Samsung DIGIMAX 202 Manuel utilisateur

Thank you for buying a Samsung Camera.

This manual will guide you through using the Digimax 202, including capturing images, downloading images and

using the MGI PhotoSuite III SE software. Please read this manual carefully before using your new camera.

6806-1747

R4040290

SAMSUNG TECHWIN CO., LTD.

OPTICS & DIGITAL IMAGING DIVISION

145-3, SANGDAEWON 1-DONG, JUNGWON-

GU,SUNGNAM-CITY, KYUNGKI-DO, KOREA

462-121

TEL : (82) 31-740-8086,8088, 8090, 8092, 8099

FAX : (82) 31-740-8398, 8111

SAMSUNG OPTO-ELECTRONICS AMERICA, INC.

HEADQUARTERS

40 SEAVIEW DRIVE, SECAUCUS, NJ07094, U.S.A.

TEL : (1) 201-902-0347

FAX : (1) 201-902-9342

WESTERN REGIONAL OFFICE

18600 BROADWICK ST.,

RANCHO DOMINGUEZ, CA 90220, U.S.A.

TEL : (1) 310-537-7000

FAX : (1) 310-537-1566

SAMSUNG OPTO-ELECTRONICS UK LIMITED

SAMSUNG HOUSE

1000 HILLSWOOD DRIVE

HILLSWOOD BUSINESS PARK

CHERTSEY KT16 OPS U.K.

TEL : +44 (0) 1932 455300

FAX : +44 (0) 1932 455325

SAMSUNG OPTO-ELECTRONICS GMBH

AM KRONBERGER HANG 6

D-65824 SCHWALBACH/TS., GERMANY

TEL : (49) 6196 66 53 03

FAX : (49) 6196 66 53 66

SAMSUNG FRANCE S.A.S.

BP 51 TOUR MAINE MONTPARNASSE

33, AV .DU MAINE

75755, PARIS CEDEX 15, FRANCE

HOTLINE PHOTO NUMÉRIQUE :

00 800 22 26 37 27(Numéro Vert-Appel Gratuit)

TEL : (33) 1-4279-2282/5

FAX : (33) 1-4320-4510

SAMSUNG TECHWIN MOSCOW OFFICE

KORP. 14 37-A LENNINGRADSKY PR-KT

MOSCOW, 125167, RUSSIA

TEL : (7) 095-258-9296, 9298, 9299

FAX : (7) 095-258-9297

TIANJIN SAMSUNG OPTO-ELECTRONICS CO.,LTD.

7 PINGCHANG ROAD NANKAI DIST., TIANJIN

P.R CHINA

POST CODE:300190

TEL : (86) 22-2761-8867

FAX : (86) 22-2761-8864

Internet address - http : //www.samsungcamera.com/

The CE Mark is a Directive conformity

mark of the European Community (EC)

ENGLISH

Instructions

Use this camera in the following order

Insert the

USB cable

Set up the

camera driver

Before connecting the camera to a PC, via the

USB cable, you will need to set up the camera

driver. Install the camera driver that is contained in

the Application S/W CD-ROM.(p.73)

Take a picture (p.21)

Insert the supplied USB cable into the PC’s USB

port and the camera’s USB connection

terminal.(p.80)

Check the camera’s power

If the power is turned off, press the camera button

to power it on.(p.25)

Take a picture

Check the

camera’s power

Check

[Removable Disk]

Open Window s EXPLORER and search for

[Removable Disk].(p.81)

If you use a card reader to copy the images on the memory card to your PC, the images could

be damaged. When transferring the images taken with the camera to your PC, be sure to use

the supplied USB cable to connect the camera to your PC. Please note that the manufacturer

holds no responsibility for loss or damage of images on the memory card due to the use of a

card reader.

