USE & CARE INSTRUCTIONS

10 CUP PROGRAMMABLE COFFEEMAKER

FSCM100

SPECIAL SELECT

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed to reduce the risk of fire, electric shock, and/or

injury to persons, including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against fire, electric shock, and injury to persons,

do not immerse cord, plug, or Coffee Maker in water or

other liquid.

4. Close supervision is necessary when any appliance is used by or

near children.

5. Unplug from outlet when not in use and before cleaning.

Allow to cool before putting on or taking off parts, and before

cleaning the appliance.

6. Do not operate any appliance with a damaged cord or plug, or

after the appliance malfunctions, or has been damaged in any

manner. Contact Consumer Service.

7. The use of accessory attachments not recommended by the

appliance manufacturer may result in fire, electric shock, or

injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch

hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a

heated oven.

11. To disconnect, slide the AUTO/OFF/ON Switch to OFF, then

remove plug from wall outlet.

12. Do not use appliance for other than intended use.

13. Be certain Lids are securely in place before operating appliance.

14. Scalding may occur if the Lid is removed during the

brewing cycles.

15. This Carafe is designed for use with this Coffee Maker. It must

never be used on a range top

16. Do not set a hot Carafe on a wet or cold surface.

17. Do not use a cracked Carafe or a Carafe having a loose or

weakened handle.

18. Do not clean Carafe with cleansers, steel wool pads, or other

abrasive material.

SAVE THESE INSTRUCTIONS

This product is for household use only.

WARNING: This appliance generates heat and escaping steam

during use. Use proper precautions to prevent the risk of

burns, fires, or other injury to persons or damage to property.

1. Do not pour liquid other than water and the cleaning solution

specified in this manual into the Water Reservoir.

2. Coffeemaker must be left to cool down for approximately

15 minutes before adding more water.

3. DO NOT attempt to move an appliance containing hot liquids.

Allow appliance to cool completely before moving.

4. DO NOT leave empty Carafe on Warming Plate when appliance is

turned ON, as the Carafe may crack or become otherwise damaged.

5. Always use fresh, cool water in your Coffeemaker. Warm water or

other liquids, except as listed in cleaning section, may cause damage

to the appliance.

6. DO NOT lift Water Reservoir Lid or Swing-Out Filter Basket until

brewing is complete and all parts have cooled.

7. DO NOT put Carafe into a microwave.

CAUTION: To prevent injury when utilizing Drip Stop Feature, replace

Carafe within 20 seconds of removing during brewing process.

ADDITIONAL IMPORTANT SAFEGUARDS

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to

fit into a polarized outlet only one way. If the plug does not fit fully

in the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician. Do not attempt to modify the plug in any way.

SHORT CORD INSTRUCTIONS

A short power-supply cord is provided to reduce the risk resulting

from becoming entangled in or tripping over a longer cord.

Longer detachable power-supply cords or extension cords are

available and may be used if care is exercised in their use.

If a longer detachable power-supply cord or extension cord is used,

(1) the marked electrical rating of the cordset or extension cord

should be at least as great as the electrical rating of the appliance,

and (2) the cord should be arranged so that it will not drape over

the counter top or table top where it can be pulled on by children

or tripped over unintentionally.

ELECTRIC POWER

If the electrical circuit is overloaded with other appliances, your

appliance may not operate properly. It should be operated on a

separate electrical circuit from other appliances.

This appliance is FOR HOUSEHOLD USE ONLY and may be

plugged into any 120V AC electrical outlet. Do not use any other

type of outlet.

GETTING TO KNOW YOUR FARBERWARE®

10 CUP COFFEEMAKER

1. Water Reservoir Lid (P/N 30654)

2. Swing-Out Filter Basket (P/N 30651)

3. Water Reservoir

4. Carafe Lid (P/N 30652)

5. Control Panel

6. Polarized Plug

7. Warming Plate

8. Carafe w/Lid (P/N 30653)

9. Drip Stop Assembly (P/N 30781)

10. Water Level Indicator

11. Removable Filter Basket Assembly

(P/N 30650)

9. 4.

