Samsung DVG52M7750V Manuel utilisateur

Dryer

User manual

DVE(G)52M775**

DC68-03170Y-10_IB_DV7750M_EN_R.indd 1DC68-03170Y-10_IB_DV7750M_EN_R.indd 1 2023-06-30  3:25:282023-06-30  3:25:28

Contents

English2

Contents

Safety information 4

What you need to know about the safety instructions 4

Important safety symbols 4

CALIFORNIA PROPOSITION 65 WARNING 9

Important safety precautions 9

Warnings 11

Cautions 11

Installation requirements 13

Key installation requirements 13

Location considerations 13

Ducting requirements 14

Exhausting requirements 15

Gas requirements 16

Electrical requirements 17

Installation 20

What’s included 20

Step-by-step installation 22

Vent blockage test 28

Exhaust ducting guide 30

Switching the door position 30

Before you start 33

Sort and load 33

Functional prerequisite 33

Operations 34

Feature panel 34

Simple steps to start 37

Cycle overview 38

Cycle guide 39

Special features 40

DC68-03170Y-10_IB_DV7750M_EN_R.indd 2DC68-03170Y-10_IB_DV7750M_EN_R.indd 2 2023-06-30  3:25:312023-06-30  3:25:31

Contents

English 3

Maintenance 42

Vent sensor (applicable models only) 42

Cleaning 43

Troubleshooting 44

Checkpoints 44

Information codes 46

Specications 48

Fabric care chart 48

Protecting the environment 49

Specication sheet 50

Cycle chart 51

DC68-03170Y-10_IB_DV7750M_EN_R.indd 3DC68-03170Y-10_IB_DV7750M_EN_R.indd 3 2023-06-30  3:25:312023-06-30  3:25:31

Safety information

SAVE THESE INSTRUCTIONS

English4

Safety information

Congratulations on your new Samsung dryer. This manual contains important information

on the installation, use and care of your appliance. Please take some time to read this

manual to take full advantage of your dryer’s many benets and features.

What you need to know about the safety instructions

Please read this manual thoroughly to ensure that you know how to safely and efciently

operate the extensive features and functions of your new appliance. Please store the

manual in a safe location close to the appliance for future reference. Use this appliance

only for its intended purpose as described in this instruction manual.

Warnings and Important Safety Instructions in this manual do not cover all possible

conditions and situations that may occur. It is your responsibility to use common sense,

caution and care when installing, maintaining and operating your dryer.

Because the following operating instructions cover various models, the characteristics of

your dryer may differ slightly from those described in this manual and not all warning

signs may be applicable. If you have any questions or concerns, contact your nearest

service center or nd help and information online at www.samsung.com.

Important safety symbols

What the icons and signs in this user manual mean:

WARNING

Hazards or unsafe practices that may result in severe personal injury, death and/or

property damage.

CAUTION

Hazards or unsafe practices that may result in personal injury and/or property damage.

NOTE

Indicates that a risk of personal injury or material damage exists.

These warning signs are here to prevent injury to yourself and others.

Please follow them explicitly.

After reading this manual, store it in a safe place for future reference.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 4DC68-03170Y-10_IB_DV7750M_EN_R.indd 4 2023-06-30  3:25:312023-06-30  3:25:31

Safety information

SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS

English 5

Read all instructions before using the appliance.

As with any equipment that uses electricity and moving parts, potential hazards exist.

To safely operate this appliance, familiarize yourself with its operation and exercise care

when using it.

WARNING - Risk of Fire

• Clothes dryer installation must be performed by

a qualied installer.

• Install the clothes dryer according to the

manufacturer’s instructions and local codes.

• Do not install a clothes dryer with exible plastic

venting materials. If exible metal (foil type) duct

is installed, it must be of a specic type identied

by the appliance manufacturer as suitable for use

with clothes dryers. Flexible venting materials

are known to collapse, be easily crushed, and

trap lint. These conditions will obstruct clothes

dryer airow and increase the risk of re.

• Do not install a booster fan in the exhaust duct.

• To reduce the risk of severe injury or death,

follow all installation instructions.

• Save these instructions.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 5DC68-03170Y-10_IB_DV7750M_EN_R.indd 5 2023-06-30  3:25:312023-06-30  3:25:31

Safety information

SAVE THESE INSTRUCTIONS

Safety information

SAVE THESE INSTRUCTIONS

English6

WARNING - To reduce the risk of re or

explosion:

• Do not dry items that have been previously

cleaned, washed, soaked, or spotted with

gasoline, dry cleaning solvents, or other

ammable or explosive substances. They emit

vapors that could ignite or explode. Any material

that has been in contact with a cleaning solvent

or ammable liquids or solids should not be

placed in the dryer until all traces of these

ammable liquids or solids and their fumes

have been removed. There are many highly

ammable items used in homes, such as acetone,

denatured alcohol, gasoline, kerosene, some

liquid household cleaners, some spot removers,

turpentine, waxes, and wax removers.

