Samsung NC241 Manuel utilisateur

User manual

NC191

NC241

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00099C-02

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

7 Symbols for safety precautions

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Electricity and Safety

11 Installation and Safety

13 Operation and Safety

16 Correct posture to use the product

PREPARATIONS 17 Checking the Contents

17 Removing the Packaging

18 Checking the Components

20 Parts

20 Frontal Buttons

22 Reverse Side

24 Installation

24 Attaching the cradle

25 Adjusting the Product Tilt and Height

25 Rotating the Monitor

26 Installing a Wall-mount Kit or Desktop Stand

27 Anti-theft Lock

USING "PCOIP" 28 What is a "PC over IP"?

Table Of Contents

Table Of Contents 3

29 Connection to Use "PCoIP"

29 LAN Connection

29 Connecting USB Devices

30 Connecting a Microphone

30 Connecting to Headphones or Speakers

30 Connecting a SERIAL cable

31 Connecting to a Secondary Monitor

31 Connecting the Power

32 Connect to the host PC using a LAN

cable

33 Installing a USB-to-Serial Driver

35 "PCoIP"

35 On Screen Display (OSD)

35 Connect Screen

36 OSD Options Menu

36 Configuration Window

46 Diagnostics Window

50 Information Window

52 User Settings Window

60 Password Window

62 Wake On LAN

63 Wake on USB

64 OSD Logo Upload

CONNECTING AND USING

A SOURCE DEVICE

65 Before Connecting

65 Pre-connection Checkpoints

66 Connecting and Using a PC

66 Connecting to a PC

67 "Windows Driver" Installation

68 Setting Optimum Resolution

69 Changing the Resolution Using a PC

SCREEN SETUP 71 Brightness

71 Configuring Brightness

Table Of Contents

Table Of Contents 4

72 Contrast

72 Configuring Contrast

73 Sharpness

73 Configuring Sharpness

74 SAMSUNG MAGIC Bright

74 Configuring SAMSUNG MAGIC Bright

75 Coarse

75 Adjusting Coarse

76 Fine

76 Adjusting Fine

CONFIGURING TINT 77 SAMSUNG MAGIC Color

77 Configuring SAMSUNG MAGIC Color

78 Red

78 Configuring Red

79 Green

79 Configuring Green

80 Blue

80 Configuring Blue

81 Color Tone

81 Configuring the Color Tone Settings

82 Gamma

82 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

83 H-Position & V-Position

83 Configuring H-Position & V-Position

84 Menu H-Position & Menu V-Position

84 Configuring Menu H-Position & Menu V-

Position

Table Of Contents

Table Of Contents 5

SETUP AND RESET 85 Reset

85 Initializing Settings (Reset)

86 Language

86 Changing the Language

87 Display Time

87 Configuring Display Time

88 Menu Transparency

88 Changing Menu Transparency

89 Power Key

89 Enabling Power Key

INFORMATION MENU AND

OTHERS

90 INFORMATION

90 Displaying INFORMATION

90 Configuring Volume in the Initial Screen

INSTALLING THE

SOFTWARE

91 Natural Color

91 What is Natural Color?

92 MultiScreen

92 Installing the Software

93 Removing the Software

TROUBLESHOOTING

GUIDE

94 Requirements Before Contacting

Samsung Customer Service Center

94 Testing the Product

94 Checking the Resolution and Frequency

94 Check the following.

96 Q & A

SPECIFICATIONS 98 General

100 PowerSaver

101 Standard Signal Mode Table

Table Of Contents

Table Of Contents 6

APPENDIX 104 Contact SAMSUNG WORLD WIDE

110 Responsibility for the Pay Service (Cost

to Customers)

110 Not a product defect

110 A Product damage caused by customer's fault

110 Others

111 Correct Disposal

111 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

111 Correct disposal of batteries in this product

112 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

Symbols for safety precautions

zAn administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

zThe amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

zDo not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

zDo not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

zEnsure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 104) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

10 cm

10 cm 10 cm

10 cm

Before Using the Product

Safety Precautions

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

zAn electric shock or fire may result.

Do not plug many products into the same power socket.

zOtherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

zOtherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

zAn unstable connection may cause a fire.

Ensure you connect the power plug to a grounded power socket. (type 1

insulated devices only).

zAn electric shock or injury may result.

Do not bend or pull the power cord with force. Do not weigh the power cord

down with a heavy object.

zA damaged power cord may cause an electric shock or fire.

Do not place the power cord or product near heat sources.

zAn electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

zOtherwise, a fire may result.
