Samsung TL320 - Digital Camera - Compact Manuel d'instructions

This Quick Start Manual has been specially designed to guide you

through the basic functions and features of your device.

Please read the Quick Start Manual and User Manual carefully to

ensure safe and correct use.

Quick Start Manual

TL320

For more information, refer to

the User Manual included on the

supplied CD-ROM.

ENG / SPA

FOR TECHNICAL SUPPORT, PLEASE CALL 1-800-SAMSUNG (726-7864)

POR FAVOR LLAMAR 1-800-SAMSUNG (726-7864) PARA ASISTENCIA TECNICA

TL320_QSM2_SEA.indb 3 2009-09-17 오후 1:21:34

EN-2

Health and safety informationContents

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach of

small children and animals. Small parts may cause choking

or serious injury if swallowed. Moving parts and accessories

may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1m/3

ft) to people or animals. Using the ﬂash too close to your

subject’s eyes can cause temporary or permanent damage.

Health and safety

information…………………… 2

Camera layout ……………… 4

Setting up your camera …… 5

Unpacking ……………………… 5

Inserting the battery and

memory card …………………… 6

Charging the battery …………… 6

Turning on your camera………… 7

Selecting options ……………… 7

Capturing photos or videos 8

Playing ﬁles ………………… 9

Transferring ﬁles to a PC

(Windows) …………………… 10

Speciﬁcations ……………… 11

TL320_QSM2_SEA.indb 2 2009-09-17 오후 1:21:34

EN-3

English

Exercise caution when connecting cables or adapters•

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

Do not insert foreign objects into any of your camera’s•

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

Protect batteries, chargers, and memory cards from

damage

Avoid exposing batteries or memory cards to very•

cold or very hot temperatures (below 0° C/32° F or

above 40° C/104° F). Extreme temperatures can

reduce the charging capacity of your batteries and

can cause memory cards to malfunction.

Prevent memory cards from making contact with•

liquids, dirt, or foreign substances. If dirty, wipe the

memory card clean with a soft cloth before inserting

in your camera.

Handle and dispose of batteries and chargers with

care

Use only Samsung-approved batteries and chargers.•

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

Never place batteries or cameras on or in heating•

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

Cautions

Handle and store your camera carefully and sensibly

Do not allow your camera to get wet—liquids can•

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

Avoid using or storing your camera in dusty, dirty,•

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

TL320_QSM2_SEA.indb 3 2009-09-17 오후 1:21:34

EN-4

Mode dial

Shutter button

POWER button

Mini dashboard

Microphone

Speaker

Flash

AF-assist light/timer lamp

Lens

USB and A/V port

Camera layout

Battery chamber cover

Remote control sensor

Zoom button

Smart Control Dial (Navigation button)

Function button

Playback button

MENU button

Status lamp

Tripod mount

Display

3 4 5

TL320_QSM2_SEA.indb 4 2009-09-17 오후 1:21:34

EN-5

English

Setting up your camera

Unpacking

Camera AC adapter/USB cable

(AD44-00143A)/(AD39-00172A)

Rechargeable battery

(4302-001226)

Strap

(Silver: AD63-02596A/

Black: AD63-02604A)

Software CD-ROM

(User manual included)

(AD46-00252A)

Quick Start Manual

(AD68-03887A)

Optional accessories

Camera case Memory cards A/V cable

(AD39-00163A)

Sold as a set

HDMI cradle manual

(AD68-03835A)

Remote control

(AD59-00164A)

Cradle

(AD61-04195A)

HDMI cable

(AD39-00160A)

TL320_QSM2_SEA.indb 5 2009-09-17 오후 1:21:34

EN-6

Setting up your camera

Inserting the battery and memory card Charging the battery

Push gently until the card

disengages from the camera

and then pull it out of the slot.

▼

Removing the battery

With the gold-colored

contacts facing up

With the

Samsung logo

facing up

▼

Removing the memroy card

Indicator light

Red▪: Charging

Green▪: Fully charged

Before using the camera for the ﬁrst time, you must

charge the battery.

TL320_QSM2_SEA.indb 6 2009-09-17 오후 1:21:35

EN-7

English

Press [

POWER].

The intial setup screen appears.▪

Press [

t] to select Language and press [t].

Press [

D] or [M] to select a language and

press [o].

Press [

D] or [M] to select Date & Time and

press [t].

Press [

F] or [t] to select an item.

Press [

D] or [M] to change the number or

select another date format and press [o].

In Shooting mode, press [

m].

Rotate or press the navigation button to scroll

to an option or menu

Press [▪D] or [M] to move up

or down; press [F] or [t] to

move left or right.

Rotate the navigation button any▪

direction.

Press [

o] to conﬁrm the highlighted option

or menu.

Press [▪m] again to go back to the previous

menu.

Turning on your camera Selecting options

TL320_QSM2_SEA.indb 7 2009-09-17 오후 1:21:35

EN-8

Taking a photo

Rotate the mode dial to

Align your subject in the frame.

Press [

Shutter] halfway down to focus

automatically.

A green frame means the subject in focus.▪

Press [

Shutter] all the way down to take the

photo.

Recording a video

Rotate the mode dial to

Align your subject in the frame.

Press [

Shutter].

Press [▪o] to pause or resume.

Press [

Shutter] again to stop the recording.

Note

Number of photos by resolution (for 1 GB SD)

Resolution Super ﬁne Fine Normal

4000 x 3000 142 274 389

3984 x 2656 162 302 426

3968 x 2232 195 355 509

2976 x 2976 195 355 509

3264 x 2448 204 361 518

2592 x 1944 327 547 764

2048 x 1536 514 774 1,028

1920 x 1080 840 1,104 1,387

1024 x 768 1,420 1,612 1,807

These ﬁgures are measured under Samsung’s standard

conditions and may vary depending on shooting conditions

and camera settings.

Capturing photos or videos

TL320_QSM2_SEA.indb 8 2009-09-17 오후 1:21:36

EN-9

English

Playing ﬁles

Viewing photos

Press [

P].

Press [

F] or [t] to scroll through ﬁles.

Press and hold to view ﬁles quickly.▪

Viewing videos

Press [

P].

Press [

o].

Pause

Use the following buttons to control playback.

[F]Scan backward

[o]Pause or resume playback

[t]Scan forward

[Zoom] up or

down Adjust the volume level

TL320_QSM2_SEA.indb 9 2009-09-17 오후 1:21:36

EN-10

Transferring ﬁles to a PC (Windows)

Insert the installation CD in a CD-ROM drive

and follow the onscreen instructions.

Connect the camera to the PC with the USB

cable.

Turn on the camera.

On your PC, select

My Computer →

Removable Disk →DCIM →100SSCAM.

Select the ﬁles you want and drag or save them

to the PC.

Disconnecting safely (for Windows XP)

Click

▼

Click

TL320_QSM2_SEA.indb 10 2009-09-17 오후 1:21:37
