Russell Hobbs RHB315 Guide d'installation

INSTRUCTIONS AND WARRANTY

RHB315

RUSSELLHOBBS

SATIN JUG BLENDER

2-year warranty (1 year retail • 1 year extended upon online registration of product • visit

www.russellhobbs.co.za)

is in place. Do not use this to switch the blender on and off.

7. Turn the switch to standby “0” / “OFF” before fitting/ removing the jugto/ from the

motor/ baseunit.

8. Turn the switch to standby “0” / “OFF” and wait until the blades come to a complete

stop before removing the lid from the jug, and before removing the jug from the motor/

baseunit.

9. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for theirsafety.

10. Children shouldbe supervisedtoensurethattheydonotplaywiththeappliance.

11. Do not use the blender without first locking the lid inplace.

12. Do not fill the jug with boiling liquids.Allow liquids to cool to a lukewarm temperature

before you put them in the jug. This type of temperature would be comfortable tothe

touch.

13. Do not put your hand into the jug, even when it has been removed for

cleaning –the blades are verysharp.

14. Do not come into contact with movingparts.

15. Do not put any other object (spoon, spatula, etc.) Into the jug while the blender

is pluggedin.

16. Do not leave the blender unattended when pluggedin.

17. Misuse of this appliance can result ininjury.

18. Position the motor unit on a dry, firm, level surface, close to a power socket

and out of reach ofchildren.

19. Route the mains lead so that it cannot be caught accidentally or trippedover.

20. Keep the blender and the mains lead away from hotplates, hobs andburners.

21. Store the blender away from direct sunlight and fluorescent light where

possible.

22. Do not let thejugoverflow. If liquid gets under the motor unit, it may be

sucked into the motor, damagingit.

23. Do not fill the jug above the MAX. mark. If you do, the contents may force the

lid off when you start the motor.

24. The blender is equipped with a powerful motor and therefore processes very

quickly. Due to its efficiency there is no need to run the motor for more than 2

minutes at atime.

25. Do not run the motor for more than 2 minutes, either continuously, or using

the pulse setting, otherwise it may overheat. After 2 minutes use, switch it off

for at least 2 minutes allowing it to cool to room temperature and allowing it

recover.

26. Do not use the blender for any purpose other than those described in these

instructions.

27. Do not run the blender empty, as it mayoverheat.

28. Do not operate the blender after it malfunctions. If the mains lead or plug is

damaged, return the blender to the manufacturer in order to avoid any

hazard.

29. Children should be supervised to ensure thatthey do not play with the appliance.

30. Always turn the power off at the power outlet before you remove the plug.

Remove by grasping the plug. Do not pull on the electricalcord.

31. This appliance is designed for processing household quantities; it is not

suitable for commercial purposes. Use the appliance only for the purpose it

was designedfor.

32. Do not use this appliance if it or parts of it show visible damage or if the

appliance has beendropped.

33. Do not attempt to make any modifications to thisappliance.

34. To avoid any risk and to remain within warranty, repairsto this appliance must

be carried out by an authorised service agentonly.

35. To reduce the risk of injury, never place the blade assembly on the base

without the jar properlyattached.

36. If the supply cord is damaged, it must be replaced by the manufacturer, its

authorised service agent or similarly qualified persons in order to avoid any

hazard.

37. Switch off the appliance and disconnect from the power supply before

changing accessories or approaching parts that move when inuse.

38. Use only accessories provided by the manufacturer for thisappliance.

39. Do not run this appliance with an external timer or remote controlsystem.

PARTS DIAGRAM 1

7 5

1. MeasuringCup

2. JugLid

3. GlassJug

4. Blade Assembly SealingRing

5. Blade AssemblyUnit

6. Blade AssemblyBase

7. MotorUnit

8. ControlKnob

9. Assembled GlassJug

10. Jug Lid SealingRing

BEFORE FIRST USE

Before using your appliance for the first time take it out of the box and take off any protective

wrappings. REMEMBER: DO NOT LEAVE PROTECTIVE PACKAGING LYING AROUND, AS IT

COULD BE DANGEROUS AROUND INFANTS. Wash the jug, lid and cap in warm soapy

water, rinse wellanddry.

