Rosslare Multi-Smart AY-K35 Manuel d'utilisation

1. Introduction

The innovative Multi-Smart™ Readers from Rosslare support multiple technologies: BLE(Bluetooth Low Energy), NFC,

125kHz and 13.56MHzRFID. Multi-technology Multi-Smart™ Readers are especially suited for sites that need more

than one RFID credential or use more than one CSN Select credential. The readers supports ASK and FSK for 125kHz

and 13.56MHz smartcards to read the RFID transponder UID and output the ID to the control panel. The reading

capability includes sector read at 13.56 MHz. This feature supports all RFID types in one reader without updating

legacy credentials in the system.

The Multi-Smart™ Readers read Rosslare BLE-ID™ and NFC-ID™ credentials generated by the BLE-ID™ mobile app or

the mobile credentials SDK that run on a user's iOS or Android smartphone. The BLE-Admin™ app can configure which

technologies are used by each reader.

The readers support SIA Open Supervised Device Protocol (OSDP V2) including SCP mode (Secured Channel

Protocol), allowing readers to connect to any controller that supports OSDP.

The readers also have a capacitive touch button on the surface which can be assigned functions such as DoorBell,

Exit, Help, Lights or other required outputs.

With simple installation, the readers allow you to easily manage add-ons installations and technology migrations. They

come in a modern small model that fit any architecture design, and are suitable for outdoor use. In addition, they are CE

and FCC certified.

1.1. Installation Kit

The installation kit consists of the following items to be used during the installation procedure.

Description Quantity

Self-adhesive mounting label template 1

Flat screw M3.5 x 25 mm 2

Plastic anchor M6 x 30 mm 2

Torx tamper proof screwdriver 1

Torx screw M3 x 5 mm 1

Bell sticker 4

www.rosslaresecurity.com 1

Multi-Smart™ Readers

125kHz, 13.56MHz, Bluetooth®

and NFC

Installation & User Guide

2. Technical Specifications

Electrical Characteristics

Power Supply Type Regulated

Operating Voltage Range 8 to 16 VDC

Current @ 12 V Maximum: 300 mA @ 12 VDC

Bluetooth BLE Read Range* 12 m (39.3 ft) (line of sight)

RFID and NFC Read Range** Contactless: 13.56 MHz: 5 cm (1.97 in.), 125 kHz: 8 cm (20.32in.)

LED/Buzzer Controls Dry Contact, N.O.

Tamper Output / Touch Button

Output

Open collector, active low, max. sink current 20 mA @12 VDC, 10 mA@5VDC. Current

limit: 500Ω series resistance

Maximum Cable Distance to

Controller

Wiegand: 150 m (500 ft) with 18-AWG cable

OSDP (RS-485): 1,200 m (4,000 ft) with 2x2 18 AWG twisted shielded cable

Environmental Characteristics

Operating Environment IP68, UV-resistant, epoxy-potted, suitable for indoor and outdoor use

Operating Temp. Range -35°C to 66°C (-31°F to 150°F)

Operating Humidity Range 0% to 95% (non-condensing)

Vandal Resistance IK09

Antimicrobial efficacy Inhibits bacteria proliferation by up to 99.8%

Physical Characteristics

Dimensions (H x W x D) 88 x 48 x 24 mm (3.46 x 1.89 x 0.94 in.)

Weight 121 g (4.27 oz)

* Read range is different for different smartphones and also is affected by a variety of factors.

** Read range listed is statistical mean rounded to nearest centimeter, measured in open air using Rosslare MIFARE Classic EV1 (ISO card). Form factor, technology and

environmental conditions, including metallic mounting surface, can degrade read range performance; plastic spacers are recommended to improve performance on

metallic mounting surfaces.

3. Installation

3.1. Mounting the Multi-Smart™ Readers

When selecting an area for mounting, ensure the location is flat.

To mount Multi-Smart™ Readers:

1. Drill 2 holes in the wall, using the mounting template provided in the installation.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 2

2. Insert 2 anchors provided into the drilled holes.

3. Mount the bracket on the wall using the 2 screws provided.

4. Mount the reader on the bracket and fasten at bottom with Torx screw and Torx screwdriver provided.

3.2. Wiring the Multi-Smart™ Readers

To wire Multi-Smart™ Readers:

Units are supplied with a 11conductor 58cm (22.8in.) pigtail with exposed wires coated with solder.

•The individual wires from the reader are color coded according the Wiegand standard.

•When using a separate power supply for the reader, this supply and that of the controller must have a

common ground.

•The reader’s cable shield wire should be preferably attached to an earth ground, or a signal ground

connection at the panel, or power supply end of the cable.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 3

To connect the reader to the controller:

1. Select the appropriate connections according to the table below.

2. Prepare the controller cable by cutting its jacket back about 3 cm (1¼ in.) and strip the insulation from the wires

about 1.3 cm (½ in.).

3. Splice the reader’s pigtail wires to the corresponding controller wires and cover each joint with insulating tape.

4. If the tamper output is being utilized, connect the purple wire to the correct input on the controller.

5. Trim and insulate the ends of all unused conductors individually. Do not short any unused wires together.

Wire Color Function

Red Power

Black Ground

Green Data 0 / Data

White Data 1 / Clock

Orange Green LED Control

Brown Red LED Control

Purple Tamper Output

Yellow Buzzer Control

Blue RS-485 - A / OSDP

Gray RS-485 - B / OSDP

Pink Touch Button

Black (shrink) Shield

4. Configuration

1. Download the Rosslare BLE-Admin application from Google Play or Apple App Store using the following QR code.

2. Open the application, select the required reader from the list displayed.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 4

3. Enter the password.

•Use the default password (12345678) when you log in to the BLE-Admin application for the first time.

