Samsung ED65E Manuel utilisateur

User Manual

The color and the appearance may differ depending on the product, and the

specifications are subject to change without prior notice to improve the performance.

Recommended hours of use per day for the EDE, EME, DCE models is less than 16 hours.

If the product is used for longer than 16 hours a day, the warranty may be void.

ED65E ED75E

EM65E EM75E

DC32E DC40E DC48E DC55E

DC32E-M DC40E-M DC48E-M DC55E-M

DC40E-H DC48E-H

Table of contents

Before Using the Product

Safety Precautions 7

Symbols 7

Cleaning 7

Storage 8

Electricity and Safety 8

Installation 9

Operation 11

Preparations

Checking the Components 15

Components 15

Parts 16

Control Panel 16

Reverse Side 18

Reverse Side 19

Anti-theft Lock 20

Remote Control 21

Before Installing the Product

(Installation Guide) 23

Switching between portrait and landscape 23

Ventilation 23

Installing the Wall Mount 24

Preparing before installing Wall-Mount 24

Installing the Wall Mount Kit 24

Wall Mount Kit Specifications (VESA) 25

Remote Control (RS232C) 26

Cable Connection 26

Connection 29

Control Codes 30

Connecting and Using a Source

Device

Before Connecting 39

Pre-connection Checkpoints 39

Connecting to a PC 39

Connection using the D-SUB cable

(Analog type) 39

Connection using a DVI cable (Digital type) 40

Connection Using an HDMI-DVI Cable 40

Connection Using an HDMI Cable 41

Connecting to a Video Device 42

Connection Using the AV Cable 42

Connection Using the component Cable 42

Connection Using an HDMI-DVI Cable 43

Connection Using an HDMI Cable 44

Connecting to an Audio System 44

Connecting the Antenna 45

Connecting the LAN Cable 45

Connecting the HDBase-T 46

Changing the Input source 47

Source 47

Using MDC

MDC Program Installation/Uninstallation 48

Installation 48

Uninstallation 48

Connecting to MDC 49

Using MDC via RS-232C

(serial data communications standards) 49

Using MDC via Ethernet 50

Screen Adjustment

Picture Mode 51

If the input source is PC, DVI, HDMI(PC) 51

If the input source is TV, AV, Component,

HDMI(AV) 51

Backlight / Contrast / Brightness / Sharpness /

Color / Tint (G/R) 52

Gamma 52

Calibrated Value 53

Picture Size 54

Position 55

Zoom/Position 55

Resolution Select 56

Auto Adjustment 56

PC Screen Adjustment 57

Table of contents

PIP 58

Advanced Settings 59

Dynamic Contrast 60

Black Tone 60

Flesh Tone 60

RGB Only Mode 60

Color Space 60

White Balance 60

Motion Lighting 60

Picture Options 61

Color Tone 62

Color Temp. 62

Digital Clean View 62

MPEG Noise Filter 62

HDMI Black Level 63

Film Mode 63

Auto Motion Plus 63

Dynamic Backlight 63

Picture Off 64

Reset Picture 64

Sound Adjustment

Sound Mode 65

Sound Effect 66

Speaker Settings 67

Reset Sound 67

Broadcasting

Auto Program 68

Antenna 69

Channel List 70

Mode 70

Guide 71

Schedule Manager 71

Edit Channel 72

Edit Favorites 74

Channel Settings 77

Fine Tune 77

Clear Scrambled Channel 77

Audio Options 78

Preferred Language 78

Multi-Track Sound 78

Visual Impaired 78

Program Rating Lock 79

Caption 81

Network

Network Status 83

Network Settings 83

Network type 83

Network Settings (Wired) 84

Network Setting (Wireless) 86

WPS(PBC) 88

Wi-Fi Direct 89

AllShare Settings 89

Server Network Settings 90

Connect to Server 90

Server Access 90

FTP Mode 90

Device Name 90

Applications

Source List 91

Refresh 91

Edit Name 91

Information 91

MagicInfo Lite 92

Playing content from the internal memory or

USB 92

Network Channel 93

Table of contents

System

Setup 95

Menu Language 96

Multi Control 96

Configuring settings for Multi Control 96

Time 97

Clock 97

Sleep Timer 98

On Timer 98

Off Timer 99

Holiday Management 99

Eco Solution 100

Energy Saving 100

Eco Sensor 100

No Signal Power Off 100

Auto Power Off 100

Auto Protection Time 101

Screen Burn Protection 102

Pixel Shift 102

Timer 103

Immediate Display 104

Side Gray 104

Ticker 105

Video Wall 106

Format 106

Horizontal 106

Vertical 107

Screen Position 107

Source AutoSwitch Settings 108

Source AutoSwitch 108

Primary Source Recovery 108

Primary Source 108

Secondary Source 108

Change PIN 109

General 110

Max. Power Saving 110

Game Mode 110

Auto Power On 110

Safety Lock 110

Button Lock 111

Standby Control 111

HDBT Standby 111

Network Standby 111

Lamp Schedule 112

OSD Display 112

Power On Adjustment 112

Temperature Control 112

Anynet+ (HDMI-CEC) 113

Auto Turn Off 114

Troubleshooting for Anynet+ 115

Clone Product 117

Reset System 117

Reset All 118

DivX®Video On Demand 118

PC Module Power 118

Synced Power-On 118

Synced Power-Off 118

Support

Software Update 119

Update now 119

Contact Samsung 119

Playing photos, videos and music

(Media Play)

