Samsung SyncMaster 550DX Manuel utilisateur

SyncMaster 550DX

LCD Display

User Manual

The color and the appearance may differ depending on the

product, and the specifications are subject to change

without prior notice to improve the performance.

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property dam-

age.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily

harm or damage to the equipment.

Note

Prohibited Important to read and under-

stand at all times

Do not disassemble Disconnect the plug from the

outlet

Do not touch Ground to prevent an electric

shock

Power

When not used for extended period of time, set your computer to DPM.

If using a screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases

(or countries).

Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or

loose power outlet.

• Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or

plugging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power out-

let.

•Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet

firmly and correctly.

• Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place

any heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

•Otherwise, this may result in damage to the product due to

electric shock.

To disconnect the apparatus from the mains, the plug must be

pulled out from the mains socket, therefore the mains plug shall

be readily operable.

• Otherwise, this may cause electric shock or fire.

Use only the power cord provided by our company. Do not use

the provided power cord of another product.

• Otherwise, this may result in fire or electric shock.

Connect the power plug to a wall outlet that can be easily

reached.

•When a problem occurs with the product, you must unplug the

power plug to cut the power off completely. You cannot cut the

power off completely using only the power button on the prod-

uct.

Installation

Be sure to contact an authorized Service Center when installing your

monitor in a location with heavy dust, high or low temperatures, high hu-

midity, and exposed to chemical substances and where it operates for 24

hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your monitor.

Ensure that at least two persons lift and move the product.

•Otherwise, it may be dropped and cause personal injury, and/

or damage the product.

When installing the product in a cabinet or rack, make sure that

the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

Safety Instructions

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIG-

ARETTES AND ANY HEATING APPLIANCES NEAR THE

PRODUCT.

• Otherwise, this may result in fire.

Keep heating appliances as far away from the power cord or the

product as possible.

• Otherwise, this may result in electric shock or fire.

Do not install it in a badly ventilated location such as a bookcase

or closet.

•Otherwise, this may result in fire due to an increase in the in-

ternal temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall

mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that

there is a clearance of more than 4 inches (10 cm) from the wall.

•Otherwise, it may result in fire due to an increase in the internal

temperature.

Ensure that the packaging vinyl is kept away from children.

•Otherwise, it may result in serious harm (suffocation) if children

play with it.

If the height of your monitor is adjustable, do not place any ob-

ject or part of your body on the stand when lowering it.

•This may cause damage to the product or the person carrying

it.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen,

wipe with a slightly moistened, soft cloth.

Safety Instructions

Edible oil, such as soybean oil, can damage or deform the prod-

uct. Do not install the product in a kitchen or near a kitchen counter.

When cleaning the power plug pins or dusting the power outlet,

clean it with a dry cloth.

• Otherwise, it may result in fire.

When cleaning the product, make sure to disconnect the power

cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and

clean it with a soft, dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner,

mosquito repellant, lubricant, or cleaner.) These may change

the appearance of the product surface and peel off the indica-

tion labels on the product.

Since the product housing is easily scratched, make sure to use

the specified cloth only.

When cleaning the product, do not spray water directly onto the

main body of the product.

• Ensure that water does not enter the product and that it is not

wet.

•Otherwise, this may result in electric shock, fire or a malfunc-

tion.

Others

The product is a high voltage product. Do not disassemble, re-

pair or modify the product yourself.

•Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming

from the product, disconnect the power plug immediately and con-

tact a Service Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust,

smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power

off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not spray cleaner directly onto the surface of the product.

•Otherwise, this may result in the discoloration and distortion of

the structure and the screen surface may peel off.

If thunder or lightning is occurring, do not touch the power cord

or antenna cable.

• Otherwise, this may result in electric shock or fire.

Do not try to move the monitor by pulling only the wire or the

signal cable.

•Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and

left while only holding the power cord or signal cables.

•Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table

or curtain.

•Otherwise, it may result in fire due to an increase in the internal

temperature.

Do not place any containers containing water, vases, flower-

pots, medicines as well as any metal on the product.

•If water or a foreign material enters the product, disconnect the

power cord and contact a Service Center.

•This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material

near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and

steel, or flammable objects, such as matches or paper, inside the

product (through the ventilating openings, input and output termi-

nals, etc).

•If water or foreign material enters the product, disconnect the

power cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain

may occur.

•If you are not using your product for a long period of time, put

it into sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

When using headphones or earphones, do not turn the volume

too high.

• Having the sound too loud may damage your hearing.

Safety Instructions

To avoid eyestrain, do not sit too close to the product.

Take a rest for at least five (5) minutes after using the monitor

for one (1) hour.

