Samsung AF MV1MAEENTC Series Mode d’emploi

Air conditioner

User & installation manual

AF✴✴MV1MAEENTC / AF✴✴MV1MAEEXTC

•Thank you for purchasing this Samsung air conditioner.

•Before operating this unit, please read this user manual carefully and retain it for future

reference.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 1 2017-06-02 오후 3:34:31

2English

Contents

Safety Information 4

At a Glance 12

Indoor Unit Overview 12

Control Panel Overview 13

Indoor unit display

Locking the control panel

Using the air conditioner with the control panel 14

Remote Control Overview 15

Replacing batteries

Storing the remote control

Remote Control Operation 17

Turning on or off the air conditioner

Operation modes

Controlling fan speed

Controlling temperature

Controlling air flow direction

Basic Operation 19

Selecting air flow direction

Quick Smart Features 20

Timed on/Timed off function

Turbo function

Long reach function

Cleaning and Maintenance 22

Cleaning at a Glance 22

Troubleshooting 25

Safety Information 28

General information

Installing the unit

Power supply line, fuse or circuit breaker

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 2 2017-06-02 오후 3:34:31

3English

Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.

charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.

To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate

these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material

resources.

Household users should contact either the retailer where they purchased this product, or their local government

office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This

product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Installation Procedure 31

Step 1 Choosing the installation location

Step 2 Unpacking

Step 3 Checking and preparing accessories

Step 4 Drilling a hole through a wall

Step 5 Taping the pipes, cables, and drain hose

Step 6 Connecting the refrigerant pipes

Step 7 Optional: Cutting and flaring the pipes

Step 8 Connecting the power and communication cables

Step 9 Optional: Extending the power cable

Step 10 Checking the earthing

Step 11 Performing gas leakage test

Step 12 Evacuating the air

Step 13 Charging the refrigerant

Step 14 Fixing and insulating the connection part for refrigerant pipes

Step 15 Installing and connecting the drain hose

Step 16 Performing drainage test

Step 17 Checking the earthing

Step 18 Performing the final check and trial operation

Appendix 49

Troubleshooting

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 3 2017-06-02 오후 3:34:31

4English

Safety Information (Using the Air Conditioner)

Safety Information

Safety Information (Using the Air Conditioner)

Before using your new air conditioner, please read this manual thoroughly

to ensure that you know how to safely and efficiently operate the

extensive features and functions of your new appliance.

Because the following operating instructions cover various models, the

characteristics of your air conditioner may differ slightly from those

described in this manual. If you have any questions, call your nearest

contact center or find help and information online at www.samsung.com.

These warning signs are here to prevent injury to you and others. Please

follow them carefully.

Important safety symbols and precautions:

WARNING

Hazards or unsafe practices that may result in severe personal injury or

death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or

property damage.

Follow directions.

Do NOT attempt.

Make sure the machine is grounded to prevent electric shock.

Unplug the power plug from the wall socket.

Do NOT disassemble.

Safety Information

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 4 2017-06-02 오후 3:34:31

5English

Safety Information

FOR INSTALLATION

WARNING

Use the power line with the power specifications of the product or

higher and use the power line for this appliance only. In addition, do

not use an extension line.

• Extending the power line may result in electric shock or fire.

• Do not use an electric transformer. It may result in electric shock or

fire.

• If the voltage/frequency/rated current condition is different, it may

cause fire.

The installation of this appliance must be performed by a qualified

technician or service company.

• Failing to do so may result in electric shock, fire, explosion, problems

with the product, or injury.

Install a switch and circuit breaker dedicated to the air conditioner.

• Failing to do so may result in electric shock or fire.

Fix the outdoor unit firmly so that the electric part of the outdoor

unit is not exposed.

• Failing to do so may result in electric shock or fire.

Do not install this appliance near a heater, inflammable material. Do

not install this appliance in a humid, oily or dusty location, in a location

exposed to direct sunlight and water (rain drops). Do not install this

appliance in a location where gas may leak.

• This may result in electric shock or fire.