NOTE: The blades are sharp,handle with care.

OPERATING INSTRUCTIONS

Assembly of the Glass Jug

Put the sealing ring (4) on the inner edge of the blade unit(5).

Put the blade unit (5) with sealing ring into the blade assembly base(6).

Mount the glass jug (3) onto the blade assembly base. Turn the blade assembly base

in a clockwise direction until it is correctly tightened in place. Be careful not to turn it

too much as it may strip the thread inside the jug baseunit.

Mount the fully assembly glass jug onto the motor/ baseunit.

After putting the ingredients in the jug, put the lid (2) onto the jug by pressingdown.

Insert the measuring cup (1) into the opening of the lid, and turn it in a clockwise

direction until it is locked inplace.

Inserting the Glass Jug

Position the motor unit on a dry, firm, level surface, close to a power socket and out of

reach ofchildren.

Make sure that the blender is switched off (Switched to the „0‟setting).

Place the fully assembled glass jug (9) onto the motor(7).

Use

Place the ingredients that you wish to process into the glassjug.

Put the lid on the glass jug and close securely. Place the measuring cup into the hole in

the lid and turn clockwise to lock. It is not a good idea to run the blender without the

measuring cup in place, especially if only solid ingredients are used. They may be

ejected through the hole once they hit theblades.

Switch on the motor:

Speedsetting Use

Low(1-3) for light usage withliquids

High(4-5) for more solid consistency –for mixing liquids and solid foodstuffs

P for ice crushing & short, powerfulbursts

Caution: Don‟t remove the lid from the jug while the blender is ON.

After using the blender, always move the switch into the „0‟ setting and remove the

mains plug from the poweroutlet.

To remove the glass jug just turn it in an anti-clockwise direction and then lift itup.

Pulse Function

The pulse function will give you a short burst at maximum speed, regardless of the

current speed of the blades. The button is spring-loaded. When you stop pressing,

it will return to the speed the switch is pointingat.

Crushing Ice

Before using the blender to crush ice, make sure it is clean and rinse it out thoroughly.

Any remaining trace of detergent may affect the taste of the crushed ice and will flatten

any drink to which it has beenadded.

Ice cubes come in many shapes and sizes. You will have to experiment with the ice from

your ice cube tray. Insert a maximum of 8 ice cubes and add 15ml (1 tablespoon) of fresh

cold water. Put the lid on the blender and turn the control knob to “P”. While the unit is

blending, hold for 2 seconds and release for 2 seconds. Note that too much blending will

reduce the ice to liquid, too little will merely chip the edges/corners off the ice. Do not try to

crush ice without adding water to thejug.

Do not be tempted simply to increase the amount of ice and blend for longer –this

willnotwork.Toomuchicewillnevergiveyousatisfactoryresults.

Adding Ingredients

If you need to add ingredients while the blender is working, lift the cap off, pour

the new ingredients through the hole then replace the measuring cup. Make

sure that the added ingredients do not push the volume in the jug past the

MAX.mark.

Tips for Using Your Blender

Donotblenddry,thickorheavymixturesformorethan60secondscontinuously.Let the

appliance cool down before continue operating the applianceagain.

Do not place the lid into boiling water as it maydeform.

To achieve the best results when pureeing solid ingredients, place small portions

into the glass jug one by one instead of placing a large quantity all atonce.

If you are processing solid ingredients, cut them into small pieces (2-3cm)first.

When mixing solid ingredients start off first with a small amount of liquid. Gradually

add more and more liquid through the opening in thelid.

For stirring solid or very thick liquid ingredients we recommend that you use the

blender in pulse mode to prevent the blades from becomingstuck.

Always place your hand on top of the blender when you are operating thedevice.

Be careful when processing lukewarmliquids.

SMOOTHIE RECIPES

Banana Smoothie

Ingredients:

1 Banana Peeled & Sliced

¼ Cup Oats

1TbspHoney

1 Tbsp Peanut Butter

100g flax seeds

150mlYogurt

1 Cup Ice

Method:

Add all ingredients into theblender.