10.

11.

(inside)

AUTO OFF ON

ONHOUR

MIN.

BREW

CONTROL PANEL

REMOVABLE FILTER BASKET

AM/PM

AUTO ON

ON/

BREWING

AUTO/OFF/ON

Switch

GETTING TO KNOW YOUR COFFEEMAKER (Cont.)

To remove the Removable Filter Basket for cleaning, pull Basket

straight up and out of the machine. After cleaning, the Removable

Filter Basket must be pushed all the way into the Swing-Out Filter

Basket. Before use, make sure the Swing-Out Filter Basket fits

securely back into the unit.

Removable

Filter Basket

Drip Stop

Assembly

Swing-Out

Filter Basket

INSTRUCTIONS FOR USE

BEFORE BREWING COFFEE FOR THE FIRST TIME

CAUTION: To protect against electric shock, do not submerge the

Coffeemaker or allow AC cord to come into contact with

water or other liquids.

1. After carefully unpacking from carton, the inside of your

Coffeemaker and Carafe must be cleaned.

2. Brew 10 cups of fresh water only. Follow the instructions

under BREWING COFFEE Section but do not add coffee

grounds to the paper filter.

3. When all the water has brewed into the Carafe, slide the

AUTO/OFF/ON Switch to OFF.

4. Allow the Coffeemaker to cool for 10 minutes, discard the

water from the Carafe, then repeat steps 2 and 3.

5. After the second pot of water has cooled, discard the water and

thoroughly wash the Removable Filter Basket (see illustration on

page 5), Carafe and Carafe Lid in warm, soapy water. Dry all

parts thoroughly.

FOR BEST RESULTS

We recommend using coffee which has been ground specifically

for automatic drip coffeemakers. This type of coffee is prepared

specifically for your Coffeemaker’s brewing system and promotes

fuller extraction to provide rich, full-bodied coffee.

Use only cone-shaped filters with this Coffeemaker. Cone-shaped

paper filters are available locally at grocery stores. Use standard, #4

filters. You may also purchase permanent gold filters, which

eliminate the need for disposable paper filters. Do not use basket-

style paper filters.

DRIP STOP FEATURE

This FARBERWARE®Coffeemaker has an Automatic Drip Stop

Feature. During the brewing cycle, the Carafe can be removed

to pour a cup of coffee from the Carafe. The Drip Stop Feature will

prevent the Coffeemaker from continuing to brew coffee for up to

one minute until the Carafe is returned to its proper position.

IMPORTANT: The Carafe must be replaced on the Warming Plate,

under the Filter Basket in less than a minute to prevent the

Filter Basket from overflowing.

AUTOMATIC START-UP FEATURE

This FARBERWARE®Coffeemaker has an Automatic Start-Up

feature. This feature allows you to pre-program the Coffeemaker to

begin brewing coffee at a specific time. By leaving the

AUTO/OFF/ON Switch in the AUTO position, the Coffeemaker

will start-up automatically every day at the programmed start-up

time. You may override the Automatic Start-Up feature at any time

(without affecting the program) by sliding the AUTO/OFF/ON

Switch to ON. To restore the program, slide the AUTO/OFF/ON

Switch back to AUTO.

AUTOMATIC SHUT-OFF FEATURE

The Automatic Shut-Off feature automatically turns off the

Coffeemaker two hours after a programmed brew time. This

prevents the Coffeemaker from being left on for an extended period

of time, which is harmful to both the Coffeemaker and

the Carafe.

NOTE: The Automatic Shut-Off feature will only work when the

Coffeemaker is in the AUTO position and a pre-programmed

start-up time has been scheduled.

BREWING COFFEE IN YOUR

FARBERWARE®10 CUP

PROGRAMMABLE COFFEEMAKER

CAUTION: Use this product with proper AC voltage rating only.

Be sure to unplug the power cord when Coffeemaker is not in

use for extended periods of time.

