SAFETYCONCERNS

ThepurposeoftheSafetyConcernssectionistoensurethesafetyofusersand

preventpropertydamage.Pleasereadthisdocumentcarefullyforproperuse.

Conventions

Warning

Providesinformationorinstructionsthatyoushouldfollowinordertoavoid

personalinjuryorfatality.

Caution

Providesinformationorinstructionsthatyoushouldfollowinordertoavoida

servicefailureordamagetoyourset-topbox.

Note

Indicatesadditionalinformationforreference.

Checks

Providestheoperatorwithcheckpointsforstablesystemoperation.

Symbols

Caution

Indicationofageneralcaution

Restriction

Indicationforprohibitinganactionforaproduct

Instruction

Indicationforcommandingaspecicallyrequiredaction

SMT -H3272UserGuide_1 1

WARNING

Power

Insertthepowerplugrmly.Donotconnectmultipledevicesto

asingleoutletsimultaneously.

Donottouchthemainbody,power

cable,orpowerplugwithwet

hands.

Ifvideo/soundcablegenerates

heatafterconnection,pulloutthe

powerplugandcontactcustomer

serviceimmediately.

Installation/Maintenance

Donotinstallinhumidordusty

areas,andavoidinstallingnear

heatingdevices.

Donotcoverthetop.

Keepammablesubstancesor

spraysawayfromtheset-topbox.

Pulloutthepowerplugduring

thunderstormsorwhennotused

foraprolongedperiodoftime.

Donotplaceheavyobjectsonthis

product.

Pulloutthepowerplugatonceand

contactcustomerserviceifunusual

noise,smell,orsmokecomesout.

General

Checkifthecoaxialcable

iscorrectlygroundedbefore

connectingtotheset-topbox.

Asktheinstallationengineerto

checkiftheset-topboxtobe

connectediscorrectlygrounded.

Class1LEDProduct.Thisproductcomplieswith21CFR

Chapter1,subchapterJ

2 2

2_ⓒSAMSUNGElectronicsCo.,Ltd.

CAUTION

Power

ConnectyourTVafterpowering

offtheTVandtheset-topboxby

pullingoutthepowerplug.

Donotinsertthepowerplugbefore

connectingthepowercabletothe

product.

Thesocket-outletshallbeinstalled

neartheequipmentandshallbe

easilyaccessible

Beforeconnectingthepower

source,permanentprotectiveearth

connectiontothecabledistribution

shouldbemade

Installation/Maintenance

Installtheproductcorrectly

complyingwiththeinstructionsin

theuserguide.

DonotremovetheCableCARD™

fromtheset-topbox.

Donotspraywaterdirectlyon

theunitanddonotusechemical

solventssuchaswax,mosquito

spray,alcoholordetergent.

Donotplaceanymetalitemssuch

aspins,paperclipsorcoinsonthe

topoftheproduct.

Donotplacetheproducton

unstablesupport.

Riskofelectricshock,DoNOT

OPEN.

Donotdisassemble,repair,or

remodel.

Wipetheproductwithasoftand

dryclothwhencleaning.

Noconnectiontoanantenna.

SMT -H3272UserGuide_3 3

TABLEOFCONTENTS

SAFETY SAFETY

SAFETYCONCERNS CONCERNS

CONCERNS. .

.. .

.1 1

Conventions...............................................................1

Symbols.....................................................................1

Warning......................................................................2

Caution.......................................................................3

BEFORE BEFORE

BEFOREUSE USE

USE. .

.. .

.6 6

DigitalHDDVROCAPSTB..........................................6

PackageContents......................................................6

NamesandFunctions.................................................7

FrontPanel........................................................7

RearPanel........................................................8

DVRFeatures.............................................................9

CableCARD™.............................................................9

INST INST

INSTALLA ALLA

ALLATION TION

TION. .

.. .

.10 10

InstallationEnvironment..............................................10

PeripheralDeviceConnection.....................................11

ConnectiontoaTVHavingaCompositePort................12

ConnectiontoaTVHavingComponentPorts(Y ,Pb,Pr)...13

HDMICableConnection........................................14

DigitalAudioConnection............................15

VCRConnection..................................................16

HomeNetworkConnection(optionalservice)................17

E-SATAConnection(ExternalHDD)............................17

USBConnection.................................................18

4 4

4_ⓒSAMSUNGElectronicsCo.,Ltd.

TROUBLESHOOTING TROUBLESHOOTING

TROUBLESHOOTING. .

.. .

.19 19

ANNEX ANNEX

ANNEX. .

.. .

.20 20

Specication...............................................................20

CableSpecications...................................................22

OpenSourceAnnouncement......................................24

SMT -H3272UserGuide_5 5

BEFOREUSE

DigitalHDDVROCAPSTB

DigitalHDDVROCAPSTB(DigitalHigh-DenitionDigitalVideoRecorder

OpenCableApplicationPlatformSet-TopBox)provideshighqualityvideoandaudio

broadcasting,andinteractiveservicesincludingVideo-On-Demand.

DigitalHDDVROCAPSTB(SMT -H3272)providesthefollowingfunctions.

