Sakura Tissue-Tek TEC 6 Manuel utilisateur

Tissue-Tek®TEC™6

Cryo Module

Operating Manual

Part Number M01-022E-01

Revision Letter Original

Released 2018-08-03

The brand names of products that have been registered or trademarked by and are owned

by Sakura Finetek USA, Inc., Sakura Finetek Japan Co., Ltd., and Sakura Finetek Europe B.V.

appear here:

Sakura

Tissue-Tek

Please visit our website www.sakura-netek.com

Manufactured for:

Sakura Finetek USA, Inc., Torrance, CA 90501 U.S.A.

Sakura Finetek Europe B.V., 2408 AV Alphen aan den Rijn, NL

Sakura Finetek Japan Co., Ltd., Tokyo, 103-0023, Japan

Manufactured by:

Sakura Seiki Co., Ltd., Nagano, 387-0015, Japan

Printed in Japan.

Table of contents

1. Introduction

1.1 Intended Use…………………………………………………………7

1.2 Safety Precautions …………………………………………………8

1.3 Precautions for Use……………………………………………… 13

1.4 Overview of the Instrument …………………………………… 14

1.4.1 Instrument Conguration ……………………………… 14

1.4.2 Specications …………………………………………… 15

1.5 Accessories ……………………………………………………… 16

1.5.1 Standard Accessories (Cryo Module) ………………… 16

1.6 Description of Instrument Parts ……………………………… 17

1.6.1 Instrument (Front Side) ………………………………… 17

1.6.2 Instrument (Rear Side) ………………………………… 17

2. Installation

2.1 Installation ………………………………………………………… 19

2.1.1 General Information on Installing the Instrument…… 19

2.1.2 Installation Environment………………………………… 19

2.1.3 Unpacking Method of the Cryo Module ……………… 20

2.1.4 Installation Method ……………………………………… 22

2.2 Setting Up the Instrument ……………………………………… 25

2.2.1 Temperature Setting for Each Part of the Instrument 25

2.2.2 Setting the Schedule of the Auto Operation (with the

Auto Cryo Mode) ………………………………………… 28

2.3 Operational Overview …………………………………………… 30

2.3.1 Operation Method ……………………………………… 30

3. Explanation of Operations

3.1 Explanation of Operations ……………………………………… 33

3.1.1 Basic Operations ………………………………………… 33

4. Error Log

4.1 Error Log ………………………………………………………… 35

4.1.1 Viewing the Error Log …………………………………… 35

5. Troubleshooting

5.1 Troubleshooting ………………………………………………… 37

5.1.1 Instrument Condition and Solution …………………… 37

5.1.2 Message Window………………………………………… 38

5.1.3 What to Do Following a Power Outage ……………… 44

5.2 Cleaning…………………………………………………………… 45

5.2.1 Inspection and Cleaning ………………………………… 45

5.2.2 Cleaning the Cryo Module ……………………………… 45

6. Replacement Parts

6.1 Replacement Parts ……………………………………………… 47

6.1.1 Cryo Module …………………………………………… 47

7. Glossary of Terms

7.1 Glossary of Terms ……………………………………………… 49

Table of contents

1. Introduction

1.1 Intended Use

The Tissue-Tek®TEC™6 Cryo Module (hereinafter referred to “the instrument”)

is intended to embed processed human or animal tissue in parafn by cooling

blocks which contain tissues and paraffin on cassettes after dispensing

molten paraffin. This instrument is used to facilitate as part of steps to

produce tissue specimens for histological studies and tests conducted in the

elds of pathology, anatomy, clinical pathology, etc.

The Cryo Module is controlled through the Embedding Module, so it must be

connected with a control cable. This document is the Operating Manual for

the Cryo Module. For more detail on how to operate the instrument, refer to

the Operating Manual for the Tissue-Tek®TEC™6 Embedding Module.

In the case of disposal or maintenance of the instrument, comply with

national, regional and local laws and regulations for equipment containing

hydrouorocarbon to ensure proper management and collection of HFC.

Carefully read this Operating Manual and use the instrument correctly so

that its performance can be utilized fully. Any other use of this instrument is

considered improper operation.

1.2 Safety Precautions

Designate the "Instrument Control Manager."

• Operation of the instrument requires expert knowledge of the target

application, method of use, and so on. Therefore, to use the instrument

correctly and safely, designate an "Instrument Control Manager."

• When the instrument is delivered, the Instrument Control Manager should

receive explanation on the handling of the instrument directly from the

staff trained in the instrument or distributor.

Before using the instrument, read the "Safety Precautions" to ensure the

correct use of the instrument.

The cautionary instructions provided herein are intended to ensure that the

instrument will be used safely in a manner preventing operator from injury and

property damage. These instructions provide important safety information

that must be needed at all times.

In this manual, instructions pertaining to different levels of potential hazards

are classified and indicated respectively as danger, warning, caution and

note.

The denition of each hazard is dened below.

DANGER pertains to a potential hazard where failure to observe the specied

instruction may result in death or serious injury of the user or another person.

WARNING pertains to a potential hazard where failure to observe the

specified instruction may result in a serious injury of the user or another

person.

CAUTION pertains to a potential hazard where failure to observe the specied

instruction may result in damage to the instrument or other property, or affect

the process results.

NOTE pertains to an item to pay attention to or other useful information.

DANGER

WARNING

CAUTION

1. Introduction

The symbols used on the labels attached to the instrument are explained.

The labels bearing one of the following symbols provide particularly important

information you must know in order to ensure safety of the operator, improve

work efficiency and protect the instrument from damage. Be sure to check

these labels and understand the specified instructions before commencing

your work

A label bearing this symbol specifies an action that must be taken. Always

follow the instruction.

A label bearing this symbol specifies a prohibited item. Always follow the

instruction.

A label bearing this symbol specifies a precaution. Wrong handling against

the instruction may potentially expose the operator to danger or damage the

instrument, so be sure to follow the instruction.

A label bearing this symbol is provided near a high-temperature area. Exercise

caution against burns caused by high temperatures.

If any biologically hazardous substance is handled, follow applicable

regulations or guidelines in your country or region to ensure safety.

WARNINGS:

• Follow instructions in this operating manual.

If the instrument is not used properly, it may induce failure of the

instrument, injury to operators, and/or damages to facilities.

• Observe the instructions described in the Operating Manual.

Failure to do so will lead to instrument failure, a risk of injury to the

user and damage to facilities.

• Do not disassemble or modify the instrument.

Do not disassemble or modify the instrument except for the areas

specified in this manual.The instrument may malfunction or cause

accident, thus creating a dangerous situation.

• Do not wet the instrument.

Do not wet the instrument except for the areas specified in this

manual. If the instrument gets wet, electrical current leak may occur

and cause re or electric shock.

• Do not operate the switches with a wet hand.

Failure to observe the instruction may result in electric shock.

• Do not connect/remove the power plug with a wet hand.

Failure to observe the instruction may result in electric shock.

• When connecting/removing the power plug, do so by holding the

plug.

Connecting/removing the power plug by holding parts other than the

plug may cause re or electric shock.

• Do not damage the power cord.

Do not forcibly bend, pull, twist or bundle the power cord. If the

damaged power cord is used, fire or electric shock may occur. If

the power cord or power plug has scratches or other abnormalities,

contact a Sakura instrument distributor or representative.

• Check the power cord and electrical outlet for damage and

accumulated dust periodically.

Failure to do so may cause re depending on the condition.
