Samsung SyncMaster 225MW Manuel utilisateur

LCD MONITOR

quick start guide

225MW

Model

Please make sure the following items are included with your monitor.

If any items are missing, contact your dealer.

Contact a local deale

to bu

tional items.

Unpacking

Without Stand With Stand

Manual

Quick Setup Guide Warranty Card

(

Not available in all locations

)

User's Guide, Monitor Driver,

Natural Color software

Cable

SyncMaster 225MW

D-Sub Cable

udio Cable Power Cord

Othe

Remote Control Batteries

(

AAA X 2

)

Cleanin

Cloth

Sold se

aratel

TV Antenna Cable

(

Coaxial Cable

)

RCA Cable (Video-Yellow,

Audio-Red and White

)

Component(PR, PB, Y) Cable

S-

IDEO Cable Ear

hones/Head

hones SCART Cable

DVI Cable DVI to HDMI cable HDMI Cable

RCA to stereo

(

for PC

)

cable

Front

1. AUTO

2. PIP

4. - +

5. MENU

7. Remote Control

Sensor

8. [ ] Power button

9. Power indicator

10. Speaker

1. AUTO

(Available in PC mode only)

When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the

animated screen on the center.

Press to self-adjust to the incoming Analog signal. The values of fine,coarse and position

are adjusted automatically.

2. PIP - Available in PC/DVI Mode

In PC mode, turns on Video or TV screens in PIP mode.

Moves from one menu item to another vertically or adjusts selected menu values.

In TV mode, selects TV channels.

4. - +

Moves from one menu item to another horizontally or adjusts selected menu values.

Adjusts the audio volume.

5. MENU

Use this button for open the on-screen menu and exits from the menu screen or closes

screen adjustment menu.

Activates a highlighted menu item.

Press the button to change the input signal source.

Changing the source is allowed only in external devices that are connected to the monitor

at the time.

To switch Screen modes:

[PC] →[DVI] →[TV] →[Ext.] →[AV] →[S-Video] →[Component] →[HDMI]

>>Click here to see an animation clip

7. Remote Control Sensor

Aim the remote control towards this spot on the monitor.

8. [ ] Power button

Turns the monitor On/Off.

9. Power indicator

This will enable you to see the overall power status of the system. For more information,

see the PowerSaver section.

10. Speaker

You can hear sound by connecting the soundcard of your PC to the monitor.

See PowerSaver described in the manual for further information regarding power saving functions.

For energy conservation, turn your monitor OFF when it is not needed or when leaving it unattended

for long periods.

Rear

(The configuration at the back of the monitor may vary from product to product.)

1. POWER

zPower terminal

Connect the power cord for your monitor to the

POWER on the back of the monitor.

This product may be used with 100 ~ 240VAC(+/-

10%).

2. DVI/PC IN / HDMI/PC/DVI-D AUDIO IN

1. PC

: Connect the signal cable to the PC port on the

back of your monitor.

2. DVI-D

: Connect the DVI cable to the DVI-D port on the

back of your monitor.

3. HDMI/PC/DVI-D AUDIO IN

: Connect the HDMI/PC/DVI-D AUDIO IN terminal at

the back of your monitor to your computer’s sound

card.

3. COMPONENT IN

1. R - AUDIO - L

: Connect the port of the DVD, VCR (DVD / DTV

Set-Top Box) to the R-AUDIO-L port of the monitor.

2. PR, PB,Y

: Connect the VIDEO OUT port of the DVD / DTV

Set-Top Box to the PR, PB,Y input ports using a

component video cable (PR, PB,Y).

4. ANT IN

zConnect the CATV cable or TV antenna cable to the

"ANT IN" port on the rear side of the monitor. Make

sure to use a TV antenna cable (sold separately) as

the antenna cable.

5. HDMI IN

zConnect your headphones to the Headphone

connection terminal.

zConnect the EXT (RGB) port of the monitor to the

DVD Player using a SCART jack.

As for EXT(RGB) port of the monitor, it makes TV or

Video signal input and output.

zConnect the HDMI IN terminal at the back of your

monitor to the HDMI terminal of your digital output

device using a HDMI cable.

6. EXT(RGB)

zThe Kensington lock is a device used to physically

fix the system when using it in a public place.

(The locking device has to be purchased

separately.)

For using a locking device, contact where you

purchase it.