–AnMPEGdecodercapableofprocessingHD/SDstream

–SCTE55-1,55-2andDOCSISCableModemforOOBSignaling

–DigitalAVtransmission,suchasIEEE1394andHDMI

–ContentProtection

–CableCARDInterfaceforCAS

–OCAP™1.0applicationplatform

–Recording:Upto130hoursforSD(StandardDenition)stream,Upto30hours

forHD(HighDenition)stream.

–DVRFeatures

–MoCA(MultimediaoverCoaxAlliance)

PackageContents

Pleasemakesurethefollowingitemsarecontainedinyourproductpackagebox.

SMT -H3272

HDMICablePowerCableUserGuide

6 6

6_ⓒSAMSUNGElectronicsCo.,Ltd.

NamesandFunctions

NamesandfunctionsonthefrontandrearpaneloftheSTBaredescribedasfollows:

FrontPanel

ThebuttonsandLEDsonthefrontaredescribedasfollows:

NameFunction

Active/Standby

Button

–ActiveMode:TheSTBisinoperationmodeandyoucanget

broadcasting.TheLEDisilluminated.

–StandbyMode:Thepowerissuppliedanditisinreadytoactive

status.TheLEDisdimmedandalltheA/Voutputsaredisabled.

RECLEDTurnonredLEDwhentheSTBisrecordedtoHDD.

MoCALEDTurnonblueLEDwhentheSTBislinkedwithotherSTBbyMoCA

application.

ListButtonDisplaytheprogramlistsavedinHDD.

GuideButtonMovetothe[OnscreenGuide]screen.

Ch±/Vol±/Select

Button–[][]:menumovement,channelselection.

–[][]:menumovement,volumeadjustment.

–[Select]:selectthemenu.

InfoButtonDisplaythecurrentchannelnumber,selectedmenuanddetailed

informationofanitem.

ExitButtonExitmenus,guideandprograminformation.

USBPortConnecttoexternalUSBdevices,suchasakeyboardormouse.

SMT -H3272UserGuide_7 7

RearPanel

Theportnamesandfunctionsoftherearpanelaredescribedasfollows:

NameFunction

CABLEINConnectthecoaxialcablethattransmitsthesignalfromthe

CableServiceProvider.

CableCARDSlotAllowCableCARDaccess.

1394ConnectanIEEE1394cabletoIEEE1394(Firewire)supported

HDTV .

E-SATAConnecttoexternalHDD

VIDEO/AUDIOOUTConnectVideo&Audiocable(RCAcable)tosendananalog

Video/AudiosignaltotheTVorVCR.

Y/Pb/PrOUT(HDTV)Connectthecomponent(Y/Pb/Pr)outputportstothe

componentinputportsonyourHDTV .

SPDIFConnectaDigitalAudiocable(Opticalcable)tosendadigital

audiosignaltoadigitalaudiodevice(anamplierorhome

theater).

HDMIConnectaHDMIcabletoaHDMIsupportedHDTV .

LANConnectaLANcabletoaLANportofanotherSTB.(option)

POWERConnectthepowercabletosupplyACpowertotheSTB.

USBConnecttoexternalUSBdevices,suchasakeyboardor

mouse.

8 8

8_ⓒSAMSUNGElectronicsCo.,Ltd.

DVRFeatures

SMT -H3272supportsDVRfeaturethroughtheHDD(HardDiskDrive)asfollows.

FeatureDescription

FilePlaybackPlay,Stop,Rewind,Pauseforrecordedcontents.

FileT rickMode1,4,8,32timesFFP(FastForwardPlay)

1,4,8,32timesFRP(FastRewindPlay)

1/2,FramebyframeskippingSFP(SlowForwardPlay)

1/2,FramebyframeSRP(SlowRewindPlay)

Time-ShiftRecordingUsercanpauseliveTVprogramforacertainamount

oftime,andresumeittowatch.TheSTBallows90

minutesofrecordingforTime-shiftrecording.

InstantRecordingRecordliveTVprograminstantly

WatchingandRecordingRecordtwoliveTVprogramssimultaneouslywhile

watchingtworecordedprogramsonHDD.

Audio/RadioRecordingAudioorRadioprogramrecording

SimultaneousRecordingand

TimeShiftRecording

UptotwoSimultaneousRecordingandTime-Shift

RecordingonliveTVprograms

EPGRecordingScheduledrecordingusingEPG

CableCARD™

CableCARDistheSTBauthorizationdevice,whichallowssubscriberstowatch

digitallyencryptedprograms.

CableCARDisinsertedbytheserviceproviderwhenadigitalbroadcastingreceiver

isinstalled.

CableCARDUse

DonotremovetheCableCARD.CableCARDfailureorservicedisruptionmay

occur.

SMT -H3272UserGuide_9 9

INSTALLATION

FollowtheinstructionsbelowtoseehowtoinstallthedigitalHDSTB.

InstallationEnvironment

TheproperinstallationenvironmentfortheSTBisasfollows.

ItemDescription

OperationTemperature32~104˚F

OperationHumidityEqualtoorlowerthan95%(104˚F)

PowerConsumption33WMax.

RatedInputVoltageAC120V ,60Hz

ChannelInputFrequency54~1002MHz

10 10

10_ⓒSAMSUNGElectronicsCo.,Ltd.