• Items containing foam rubber (which may

be labeled latex foam) or similarly textured

rubberlike materials must not be dried on a heat

setting. Heated foam rubber materials can, under

certain circumstances, ignite spontaneously.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 6DC68-03170Y-10_IB_DV7750M_EN_R.indd 6 2023-06-30  3:25:312023-06-30  3:25:31

Safety information

SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS

English 7

WARNING - Fire or explosion hazard

• Failure to follow safety warnings exactly could

result in serious injury, death or property

damage.

• Do not store or use gasoline or other ammable

vapors and liquids near this or any other

appliance.

• Installation and service must be performed by

a qualied installer, service agency, or the gas

supplier.

• Do not install a booster fan in the exhaust duct.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 7DC68-03170Y-10_IB_DV7750M_EN_R.indd 7 2023-06-30  3:25:322023-06-30  3:25:32

Safety information

SAVE THESE INSTRUCTIONS

Safety information

SAVE THESE INSTRUCTIONS

English8

WARNING - What to do if you smell gas:

• Do not try to light any appliance.

• Do not turn on the appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call the

re department.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 8DC68-03170Y-10_IB_DV7750M_EN_R.indd 8 2023-06-30  3:25:322023-06-30  3:25:32

Safety information

SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS

English 9

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Important safety precautions

WARNING

To reduce the risk of re, electric shock, or injury to persons when using your appliance,

follow basic precautions, including the following:

1. Read all instructions before using this appliance.

2. Do not dry articles that have been previously cleaned in, washed in, soaked in,

or spotted with gasoline, dry-cleaning solvents, or other ammable or explosive

substances, as they give off vapors that could ignite or explode.

3. Do not use the dryer to dry clothes which have traces of any ammable substance,

such as vegetable oil, cooking oil, machine oil, ammable chemicals, paint thinner,

etc., or anything containing wax or chemicals, such as mops and cleaning cloths.

Flammable substances may cause the fabric to catch re by itself.

4. Do not store or use gasoline or other ammable vapors and liquids near this or any

other appliance.

5. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

6. Before the appliance is removed from service or discarded, remove the door to the

drying compartment.

7. Do not reach into the appliance if the drum is moving.

8. Do not install or store this appliance where it will be exposed to the weather.

9. Do not tamper with internal controls.

10. Do not repair or replace any part of the appliance or attempt any service unless

specically recommended in the user-maintenance instructions or in published user-

repair instructions that you understand and have the skills to carry out.

11. Do not use fabric softeners or products to eliminate static unless recommended by the

manufacturer of the fabric softener or product.

12. Clean the lint screen before or after each load.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 9DC68-03170Y-10_IB_DV7750M_EN_R.indd 9 2023-06-30  3:25:322023-06-30  3:25:32

Safety information

SAVE THESE INSTRUCTIONS

Safety information

SAVE THESE INSTRUCTIONS

English10

13. Do not use heat to dry articles containing foam rubber or similarly textured rubber-

like materials.

14. Keep area around the exhaust opening and adjacent surrounding areas free from the

accumulation of lint, dust, and dirt.

15. The interior of the appliance and exhaust duct should be cleaned periodically by

qualied service personnel.

16. Do not place items exposed to cooking oils in your dryer. Items contaminated with

cooking oils may contribute to a chemical reaction that could cause a load to catch

re. To reduce the risk of re due to contaminated loads, the nal part of a tumble

dryer cycle occurs without heat (cool down period). Avoid stopping a tumble dryer

before the end of the drying cycle unless all items are quickly removed and spread

out so that the heat is dissipated.

17. This appliance must be grounded. See “Electrical requirements” and “Grounding” in

“Installation” section.

18. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

19. Do not insert your hand under the dryer.

– This may result in injury.

20. Take care that children’s ngers are not caught in the door when closing it.

– This may result in injury.

21. The control board and inlet valve are intentionally not grounded and may present a

risk of electric shock only during servicing.

– Do not contact these parts while the appliance is energized.

DC68-03170Y-10_IB_DV7750M_EN_R.indd 10DC68-03170Y-10_IB_DV7750M_EN_R.indd 10 2023-06-30  3:25:322023-06-30  3:25:32
