SyncMaster NC190,NC240

LCD MONITOR

quick start guide

1 Installing the Product

1-1 Package Contents

• Unpack the product and check if all of the following contents have been included.

• Store the packaging box in case you need to move the Product at a later stage.

Monitor

1-2 Installing the Stand

Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.

CONTENTS

Installation Manual Product Warranty User Manual Power Cord

OPTIONAL PARTS

Keyboard (USB) Mouse (USB) D-Sub Cable

Place a soft cloth over the table to protect the product and place the product onto the

cloth so that the front of the product is facing downwards.

Do not remove the stopper pin before installing the base.

Hold the main body of the product with your hand as shown by the figure.

Insert the stand base into the stand connection part in the direction shown in the figure.

Turn the connecting screw at the bottom of the stand fully so that it is completely fixed.

Installing the Product 1-3

Disassembly is in the reverse order of assembly.

1-3 Installing a Wall Mount

Before installation, disassemble the product according to the following steps.

After the installation of the base, stand the monitor up as shown in the figure. Now you

can remove the stopper pin to adjust the stand.

- Caution

Avoid lifting the product holding only the stand.

1-3 Installing the Product

This product provides a wall mount of 100 mm x 100 mm(200 mm x 100 mm) that complies with the VESA specifications.

1. Turn the product off and unplug the power cord from the wall outlet.

2. Place a soft cloth or cushion on a flat surface to protect the panel and place the product face down.

3. Separate the stand.

4. Align the groove of the Monitor's wall mount base with the groove in the wall mount ki and firmly fix the wall mount kit by

fastening the screws.

Lift up the monitor stand to the maximum angle with your left hand, and remove the back

decoration cover with your right hand, as shown in the figure.

Remove the two screws(A).

Remove the stand arm in the direction shown in the figure.

100 mm x 100 mm 200 mm x 100 mm

A. Wall Mount Base

B. Wall Mount Kit (Optional)

Installing the Product 1-4

•If you use a screw that is longer than the standard specifications, the inside of the product may be damaged.

•For wall mounts that are not compatible with the standard VESA specifications, the length of the screw may differ depending

on the corresponding specifications.

•Do not use screws that are incompatible with the standard VESA specifications and do not assemble them using excessive

force.

This may result in damage to the product or injury due to the product falling. Samsung shall not be held liable for any damage

or injury.

•Samsung shall not be held liable for any damage to the product or injury caused by using a stand that is not compatible with

the specified specifications or due to an installation not performed by an authorized installation engineer.

•When installing the product using a wall mount, purchase a wall mount that provides at least 4 inches (10 cm) of space from

the wall.

•Samsung shall not be held liable for any problems caused by using a stand that is not compatible with the specified

specifications.

•Use a wall mount according to specifications of your country.

1-4 Connecting to your Network

The connecting part may differ depending on the product model.

Connect between the [LAN] port on the product and your network using a LAN cable.

The two [LAN] ports are designed to work as an Internet HUB. One port can be used for input and the other port for output

to connect the product to an external Internet device. Both ports can be used for either input or output.

1-5 Installing the Product

1-5 Connecting Power

Connect one end of the power cord to the POWER port of the product and connect the other end of the power cord to a 220V or

110V wall outlet.

(The input voltage is switched automatically.)

Installing the Product 1-6

1-6 Connecting to another Monitor

Please select the right connection method for your monitor.

• When using the [RGB OUT] port

• Connect between the [RGB OUT] port on the product and the D-Sub port on your monitor using a D-Sub cable.

• When using the [DVI OUT] port

• Connect between the [DVI OUT] port on the product and the DVI port on your monitor using a DVI cable.

Connect to the [DVI OUT], [RGB OUT]port to display the same picture on another monitor such as the projector.

(For presentation purposes)

1-7 Installing the Product

1-7 Connecting with a PC

Connect the [RGB IN] port of the product to the [D-Sub] port of your PC with a D-Sub cable.

Use the [RGB IN] port to directly connect the monitor to a PC.

Installing the Product 1-8

1-8 Connecting a Stereo Cable

Connect the [AUDIO IN] port on the rear side of the monitor to the sound card of the PC.