Never install the outdoor unit in a location such as on a high external

wall where it could fall.

• If the outdoor unit falls, it may result in injury, death or property

damage.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 5 2017-06-02 오후 3:34:31

6English

Safety Information (Using the Air Conditioner)

Safety Information

This appliance must be properly grounded. Do not ground the

appliance to a gas pipe, plastic water pipe, or telephone line.

• Failure to do so may result in electric shock, fire, an explosion, or

other problems with the product.

• Never plug the power cord into a socket that is not grounded

correctly and make sure that it is in accordance with local and

national codes.

CAUTION

Install your appliance on a level and hard floor that can support its

weight.

• Failing to do so may result in abnormal vibrations, noise, or problems

with the product.

Install the draining hose properly so that water is drained correctly.

• Failing to do so may result in water overflowing and property

damage.

When installing the outdoor unit, make sure to connect the draining

hose so that draining is performed correctly.

• The water generated during the heating operation by the outdoor

unit may overflow and result in property damage. In particular, in

winter, if a block of ice falls, it may result in injury, death or property

damage.

Do not install the product in a place where thermo-hygrostat is needed

(such as server room, machinery room, computer room, etc.)

• Those places do not provide guaranteed operation condition of the

product therefore performance can be poor in these places.

Do not install the product in a place where hair spray is frequently

used (such as hair salon) since it decreases the hydrophilicity of the

product's heat exchanger and cause dew formation on the surface of

the product.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 6 2017-06-02 오후 3:34:32

7English

Safety Information

FOR POWER SUPPLY

WARNING

When the circuit breaker is damaged, contact your nearest service

centre.

Do not pull or excessively bend the power line. Do not twist or tie the

power line. Do not hook the power line over a metal object, place a

heavy object on the power line, insert the power line between objects,

or push the power line into the space behind the appliance.

• This may result in electric shock or fire.

CAUTION

When not using the air conditioner for a long period of time or during

a thunder/lightning storm, cut the power at the circuit breaker.

• Failing to do so may result in electric shock or fire.

FOR USING

WARNING

If the appliance is flooded, please contact your nearest service centre.

• Failing to do so may result in electric shock or fire.

If the appliance generates a strange noise, a burning smell or smoke,

unplug the power plug immediately and contact your nearest service

centre.

• Failing to do so may result in electric shock or fire.

In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate

immediately without touching the power line. Do not touch the

appliance or power line.

• Do not use a ventilating fan.

• A spark may result in an explosion or fire.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 7 2017-06-02 오후 3:34:32

8English

Safety Information (Using the Air Conditioner)

Safety Information

To reinstall the air conditioner, please contact your nearest service

centre.

• Failing to do so may result in problems with the product, water

leakage, electric shock, or fire.

• A delivery service for the product is not provided. If you reinstall the

product in another location, additional construction expenses and an

installation fee will be charged.

• Especially, when you wish to install the product in an unusual

location such as in an industrial area or near the seaside where it

is exposed to the salt in the air, please contact your nearest service

centre.

Do not touch the circuit breaker with wet hands.

• This may result in electric shock.

Do not strike or pull the air conditioner with excessive force.

• This may result in fire, injury, or problems with the product.

Do not place an object near the outdoor unit that allows children to

climb onto the machine.

• This may result in children seriously injuring themselves.

Do not turn the air conditioner off with the circuit breaker while it is

operating.

• Turning the air conditioner off and then on again with the circuit

breaker may cause a spark and result in electric shock or fire.

After unpacking the air conditioner, keep all packaging materials well

out of the reach of children, as packaging materials can be dangerous

to children.

• If a child places a bag over its head, it may result in suffocation.

Do not insert your fingers or foreign substances into the outlet when

the air conditioner is operating or the air flow blade is closing.

• Take special care that children do not injure themselves by inserting

their fingers into the product.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 8 2017-06-02 오후 3:34:32

9English

Safety Information

Do not insert your fingers or foreign substances into the air inlet/outlet

of the air conditioner.

• Take special care that children do not injure themselves by inserting

their fingers into the product.

