounting device specified in the owner's manual.

Leave a space for ventilation between the product and the wall.

zPoor ventilation may cause the interior temperature to rise and lead

to a fire.

English > Main > Safety Instructions > Clean

Notational

Power

Installation

Clean

Other

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe

with a slightly moistened, soft fabric.

Do not spray detergent directly on the monitor.

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty,

clean it properly with a dry cloth.

zA dirty connector can cause an electric shock or fire.

Do not set a glass of water, chemicals or any small metal objects

on the monitor.

zThis may cause damage, electric shock or a fire.

zIf a foreign substance gets into the monitor, disconnect the plug

and then contact a service center.

Contact a Service Center or Customer Center for interior cleaning

once a year.

zKeep the product's interior clean. Dust which has accumulated in

the interior over an extended period of time may cause malfunction

or a fire.

English > Main > Safety Instructions > Other

Notational

Power

Installation

Clean

Other

Do not remove cover(or back). No user serviceable parts inside.

zThis may cause an electric shock or a fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there

are any unusual sounds or smells coming from it - unplug it

immediately and contact an authorized dealer or service.

zThis may cause an electric shock or fire.

Be careful not to let water drip into the monitor or expose the

monitor to moisture.

zThis may cause malfunction, an electric shock or a fire.

zEspecially avoid operating the monitor near water or outdoors

where it could be exposed to snow or rain.

If the monitor is dropped or the casing is damaged, turn the

monitor off and unplug the power cord.

zThe monitor may malfunction, causing an electric shock or a fire.

zThen contact the Service Center.

Keep the power off when there is thunder and lightening outside,

or let the monitor remain unused for an extended period of time.

zThe monitor may malfunction, causing an electric shock or a fire.

Do not try to move the monitor by pulling on the wire or the signal

cable.

zThis may cause a breakdown, electric shock or a fire due to

damage to the cable.

Do not move the monitor right or left by pulling only the wire or the

signal cable.

zThis may cause a breakdown, electric shock or a fire due to

damage to the cable.

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Do not insert metal objects such as utensils, wire or drill bits, or

things that catch fire easily, such as pieces of paper or matches,

into the vents or the headphone or A/V ports on the monitor.

zThis may cause malfunction, an electric shock or a fire.

zAlways contact the Service Center if foreign substances/objects

enter into the monitor.

If you view a fixed screen for an extended period of time, residual

image or blurriness may appear.

zChange the mode to energy save or set a screensaver to moving

picture when you need to be away from the monitor for an

extended period of time.

Be careful when adjusting the stand angle.

zApplying too much force may cause the monitor topple over or fall,

resulting in injury.

zYour hand or finger(s) may get caught between the monitor and

the stand, causing injury.

Adjust the resolution and frequency to the levels appropriate for

the model.

zInappropriate levels of resolution and frequency may damage your

eyesight.

15 inch - 1024 x 768

17,19 inch - 1280 x 1024

Be careful that adapter should not be in contact with water and

therefore not be wet.

zThis may cause malfunction, an electric shock or a fire.

zDo not use adaptor by the waterside or outside particularly when it

rains or snows.

zBe careful that adaptor should not be wet while cleaning floor with

water.

Keep all power adaptors apart.

zPossible fire hazard.

Remove and discard vinyl bag from power adaptor before use.

zPossible fire hazard.

Always keep power adaptor in well-ventilated area.

Keep the volume at a proper level when you use the headphones.

zExcessively loud volume levels may damage hearing.

Keep a proper distance between your eyes and the monitor screen.

zSitting too close to the monitor on a continuous basis may damage

eyesight.

To ease eye strain, take at least a five-minute break after every

hour of using the monitor.

Do not use the monitor where it can be exposed to strong

vibrations.

zExposure to strong vibrations can be a fire hazard and shorten the

life of the monitor.

When moving the monitor, turn the power switch off and unplug

the power cord.

Make sure that all cables, including the antenna cable and cables

connecting to other devices, are disconnected before moving the

monitor.

zFailure to disconnect a cable may damage it and lead to a fire or

an electric shock.

Keep power adaptor away from any other heat source.

Unpacking

Front

Rear

Monitor and Stand

Please make sure the following items are included

with your monitor. If any items are missing,

contact your dealer.

Power Cord

Signal Cable

Quick Setup Guide

Warranty Card

(Not available in all locations)

SyncMaster 153V/173V/152V/172V/193V/192V

User's Guide and Monitor Driver,

Natural Color software