1. Lift the Carafe Lid. Fill the Carafe with

cold water to the level for the desired

number of cups (1-10). Open the Water

Reservoir Lid, and pour the water from

the Carafe into the Water Reservoir.

Close the Water Reservoir Lid.

2. Swing out the Coffee Filter Basket

and place a #4 paper coffee filter

(or a permanent gold filter) inside

the Removable Filter Basket.

3. Put coffee grounds in the filter, using

one level tablespoon of drip grind

coffee for each cup of brewed coffee.

(See Figure 1.)

4. Make sure the Removable Filter Basket is

pushed all the way into the Swing-Out

Filter Basket. Make sure the Swing-Out

Filter Basket fits securely back into the unit.

IMPORTANT: When using the Timer feature,

and at all times before brewing, remember

to place Carafe on the Warming Plate.

5. Place the Carafe on the Warming Plate,

making sure the Carafe Lid is on the Carafe.

6. Make sure the AUTO/OFF/ON Switch is in

the OFF position. Plug the appliance into a

standard 120V AC electrical outlet.

7. The LCD will flash “12:00” until you set the

time. (See Figure 2.)

FIGURE 1

AUTO OFF ON

ONHOUR

MIN.

BREW

FIGURE 2

SETTING THE CLOCK / TIMER

1. Set the Timer to the correct time of

the day by pushing the HOUR Button

until the correct hour appears on the

LCD Display. Then push the MIN.

Button to the current minutes. Be sure

to note a.m. and p.m. times.

NOTE: The LED in the upper-left corner

of the Display indicates the P.M.

hours. (See Figure 3.)

2. To program the Coffeemaker for

Automatic Start-Up, push and HOLD

the BREW Button. While holding the

BREW Button, push the HOUR Button

to the desired start-up time hour.

Continue to hold the BREW Button,

and push the MIN. Button until the

correct minutes appears. Be sure to

note a.m. and p.m. times.

(See Figure 4.)

NOTE: Once the BREW button is

released, the exact time of the day

will be shown. To see the

programmed start-up time, press the

BREW Button.

3. To start the Coffeemaker

immediately:

Slide the AUTO/OFF/ON Button to

the ON position. The ON LED will

illuminate as the Coffeemaker begins

brewing the coffee. (See Figure 5.)

BREWING COFFEE (Cont.)

AUTO OFF ON

ONHOUR

MIN.

BREW

FIGURE 3

AM/PM Indicator

AUTO OFF ON

ONHOUR

MIN.

BREW

FIGURE 5

Brew Coffee

AUTO OFF ON

ONHOUR

MIN.

BREW

FIGURE 4

Set Auto Start-Up times

Table des matières

Autres manuels Salton Cafetière

Salton

Salton FC1205 Manuel utilisateur

Salton

Salton FC2074 Manuel utilisateur

Salton

Salton Expresso Pro EX-1040 Manuel utilisateur

Salton

Salton FC-1180 Manuel utilisateur

Salton

Salton FC1939 Manuel utilisateur

Salton

Salton EX-1091 Manuel utilisateur

Salton

Salton ME5B Manuel utilisateur

Salton

Salton SCM80 Guide d'installation

Salton

Salton JUMBO java FC1667TH Manuel utilisateur

Salton

Salton Elite SCM30E Mode d’emploi

Salton

Salton EX-1016 Manuel utilisateur

Salton

Salton FC-1104 Manuel utilisateur

Salton

Salton FC-1052 Manuel utilisateur

Salton

Salton SEM10 Guide d'installation

Salton

Salton Elite SECM21 Guide d'installation

Salton

Salton FC-1026 Manuel utilisateur

Salton

Salton Thermal Cafe ME8DSB Manuel utilisateur

Salton

Salton MEPE123BT Manuel utilisateur

Salton

Salton FC-120E Manuel utilisateur

Salton

Salton FC1214 Manuel utilisateur

Salton

Salton FC-3T Manuel utilisateur

Salton

Salton FC1952 Manuel utilisateur

Salton

Salton FC-1191 Manuel utilisateur

Salton

Salton FC1438 Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