Read the following before using media play

with a USB device 120

Using a USB device 122

Menu items in the media content list page 123

Available buttons and features during photo

playback 124

Available buttons and features during video

playback 125

Available buttons and features during music

playback 126

Supported Subtitle and Media play file

formats 127

Table of contents

Subtitle 127

Compatible image file format 127

Supported music file formats 128

Supported Video Formats 128

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Center 131

Testing the Product 131

Checking the Resolution and Frequency 131

Check the followings. 132

Q & A 139

Specifications

General 140

Preset Timing Modes 142

Appendix

Responsibility for the Pay Service

(Cost to Customers) 144

Not a product defect 144

A Product damage caused by customer's fault 144

Others 144

Optimum Picture Quality and Afterimage

Burn-in Prevention 145

Optimum Picture Quality 145

Prevention of Afterimage Burn-in 145

License 147

Terminology 148

Before Using the Product

Chapter 01

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

•Do not use detergents that contain alcohol, solvent or

surface-active agents.

•Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-

colored stains on the product.

―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be

charged).

Electricity and Safety

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•An electric shock or fire may result.

Do not use multiple products with a single power socket.

•Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock

may result.

Insert the power plug all the way in so it is not loose.

•An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

•An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the

power cord under a heavy object.

•Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with

a dry cloth.

•A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not

use the power cord with other products.

•A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•The power cord must be disconnected to cut off power to the product

when an issue occurs.

•Note that the product is not completely powered down by using only

the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

•An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF

THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•A fire may result.

Have a technician install the wall-mount hanger.

•Installation by an unqualified person can result in an injury.

•Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or

closet.

•An increased internal temperature may cause a fire.

Install the product at least 10cm away from the wall to allow ventilation.

•An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•Children may suffocate.

Bend and keep part of the outdoor TV antenna cable hanging downwards

(the part inside the room) to prevent rainwater from entering the product.

•If rainwater enters the product, a fire or electric shock can occur.

When using an outdoor antenna, be sure to install the antenna away from

nearby power lines to prevent the antenna from collapsing onto them in

strong winds.

•A collapsed antenna can cause an electric shock or injury.

Do not install the product on an unstable or vibrating surface (insecure shelf,

sloped surface, etc.)

•The product may fall and become damaged and/or cause an injury.

•Using the product in an area with excess vibration may damage the

product or cause a fire.

Do not install the product in a vehicle or a place exposed to dust, moisture

(water drips, etc.), oil, or smoke.

•A fire or electric shock may result.

Do not expose the product to direct sunlight, heat, or a hot object such as a

stove.

•The product lifespan may be reduced or a fire may result.

Do not install the product within the reach of young children.

•The product may fall and injure children.

•As the front is heavy, install the product on a flat and stable surface.

Edible oil, such as soybean oil, can damage or deform the product. Do not

install the product in a kitchen or near a kitchen counter.

Autres manuels pour ED65E

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster 460UTn-2 Manuel utilisateur

Samsung

Samsung SyncMaster 2343BW Manuel utilisateur

Samsung

Samsung CKE5507L Manuel utilisateur

Samsung

Samsung 203B - SyncMaster - 20" LCD Monitor Guide de démarrage rapide

Samsung

Samsung S27B80 T Series Manuel utilisateur

Samsung

Samsung 720N - SyncMaster - 17" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 750s Manuel utilisateur

Samsung

Samsung SyncMaster 1100 DF Manuel utilisateur

Samsung

Samsung SyncMaster S23A750D Manuel utilisateur

Samsung

Samsung T190 - SyncMaster - 19" LCD Monitor Guide de l'utilisateur

Samsung

Samsung PPM63H3 Manuel utilisateur

Samsung

Samsung SyncMaster 151Q Guide de démarrage rapide

Samsung

Samsung SyncMaster 400TSn-2 Manuel utilisateur

Samsung

Samsung RS21A Series Manuel utilisateur

Samsung

Samsung PM55H Manuel utilisateur

Samsung

Samsung 320MP-2 - SyncMaster - 32" LCD Flat Panel... Guide de l'utilisateur

Samsung

Samsung DC32E Manuel utilisateur

Samsung

Samsung SyncMaster 2253LN Manuel utilisateur

Samsung

Samsung OMD-W Series Manuel utilisateur

Samsung

Samsung 2243WM - SyncMaster - 22" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 940MG Manuel utilisateur

Samsung

Samsung SyncMaster XL20 Manuel utilisateur

Samsung

Samsung LS32A700NWNXZA Manuel utilisateur

Samsung

Samsung 931C - SyncMaster - 19" LCD Monitor Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