Pulse it at first to break theice.

Blend for about 2 minutes untilsmooth.

Tip

This smoothie is great for sustained energy throughout the day. The banana has

high levels of potassium, helping you to quickly replenish electrolytes. (The riper a

banana, the higher the sugar content). The peanut butter is high in protein and the

raw oats is a Low GI filler. Flax seed is a great source of fibre and Omega 3 fatty

acids, and yoghurt contains protein, calcium, riboflavin, vitamin B6 and vitamin

B12.

Berry Smoothie

Ingredients:

1 Cup Strawberry, blueberry & Raspberry

150ml low fat ice cream/ frozen yogurt

1Banana

1 Cup Ice

Method:

Add all ingredients into theblender.

Pulse it at first to break theice.

Blend for about 2 minutes untilsmooth.

Tip.

Strawberry –high in vitamin C andantioxidants.

Blueberry - high level of antioxidants and may be considered t hemost

nutritionalberry.

Raspberry - sweet taste along with vitamin C, vitamin E, and a good weight loss

supplement.

Banana - high in dietaryfibre.

Coconut Smoothie

Ingredients:

1 Tin coconut milk

1 tablespoon sesame oil

1 tablespoon flax seeds

1 teaspoon vanilla extract

1 Tbsp Honey

Cup ice

Method:

Add all ingredients into theblender.

Pulse it at first to break theice.

Blend for about 2 minutes untilsmooth.

Tip

Sesame oil is a source of vitamin E which is an anti-oxidant and has been

correlated with lowering cholesterollevels.

Flax seed is a great source of fibre and Omega 3fatty acids.

Fruit & Muesli Smoothie

Ingredients:

1½ cups low-fat milk

tablespoons low-fat natural or vanillayoghurt

Autres manuels pour RHB315

Table des matières

Autres manuels Russell Hobbs Mixer

Russell Hobbs

Russell Hobbs DESIRE RHBL5BLK Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs 24722-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 28241-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs MIX & GO Manuel utilisateur

Russell Hobbs

Russell Hobbs RHSB 025 Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs 21480-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 24601-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs Soup and Blend 21481-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 14449 Manuel utilisateur

Russell Hobbs

Russell Hobbs Explore Mix & Go Cool 21350-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 18995-56 Manuel

Russell Hobbs

Russell Hobbs 22990 Manuel utilisateur

Russell Hobbs

Russell Hobbs 25230-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 23820-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHFP62 Manuel utilisateur

Russell Hobbs

Russell Hobbs 25720-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 24732-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 22340-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHBL50 Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs Aura Mix & Go Pro 22340-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 25710-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs Blender Manuel utilisateur

Russell Hobbs

Russell Hobbs Desire 18508 Manuel utilisateur

Russell Hobbs

Russell Hobbs 22250-56 Manuel utilisateur

Manuels Mixer populaires d'autres marques

ROTOR

ROTOR 1125.201 Manuel utilisateur

Braun

Braun Multiquick 5 Vario series Manuel utilisateur

ARENDO

ARENDO MIRA 305424 Manuel utilisateur

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuel utilisateur

Viconte

Viconte VC-4406 Manuel utilisateur

Oster

Oster BLSTAB-CB0 Manuel utilisateur

HOFFEN

HOFFEN MC-3005 Manuel utilisateur

Black & Decker

Black & Decker BLC18750DM Manuel utilisateur

Sunbeam

Sunbeam 4182 Manuel utilisateur

Bialetti

Bialetti FMX35 Manuel utilisateur

Black & Decker

Black & Decker BL8000 Manuel utilisateur

Duronic

Duronic BL530 Manuel utilisateur

Exquisit

Exquisit MS 3002 wes Manuel utilisateur

Lumme

Lumme LU-KP1891A Manuel utilisateur

Binatone

Binatone HB-735 Manuel utilisateur

Moulinex

Moulinex LM936E10 Manuel utilisateur

Oster

Oster VERSA Manuel d'installation et d'exploitation

Ninja

Ninja NN210Q Manuel utilisateur