9. S-VIDEO / VIDEO / R - AUDIO - L

See Connecting the monitor for further information regarding cable connections.

1. S-VIDEO / VIDEO

: Input devices such as DVD, VCR or Camcorder

are connected to the VIDEO or S-VIDEO terminal of

the monitor using the Video or S-Video cable.

2. R - AUDIO - L

: Connect the port of the DVD, VCR (DVD / DTV

Set-Top Box) to the R-AUDIO-L port of the monitor.

Remote Control

The performance of the remote control may be affected by a TV or other electronic device operated near

the monitor, causin

malfunction due to interference with fre

uenc

1. POWER

2. Number button

3. -/--

5. MENU

6. MUTE

7. Up-Down Left-Right buttons

8. ENTER

9. INFO

10. SOURCE

11. PRE-CH

12. P

13. EXIT

14. P.MODE, M/B (MagicBright™)

15. S.MODE

16. STILL

17. P.SIZE

18. SOURCE

19. TTX/MIX

20. DUAL I-II

21. SLEEP

22. PIP

23. AUTO

1. POWER

Turns the monitor On/Off.

2. Number button

Selects TV channels in the TV mode.

Used to change channels when PIP is selected and the PIP Source is set to TV.

3. -

(One/Two-Digit channel selection)

Use to select a channel numbered ten or over.

Press this button, and the "--" symbol is displayed.

Enter the two-digit channel number.

djusts the audio volume.

5. MENU

Opens the on-screen menu and exits from the menu or closes the adjustment menu.

6. MUTE

Press to mute the sound temporarily.

Displayed on the bottom left of the screen.

Press the MUTE button again to cancel the Mute function.

lternatively press the buttons to cancel the Mute function.

7. U

-Down Left-Ri

ht buttons

Moves from one menu item to another horizontally, vertically or adjusts selected menu

values.

8. ENTER

ctivates a highlighted menu item.

9. INFO

Current picture information is displayed on the upper left corner of the screen.

10. SOURCE

Press the 'SOURCE' button to change the input signal source.

Changing the source is only allowed for external devices that are connected to the monitor

at the time.

11. PRE-CH

This button is used to return to the immediately previous channel.

12. P

In TV mode, selects TV channels.

13. EXIT

Exits from the menu screen.

14. P.MODE, M/B

(

icBri

ht™

)

Press to select a pre-defined Picture Mode of the monitor or to change the picture

atmosphere as required.

When you press this button, current mode is displayed on the lower center of the screen.

TV / AV / Ext. / S-Video / Component / HDMI : P.MODE

The monitor has four automatic picture settings that are preset at the factory.

Then press the button again to circle through available preconfigured modes.

( Dynamic →Standard →Movie →Custom )

PC / DVI Mode : M/B ( MagicBright™ )

MagicBright™ is a new feature providing the optimum viewing environment depending on

the contents of the image you are watching.

Then press the button again to circle through available preconfigured modes.

( Entertain→Internet →Text →Custom )

15. S.MODE

(

Sound Mode

)

When you press this button, current mode is displayed on the lower center of the screen.

The monitor has a built-in high fidelity stereo amplifier.

Then press the button again to circle through available preconfigured modes.

( Standard →Music →Movie →Speech →Custom )

16. STILL - O

erates onl

for the CVBS, S-

ideo and RF Si

20. DUAL I-II

STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM MONO/NICAM STEREO can be

operated depending on broadcasting type by using DUAL button on the remote control while

watching TV.

nal SOURCEs.

Press the button once to freeze the screen. Press it again to unfreeze.

17. P.SIZE

Press to change the screen size.

- PC/ DVI mode : Wide / 4:3

- TV / Ext. / AV / S-Video mode : Auto Wide / Wide / 16:9 / Zoom1 / Zoom2 / 4:3

- Component / HDMI mode : Wide / 16:9 / Zoom1 / Zoom2 / 4:3

18. SOURCE - Ad ustable when the PIP function is ON.

Selects the Video SOURCE.

19. TTX/MIX

TV channels provide written information services via teletext.

zTeletext buttons

For more information > TTX / MIX

21. SLEEP

Turns the monitor off after a pre-determined period of time.

22. PIP - Available in PC/DVI Mode

Push the PIP button to turn PIP screen On/Off.

23. AUTO - Available In PC mode Onl

djusts the screen display automatically.
