Real Time DVR

SHR-2040/2041/2042 User’s Manual

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page i

SHR-2040/2041/2042 USER’S MANUAL

Please be sure to keep the following in mind for the right use of the product to

pre-vent proprietary risk or damage.

■Do not use multiple plugs at once.

●This may cause abnormal heat generation or fire

■Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel

with water around you.

●This may cause fire.

■Do not bend the power cord forcibly nor put a heavy material on it.

●This may cause fire.

■Do not touch the power plug with wet hands.

●This may cause electric shock.

■Insert the power plug firmly enough not to shake.

●This imperfect connection may cause fire.

■Keep the product off humidity, dust, or soot.

●This may cause fire or electric shock.

■Do not put metals(coin, hair pin, metal piece, etc.) or inflammable

materials(match, paper, etc.) in the ventilation hole.

●This may cause fire.

■Keep the surrounding temperature between 0˚C to 40˚C and keep the

product off humidity.

●This may cause breakdown.

■Secure sufficient ventilation.

●This may cause abnormal operation due to high temperature.

■Keep the product off direct ray of light or heat from the heating

device

●This may cause fire.

■Do not disassemble, repair, or remodel the product.

●This may cause fire, electric shock, or injury due to abnormal operation.

■Do not pull out the power cord.

●This may destroy the power cord, eventually, cause fire or

electric shock.

■Plug out in the event of thunder or lightning.

●This may cause fire.

■Keep your children off the battery after you take it out of the product.

They tend to swallow it unconsciously.

●If your children swallow it, please see the doctor immediately.

■Install the product at a safe place or attach the product to the wall or

ceiling with a stand firmly enough not to fall to the ground.

●This may injure people.

Safety Regulations

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page ii

iii

WARNING

[Battery]

As wrong exchange of the battery in SHR-2040/2041/2042 may cause explosion, you

shall use the certified battery for SHR-2040/2041/2042.

The battery specification is as follows.

-Normal Voltage: 3V

-Normal Capacity: 220mAh

-Continuous Standard Load: 0.2mA

-Operating Temperature: -30 ~ +60˚C

[System Shutdown]

- Power-off without terminating the system in the System Shutdown menu may incur

improper motion like data loss and disk failure. Power-off shall be done in the

System Shutdown menu.

This User’s Manual describes the basic usage of SHR-2040/2041/2042. This Manual

contains all the matters necessary for using SHR-2040/2041/2042 such as brief

instruction, part name, function, connecting other equipment, and menu setup of

SHR-2040/2041/2042.

- SEC retains the copyright on this User’s Manual.

- This User’s Manual cannot be copied without SEC’s prior written approval.

- We are not liable for any or all losses to the product incurred by your use of non-

standard product or violation of User’s Manual.

- If you want to open the system case to touch the inside, please consult with an

expert who works for the shop where you bought the product.

- You may download open source codes from the following website.

(See CCTV Part of http://www.sec.co.kr)

Before we start

Standards Approvals

Note :

This equipment has been tested and found to comply with the limits for a Class

Adigital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance whit the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page iii