This reduces eye fatigue.

Do not install it in an unstable location such as an unstable rack

or uneven surface or a location exposed to vibrations.

•Otherwise, it may fall and cause personal injury and/or damage

the product.

•If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect

the power plug, antenna cable, and all the cables connected to the

product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up

onto the product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect

the power cord from the power outlet.

•Otherwise, this may result in overheating or fire due to dust,

and may result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as

cookies etc. that may attract the attention of children and to the

product.

•Your children may hang onto the product causing it to fall and

this may result in personal injury or death.

Be careful that children do not place the battery in their mouths

when removed from the remote control. Place the battery in a lo-

cation that children or infants cannot reach.

•If children have had the battery in their mouths, consult your

doctor immediately.

When replacing the battery, insert it with the right polarity (+, -).

•Otherwise, the battery may become damaged or it may cause

fire, personal injury or damage due to leakage of the internal

liquid.

Use only the specified standardized batteries, and do not use a

new battery and a used battery at the same time.

•Otherwise, the batteries may be damaged or cause fire, per-

sonal injury or damage due to a leakage of the internal liquid.

Safety Instructions

The batteries (and rechargeable batteries) are not ordinary re-

fuse and must be returned for recycling purposes. The customer

is responsible for returning the used or rechargeable batteries for

recycling.

•The customer can return used or rechargeable batteries to a

nearby public recycling center or to a store selling the same

type of the battery or rechargeable battery.

Do not place the product in a location exposed to direct sunlight

or near any heat such as a fire or heater.

•This may reduce the lifetime of the product, and may result in

fire.

Do not drop any objects onto the product or cause any impact

to the product.

• Otherwise, this may result in electric shock or fire.

Do not use a humidifier near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power

plug; ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display

panel becomes hot. Do not touch it.

Keep the small accessories in a location out of the reach of

children.

Be careful when adjusting the angle of the product or the height

of the stand.

•This may result in personal injury as your hand or fingers may

become caught.

•Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children

to reach.

• Otherwise, it may fall and result in personal injury.

•Since the front part of the product is heavy, install the product

on a level and stable surface.

Safety Instructions

Do not put any heavy objects on the product.

•This may result in personal injury and/or damage to the prod-

uct.

Safety Instructions

Introduction

Package Contents

Checking the Contents of the Package

Remove the lock from the package box, as shown in the figure above.

Lift up the package box by

holding the grooves on

both sides of the package

box.

Check the contents of the

package.

Remove the Styrofoam

and vinyl cover.

Note

•After unpacking the package, make sure to check the contents of the package.

•Store the packaging box in case you need to move the Product later.

•If any items are missing, contact your dealer.

•Contact a local dealer to purchase optional items.

Unpacking

LCD Display

Autres manuels pour SyncMaster 550DX

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster S20A350B Manuel utilisateur

Samsung

Samsung T200HD - SyncMaster - 20" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster S22B300B Manuel utilisateur

Samsung

Samsung SyncMaster 153V Manuel utilisateur

Samsung

Samsung QM49F Manuel utilisateur

Samsung

Samsung SyncMaster Magic P2770H Guide de l'utilisateur

Samsung

Samsung 400UX - SyncMaster - 40" LCD Flat Panel... Manuel utilisateur

Samsung

Samsung SyncMaster S22A450BW Manuel utilisateur

Samsung

Samsung DBJ Series Manuel utilisateur

Samsung

Samsung SyncMaster 798MBplus Manuel utilisateur

Samsung

Samsung SyncMaster MD230X3 Manuel utilisateur

Samsung

Samsung SyncMaster 710NT Manuel utilisateur

Samsung

Samsung SyncMaster 400MX-2 Manuel utilisateur

Samsung

Samsung SyncMaster 210T Manuel utilisateur

Samsung

Samsung SyncMaster BN59-00786C-01 Manuel utilisateur

Samsung

Samsung CN17A series Manuel utilisateur

Samsung

Samsung 730MW - SyncMaster - 17" LCD Monitor Manuel utilisateur

Samsung

Samsung 320MX - SyncMaster - 32" LCD Flat Panel... Manuel utilisateur

Samsung

Samsung SyncMaster 930ND Manuel utilisateur

Samsung

Samsung S27B971D Manuel utilisateur

Samsung

Samsung SyncMaster 711MP Manuel utilisateur

Samsung

Samsung 730B - SyncMaster - 17" LCD Monitor Manuel utilisateur

Samsung

Samsung S27AG50 Series Manuel utilisateur

Samsung

Samsung SyncMaster 400CXN Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