Do not use this air conditioner for long periods of time in badly

ventilated locations or near infirm people.

• Since this may be dangerous due to a lack of oxygen, open a window

at least once an hour.

If any foreign substance such as water has entered the appliance,

cut the power by unplugging the power plug and turning the circuit

breaker off and then contact your nearest service centre.

• Failing to do so may result in electric shock or fire.

Do not attempt to repair, disassemble, or modify the appliance

yourself.

• Do not use any fuse (such as copper, steel wire, etc.) other than the

standard fuse.

• Failing to do so may result in electric shock, fire, problems with the

product, or injury.

CAUTION

Do not place objects or devices under the indoor unit.

• Water dripping from the indoor unit may result in fire or property

damage.

Check that the installation frame of the outdoor unit is not broken at

least once a year.

• Failing to do so may result in injury, death or property damage.

Max current is measured according to IEC standard for safety and

current is measured according to ISO standard for energy efficiency.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 9 2017-06-02 오후 3:34:32

10 English

Safety Information (Using the Air Conditioner)

Safety Information

Do not stand on top of the appliance or place objects (such as laundry,

lighted candles, lighted cigarettes, dishes, chemicals, metal objects,

etc.) on the appliance.

• This may result in electric shock, fire, problems with the product, or

injury.

Do not operate the appliance with wet hands.

• This may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of

the appliance.

• As well as being harmful to humans, it may also result in electric

shock, fire or problems with the product.

Do not drink the water from the air conditioner.

• The water may be harmful to humans.

Do not apply a strong impact to the remote control and do not

disassemble the remote control.

Do not touch the pipes connected with the product.

• This may result in burns or injury.

Do not use this air conditioner to preserve precision equipment, food,

animals, plants or cosmetics, or for any other unusual purposes.

• This may result in property damage.

Avoid directly exposing humans, animals or plants from the air flow

from the air conditioner for long periods of time.

• This may result in harm to humans, animals or plants.

This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety. Children should be supervised to ensure that they do not

play with the appliance.

PAC_B2B 미라지 필리핀향_IBIM_EN_DB68-07271A-00_170504.indd 10 2017-06-02 오후 3:34:32

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Climatiseur

Samsung

Samsung AVMKH020EA0 Manuel utilisateur

Samsung

Samsung AQ12PGGE Manuel utilisateur

Samsung

Samsung AC048KNPPCC Manuel utilisateur

Samsung

Samsung AS U Series Mode d’emploi

Samsung

Samsung HTDS1860 Manuel utilisateur

Samsung

Samsung FH052EAV1 Manuel utilisateur

Samsung

Samsung AM053FXMDCH Manuel utilisateur

Samsung

Samsung AXM260VE Manuel utilisateur

Samsung

Samsung MH020FPEA Manuel utilisateur

Samsung

Samsung AM***KNTD** Manuel utilisateur

Samsung

Samsung AS12WA Series Manuel utilisateur

Samsung

Samsung AJ CXS CH Series Manuel utilisateur

Samsung

Samsung S-NET mini MST-S3W Manuel utilisateur

Samsung

Samsung PH28ZA1 Manuel utilisateur

Samsung

Samsung DB98-32786A Manuel utilisateur

Samsung

Samsung AS18BP Series AS24BP Series Manuel utilisateur

Samsung

Samsung AS18A0RCF Manuel utilisateur

Samsung

Samsung AVMBC020EA Manuel utilisateur

Samsung

Samsung AM KN4DCH Series Manuel utilisateur

Samsung

Samsung AVMDSH022EA Manuel utilisateur

Samsung

Samsung ND 4HXEA Series Manuel utilisateur

Samsung

Samsung AC BN4PKG Series Manuel utilisateur

Samsung

Samsung MH052FDEA Manuel utilisateur

Samsung

Samsung AW05M0YEA/XFO Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur

Webasto

Webasto Frigo Top 25 DS Manuel utilisateur

Frigidaire

Frigidaire FAZ12ES2A Manuel utilisateur