Contents

Getting to know your camera 5

About the icons 5

Danger 6

Warning 6

Caution 7

An FCC warning 7

This digital camera can be used for 8

Manufacturer's contents 10

Identification of features 11

Front & Top 11

Back & Bottom 11

Side/ 5-function button 12

Mode dial 12

Connecting to a Power Source 14

Using the AC power adapter

(3.3V 2.0A) 15

Using the batteries 16

Using the Digimax battery pack

( Optional : SBP-3603, 3.3V) 16

Instructions on how to use the memory card

Maintenance of the memory card 17

Preserving the memory card data 17

Inserting the memory card 19

Removing the memory card 19

LCD monitor indicator 20

Starting the recording mode 21

Using the camera buttons to adjust the

camera 25

POWER button 25

SHUTTER button 25

WIDE / TELE button 25

Up/Down button 27

FLASH / LEFT button 27

Self-timer / Right button 28

+/- button 30

Focus lever 31

MENU/ OK button 32

LCD button 32

Using the LCD monitor to adjust the camera

settings 33

How to use the menu 34

Size 35

Quality 35

Metering 36

Sharpness 37

White balance 38

Effect 39

Photo Frame 39

LCD monitor indicator 40

Starting play mode 41

Playing back a still image 41

Playing back a movie clip 42

Using the camera buttons to adjust the

camera 42

Thumbnail / Enlargement button 42

Play & Pause / Down button 44

UP/LEFT / RIGHT/ MENU/ OK button 44

LCD button 45

READY

RECORDING

PLAY

Contents

Delete button 45

Setting up the play back function using the

LCD monitor 46

Starting the slide show 47

Protecting images 48

Deleting all images 49

Copy to card 50

DPOF : Setting the Number of

Copies to Print 51

Rotating an image 52

Resize 53

Setup menu 54

File name 55

Auto power off 56

Language 57

Formatting a memory card 57

Setting up the Date type 58

Date Setup 59

Time Setup 59

Imprinting date recording 60

Beep 60

Frequency 61

Quick view 62

Initialization(RESET ALL) 62

Latest 63

Setting up the MYCAM menu 63

Start up sound 64

Start up image 64

Important notes 65

Warning indicator 67

Before contacting a service center 68

Specifications 70

Software Notes 72

System Requirements 72

About the software 73

Setting up the application software 74

Starting PC Mode 80

Removing the USB Driver for

Windows 98SE 83

Removable Disk 84

Removing the removable disk 85

Setting up the USB Driver for MAC 86

Using the USB Driver for MAC 86

Digimax Viewer 87

MGI PhotoSuite III SE 88

FAQ 98

SOFTWARE

SETUP

Getting to know your camera

Thank you for buying a Samsung Digital Camera.

Prior to using this camera, please read the user manual thoroughly.

When you require After Sales service, please bring the camera and the cause of the camera

malfunction (such as Batteries, Memory card etc.) to the A/S center.

Please check that the camera is operating properly prior to when you intend to use it (e.g. for

a trip or an important event) to avoid disappointment. Samsung camera takes no

responsibility for any loss or damages that may result from camera malfunction.

Keep the manual in a safe place.

Microsoft, Windows and Windows logo are registered trademarks of Microsoft Corporation

incorporated in the United States and/or other countries.

All brand and product names appearing in this manual are registered trademarks of their

respective companies.

This manual contains instructions on using this camera that will help you to use this camera

safely and correctly. This will help prevent danger and injury to others.

About the icons

DANGER

DANGER indicates an imminently hazardous situation which, if not avoided,

will result in death or serious injury.

WARNING

WARNING indicates a potentially hazardous situation, which, if not avoided,

could result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation, which, if not avoided,

may result in a minor or moderate injury.

Danger

Do not attempt to modify this camera in any way. This may result in fire, injury, electric shock

or severe damage to you or your camera. Internal inspection, maintenance and repairs

should be carried out by your dealer or Samsung Camera Service Center.

Please do not use this product in close proximity to flammable or explosive gases, as this

could increase the risk of explosion.

Should any form of liquid or a foreign object enter the camera, do not use it. Switch off the

camera, and then disconnect the power source (batteries or AC Power Adapter). You must

contact your dealer or Samsung Camera Service Center. Do not continue to use the camera

as this may cause a fire or electric shock.

Do not insert or drop metallic or inflammable foreign objects into the camera through access

points e.g. the memory card slot and battery chamber. This may cause a fire or electric

shock.

Do not operate this camera with wet hands. This could pose a risk of electric shock.

Do not use the flash in close proximity to people or animals. Positioning the flash too close to

your subject’s eyes, may cause eyesight damage.

When taking photographs, never point the lens of the camera directly into very strong light.

This may result in permanent damage to your eyesight.

For safety reasons keep this product and accessories out of reach of children or animals to

prevent accidents e.g.:

Swallowing batteries or small camera accessories. If an accident should occur, please

consult a doctor immediately.

There is the possibility of injury from the camera’s moving parts.

Batteries and camera may become hot during prolonged use and it may result in camera

malfunction. Should this be the case, allow the camera to sit idle for a few minutes to allow it

time to cool.

Do not recharge non rechargeable batteries. This may cause an explosion.

