Royston “T” UNIT Manuel utilisateur
MODULAR MERCHANDISING ASSEMBLY: “T” UNIT
G (2)
A (2)
B (2)
D (2)
C (2 left hand,
2 right hand)
E (2)
F (1)
H (8) J (4) K (4) L (4)
PARTS:
Slatwall shown is optional
ASSEMBLING FEET:
Drive Plugs (J) into bottom of
Uprights (B). Tap all the way in.
Leveler Screws (K) should be
screwed into (J).
ASSEMBLING FRAME:
Insert Wings (C) into both sides of
each Upright (B) as shown.
1.
J K
B J
2.
Insert the Wire Grids
(G) into the channels
on Upright (B).
Note: the Wire Grids
(G) must be inserted
so that
the vertical
wires are inside
the
frame.
B
G(2)
The end of the Wire Grid must fit into
the hole at the bottom of the Upright
channel.
Make sure the
horizontal wires that
are set close together
are at the
bottom
of
the unit.
C
B
MODULAR MERCHANDISING ASSEMBLY: “T” UNIT
Insert Screws (H) into
holes at top and bottom
of both sides of Upright.
If the unit is going to
be sitting alone, affix
End Panels (E) to each
of the Uprights (B).
Bottom of Uprights Top of Uprights
Insert open ends of the Wire Grids
G (2) (G) into the channels on the
second Upright (B) as shown.
Next, fasten with Screws (K) as
previously described.
B
B
G (2)
ASSEMBLING FRAME:
2.
MODULAR MERCHANDISING ASSEMBLY: “T” UNIT
If the unit will be connected to another “T” unit, slide the two units together,
and connect as shown using the bottom and top connector pieces
B
E
Royston LLC One Pickroy Road Jasper, GA 30143 800.334.1766 770.735.3456 770.735.4017fax roystonllc.com
#10013660 ©Royston LLC. All rights reserved. 061616
Lower Base Shelves (D) onto Base.
4.
5.
ADDING TOP CAP:
Insert Top Cap (F) into locking tabs
on either end of the frame.
SHELVES:
Shelves can be added at either
a right angle or 15 degree tilt.
3. ADDING KICKPLATES AND BASE SHELVES:
Hook Kickplates (A) onto tabs on Wings (C) as shown.
C
B
L
F
A
D
Locking
Tabs
Once Kickplates (A) are in place, insert
tabs on Base Shelves (D) into the first
slots on Uprights (B).
Insert Plugs (L ) into each
Upright (B), and push
completely down.
MODULAR MERCHANDISING ASSEMBLY: “T” UNIT
