Sailor SP3110 Manuel utilisateur

SAILOR, THE GREAT EUROPEAN

SAILOR SP3110

THE PORTABLE VHF

TRANSCEIVER

FOR GMDSS

PWR

VOL

A B 16

VOL

SP3110

28442A

MONITOR

LAMP

PTT

CALL

Monitor switch for listening-in on

a channel, irrespective of the

squelch level setting.

Backlight switch, used to turn-on

the illumination of the display

and/or the keyboard, depending

on programming.

PTT switch.

(Call switch, for selective calling.)

Microphone

SP3110

Display read-out

HI VOL

DUP

1 2 3 4 5

101112 9 7 6

28443

1. HIgh - LOw, TX power level indicators.

2. TX on indicator, (carrier is transmitted).

3. DUPlex channel indicator.

4. Volume indicator, on in high level AF

power mode.

5. VOLume sign, the two digits below indicate

the actual volume setting.

6. 8 alpha-numeric digits, used for channel

number indication etc.

7. Squelch sign, the two digits above indicate the

actual squelch setting.

8. Battery low indicator.

9. Keyboard lock indicator.

10.Individual call alarm indicator.*

11.AF-mute indicator.*

12.Tone system ON indicator.*

* Functional only in conjunction with

optional tone module for selective calling.

SP3110

Contents

Page

Introduction 1

Emergency 3

Batteries 4

Operator's guide 5

Quick channel programming 7

Additional features 8

Installation 10

Rechargeable batteries 11

Mounting of clip 13

Removing clip 14

1 SP3110

Introduction

SP3110, your new VHF-transceiver, is approved

to fulfil the GMDSS-requirements to portable

VHF-transceivers, and so it is a part of the

required safety equipment to be used in an

emergency situation.

However, the best way to guarantee functional-

ity in an emergency, is to use the equipment in

the daily work on-board, as a useful communica-

tion media.

This is possible, due to a unique concept, with

the PRIMARY EMERGENCY BATTERY, stored

for the emergency, and a SECONDARY RE-

CHARGEABLE BATTERY for daily use of your

new portable VHF-transceiver.

This concept secures at least 8hours operation

time, even at minus 20 C° at sea.

ECI has developed the first portable VHF-

transceiver to be used as you normally use a

telephone.

This feature gives you a much better com-

munication quality in noisy surroundings.

SP3110 2

Furthermore, you have all the international

simplex channels, quick selection of distress ch.

16 and two additional user programmable

channels, and a lot of other useful features.

3 SP3110

Emergency

Procedure for SP3110.

If an emergency situation forces you to leave the

ship, do as follows:

1. Remove the top-seal of the orange emer-

gency battery package.

2. Insert the battery package into the handheld

transceiver unit.

3. Push the - button,

until the radio turns on, indicated by channel

read-out in the display.

4. Push the

- button to ensure that the

channel for distress traffic is active.

NOTE !

Due to battery storage effects, the turn-on time

may be extended compared to normal condi-

tions. If Battery seal is broken for test, fill in label

on battery.

SP3110 4

Batteries

This unit has been delivered with two types of

battery packages :

* An orange PRIMARY EMERGENCY BAT-

TERY package, to be used in an emergency,

as indicated by its colour.

* A black SECONDARY RE-CHARGEABLE

BATTERY for daily use of the equipment.

Replacement of battery package :

* Press the two stainless steel locks on each

side of the battery package with your thumb

and indexfinger and pull out the battery.

28468

* Insert the new battery package into the

bottom of the transceiver and press it

upwards until it snaps in with a “click”.

5 SP3110

Operator's guide

Press.....

Until unit turns ON/OFF, indicated by the

display readout.

To lock keyboard, indicated by

To unlock keyboard, disappears.

To select loudspeaker operation, .

To select telephone-mode operation.

To turn on keyboard beep-function.

To turn off keyboard beep-function.

To change setting of a selected function,

Default: Volume level function.

PWR

To select Tx power level function.

To select Channel selection function.

To select Squelch level function.

VOL

To select Volume level function.