Safety Regulations

Before we start

Standards Approvals

Chapter 1 Overview

1. Introduction

2. Features

3. Part Names and Functions

Chapter 2 Installation

1. Installation Environment Setup

2. Checking Product & Accessory

3. HDD Addition

Chapter 3 Connecting with Other device

1. Connecting Video, Audio, & Monitor

2. Connecting the Network

3. Connecting the USB

4. Connecting the Alarm Input/Output

5. Connecting the RS-485 Device

Chapter 4 Live

1. System Operation

2. Live Screen Mode

3. Live Channel Selection and Audio On/Off Setup

4. Freeze and Zoom

5. Event Monitoring

6. Spot-out Monitoring

Contents

iii

1-1

1-2

1-3

2-1

2-2

2-3

3-1

3-3

3-5

3-6

3-8

4-1

4-2

4-5

4-6

4-7

4-8

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page iv

Chapter 5 Menu Setup

Before Use

1. System

2. Camera

3. Monitoring

4. Recording Mode

5. Event Record Mode

6. Record Schedule

7. Backup

8. Network

9. Network Setup

Chapter 6 PTZ Camera Control

1. PTZ camera Control Mode

2. Basic Operation of PAN, TILT, & ZOOM

3. Preset Setup

4. Camera Menu Setup

5. Preset View

6. Other View

Chapter 7 Recording

1. REC (Normal Recording)

2. Schedule Recording

3. Event Recording

Chapter 8 Search and Play

Before Use

1. Calendar Search

2. Event Search

3. Date/Time Search

4. Go to First Search

5. Go to Last Search

6. Backup

7. Playback

5-1

5-2

5-12

5-16

5-18

5-20

5-25

5-27

5-28

5-32

6-1

6-3

6-4

6-6

6-7

6-8

7-1

7-2

7-3

8-1

8-2

8-3

8-4

8-5

8-6

8-7

8-8

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page v

Chapter 9 Smart Viewer

1. Introduction

2. Feature

3. PC Specification(Recommendation)

4. Smart Viewer Installation

5. Smart Viewer Program Execution

6. Smart Viewer Initial Screen

7. Monitoring Mode

8. Search Mode

9. Setup Mode

Appendix

1. Product Specification

2. The specification of HDD and peripheral device

3. Outline Drawings

4. Factory Default

5. Smart Viewer Frame Specification for the Playback

6. Troubleshooting(FAQ)

9-1

9-2

9-3

9-4

9-7

9-8

9-9

9-23

9-30

10-1

10-4

10-5

10-7

10-9

10-11

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page vi

Chapter 1 Overview

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page 1

Introduction

1-1

The Digital Video Recorder(DVR) compresses the 4 channel of camera input data into the

MPEG4 video file and the 4 channel of voice input data into the ADPCM audio file in the real

time to record them in the Hard Disk or retrieve them from the Hard Disk simultaneously.

In addition, it transfers the Video/Audio out through a network in the real time and it is able to

monitor the Video/Audio remotely by your PC.

SHR-2040/2041/2042 USER’S MANUAL

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page 1-1

Features

1-2

■4 CH Composite Input Connectors

■NTSC / PAL Video Source Compatible

( NTSC : SHR-2040/SHR-2041/SHR2042, SHR-2040N / SHR-2041N / SHR-2042N

PAL:SHR-2040P/SHR-2041P/SHR2042P)

■Able to record the CIF sized (NTSC-352 x 240/PAL-352 x 288) video at the speed of

120 ips(NTSC)/100ips(PAL)(Image Per Second)

■4 CH Loop Through Video Connectors

■Hard Disk Overwrite Mode

■Large Quantity Hard Disk Backup by USB2.0

■Backup function by the USB2.0 memory and exterior CD/DVD writer(SHR-2042 supports

the internal CD-RW.)

■Able to record, play, and transmit both audio and video files to Windows Network

Viewer(Smart Viewer) simultaneously

■Able to record and play the audio 4CH

■Variable Search Mode (Time/Date, Event, Camera)

■Variable Recording Mode (Time Lapse, Event, Schedule)

■Extended Hard Disk Connection (USB2.0)

■Alarm Interface function (Input : 4, Output:2, Reset:1)

■Remote Monitoring function by Windows Network Viewer(Smart Viewer)

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page 1-2

No. Name Function

SHR-2040/2041/2042 USER’S MANUAL

Part Names and Functions

1-3

Power LED

HDD Access

LED Displays Normal Access to HDD. Upon Access to HDD, LED

repeats on and off.

Mode Selection

Button Search

Audio Setup

Button

Displays power on/off condition.

Network LED

Displays both network connection and data transmission conditions.

Backup LED Displays Back Up Mode.

Alarm LED lights on when an event occurs.

Rec LED Displays the record condition.

...

1 4

AUDIO

MODE

6MODE

Sets the Audio On/Off.

Audio Setup

Button

4ALARM

Cancels the alarm when the Alarm button is selected.

The single channel screen is changed

according to the time set on the menu.

Displays 4 split screen.

Displays PIP(Picture in Picture) screen.

Displays 4 split screen.

Displays 9 split screen.

(4 CH playback screen and 4 CH live screen)

Channel Button Selects a channel in the Single Mode. Used for number

input button in the number input mode.

Split Screen

Selection Button Display

Mode

Displays both LIVE Channel and Playback

Channel in the PIP Screen simultaneously.

Displays 6 split screen.

(1 CH playback screen and 4 CH live screen)

[SHR-2040]

SHR-2040/2041/2042-ENG-1 2005.6.29 4:58 PM Page 1-3