Do not leave this camera in places subject to extremely high temperatures, such as a sealed

vehicle, direct sunlight or other places of extreme variances in temperature. Exposure to

extreme temperatures may adversely affect the camera s internal components and could

cause a fire.

When in use, do not cover the camera or AC Power Adapter. This may cause heat to build up

and distort the camera body or cause a fire. Always use the camera and its accessories in a

well-ventilated area.

Warning

Caution

Leaking, overheating, or burst batteries could result in fire or injury.

Use batteries with the correct specification for the camera.

Do not short circuit, heat or dispose of batteries in fire.

Do not insert the batteries with the reverse polarities.

Remove the batteries when not planning to use the camera for a long period of time.

Batteries may leak corrosive electrolyte and irreparably damage the camera's components.

Do not fire the flash while it is in contact with hands or objects. Do not touch the flash after

using it continuously. It may cause burns.

Do not move the camera while it is switched on, if you are using the AC Power Adapter.

After use, always switch off the camera before unplugging the adapter from the wall socket.

Then make sure that any connector cords or cables to other devices are disconnected before

moving the camera. Failure to do so may damage the cords or cables and cause a fire or

electric shock.

An FCC warning

This device has been tested in accordance with the limits of a class B digital device

under item 15 of the FCC rules. These limits are designed to provide protection against

harmful interference in commercial installation. This equipment generates, absorbs and

can emit radio frequency energy. If it is not installed and used in accordance with the

instructions, it may cause harmful interference to radio communication. There is

however, no guarantee that interference will not occur in some situations. Should any

interference occur when this device is in operation, please try one or more of the

following measures.

Change the location and direction of any aerial.

Increase distance between the camera and the affected device.

Use a different socket away from the affected device.

Please contact a Samsung agent or a radio/TV engineer.

This device complies with part 15 of the FCC Rules.

Changes or modifications not expressly approved by the party responsible for

compliance could void user's authority to operate the equipment.

This digital camera can be used for

Printing images using a dedicated

printer, DPOF-compatible printer or

DPOF-equipped photo lab.

(refer to page 51)

Downloading image files from

camera to computer.

(refer to page 81)

Editing images on a PC.

(refer to page 88)

Taking a picture.

(refer to page 21)

This digital camera can be used for

Inserting images directly

into any electronic

document.

Taking a self-portrait

and using the image

to personalize name

cards.

You can even create your own unique

gift wrap paper by using your digital

images.

Creation of a digital photo album.

Recording a movie clip

(refer to page 22)

Manufacturer's contents

Please check that you have the correct contents before using this product.

marked contents are optional.

Digital Camera USB cablePouch

2 AA Alkaline

Batteries

Camera strap Software CDProduct warrantyUser manual

AC adapter (3.3V)

Battery pack

(SBP-3603)

SD memory card

Battery charger AC adapter (5V)Rechargeable battery

Digimax Battery I-Pack : SBP-1103 KIT

Table des matières

Autres manuels Samsung Appareil photo numérique

Samsung

Samsung S85 - Digital Camera - Compact Manuel utilisateur

Samsung

Samsung ST510 Manuel d'instructions

Samsung

Samsung Galaxy Camera EK-GC100 Manuel utilisateur

Samsung

Samsung GX10 - Digital Camera SLR Manuel utilisateur

Samsung

Samsung ES63 Manuel d'instructions

Samsung

Samsung DIGIMAX A6 Manuel utilisateur

Samsung

Samsung SCC-B2391(P) Manuel utilisateur

Samsung

Samsung SLB-1974 Manuel utilisateur

Samsung

Samsung Digimax S500 Manuel utilisateur

Samsung

Samsung Digimax S800 - Digital Camera - 8.1... Manuel utilisateur

Samsung

Samsung VLUU ST80 Manuel utilisateur

Samsung

Samsung AD68-04852A Manuel d'instructions

Samsung

Samsung NX100 Manuel utilisateur

Samsung

Samsung CL65 Manuel d'instructions

Samsung

Samsung L100 - Digital Camera - Compact Manuel utilisateur

Samsung

Samsung L100 - Digital Camera - Compact Manuel utilisateur

Samsung

Samsung VLUU PL120 Manuel utilisateur

Samsung

Samsung SAMSUNG PL210 Manuel utilisateur

Samsung

Samsung Vluu ST600 Manuel d'instructions

Samsung

Samsung NX10 Manuel utilisateur

Samsung

Samsung NX10 Guide de démarrage rapide

Samsung

Samsung S 85 Manuel utilisateur

Samsung

Samsung ES20 Manuel d'instructions

Samsung

Samsung S85 - Digital Camera - Compact Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