•It is highly recommended that you change the password (see step 4).

4. On the main screen, configure the following:

Option Remarks

Reader Name Assign name to selected door reader

Password Change password

5. Tap Set Configuration and configure the following:

Parameter Options Remarks

Protocol Wiegand, OSDP, OSDP-SC, Clock and Data

Wiegand: 26, 32, 34, 40, 56, 64 bit

26 bit (default)

Toggle to select Reverse

OSDP-SC: Install mode (read/write)

OSDP addresses: 0-31

13 (default)

Credentials reading

standards

125 KHz EM (ASK)

125 KHz (FSK)

ISO 14443A

ISO 14443B

ISO 15693

BLE Credential

You can select multiple credentials.

All standards are selected by default.

125KHz (FSK) supports

Wiegand 26, 32, 34, 35, 37,

40, 48 bit.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 5

Parameter Options Remarks

Sector Off, Key A. xxxxxx

Off (default)

Key A: Must type 12 character key in Hex

format

Location:

•1K card

•Sector [0-15]

•Block

-Sector 0, Blocks 1,2

-Sector 1-15, Blocks 0-2

•Byte [0-15] in each available block

•4K card

•Sector [0-39]

•Block

-Sector 0, Blocks 1,2

-Sector 1-31, Blocks 0-2

-Sector 32-39, Blocks 0-14

•Byte [0-15] in each available block

When a sector is activated,

the ISO14443A,

ISO14443B, and ISO18092

credential reading standards

are automatically set to OFF.

If necessary, select a

standard again.

General purpose

button

Activation

On/Off

If set to Off, the following are hidden:

•Set key as bell

•Keypad press duration

Set key as bell

•6-Bit Wiegand Rosslare format

(default)

•6-Bit Wiegand with Nibble + Parity Bits

•8-Bit Wiegand Nibble Complemented

•Single Key, 4-Bit Wiegand

Keypad press duration (seconds) 0.25, 0.5, 0.75, 1, 1.25, 1.5, 2

0.25 (default)

Light bar

Activation On/Off.

On (default)

Brightness level High, Medium, Low

Medium (default)

Buzzer Level Off, High, Medium, Low.

High (default)

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 6

4.1. Configuration Options

Tap the menu icon located at the top-right of the screen to do the following functions.

Option Remarks

Reset Reset the reader to the default settings.

email Email the reader configuration.

Export Export the reader configuration.

Import Import a reader configuration.

5. NFC and BLE Operation using Rosslare BLE-ID™ mobile app

5.1. Rosslare credential NFC-ID (Android)

Rosslare's NFC-ID read function for Multi-Smart™ Readers can read both active and passive NFC credentials. NFC-ID

can be generated from the Rosslare BLE-ID app or Mobile Credentials SDK for each NFC supported Android

smartphone.

The reader scans for NFC-ID and transmits the ID number to the host controller via OSDP or Wiegand protocols.

5.2. Rosslare BLE-ID credentials (Android and iOS)

The reader can read credentials from Rosslare BLE-ID app or Mobile Credentials SDK via Bluetooth.

The reader scans for BLE-ID and transmits the ID number to the host controller via OSDP or Wiegand protocols.

BLE-ID credentials have a line-of-sight range of up to 12 m (39 ft) from the reader depending on the type and brand of

smartphone or BLE device.

The BLE-ID application allows a mobile device to be used as a credential. Download the application from

Google Play or App Store using the following QR code.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 7

6. LED Operation

6.1. Normal Power Up

When power applied from OFF position, LED test will run for 1.5sec. (cycle all LED colors of the RGB for 500ms each

color in the following order: Red, Green, Blue), followed by 3 beeps.

6.2. Restore to Factory Defaults

The following procedure restores the reader to the factory version with the default settings.

1. Turn off the power to the reader.

2. Remove the reader from its mounted location to expose the tamper to light.

3. Connect the orange wire (green LED control) and yellow wire (Buzzer Control) to GND.

When the reset is complete, the LED will blink in the sequence green, yellow, green, yellow for two

seconds while the buzzer will operate.

4. Turn on the power to the reader and keep the orange wire and yellow wire to GND for four or more seconds.

When the restore to factory defaults procedure is complete, the reader it will have the factory firmware

version with the default settings.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 8

6.3. Standby Mode

In standby mode, two LED bars will be in steady RED condition.

EM 125 kHz and CSN 13.56 MHz Credential Read

When a 125 kHz credential or a 13.56 MHz credential is detected by the reader, both LED bars will flash GREEN for

250ms, and the reader will sound short beep for 300ms. This indicates a successful card read and transfer on the

Wiegand port. Then, the reader will return to standby mode and the right light bar stays solid RED.

7. Touch Button Operation

The General Purpose Button is located in the center of the reader.

Connect the pink wire to an available input of the controller.

The general purpose button is used to operate a bell or do other functions.

The general purpose has a LED. The LED comes on when the general purpose button is pushed. The LED stays on

until the button is released.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 9

8. Declaration of Conformity

FCC ID: GCD-AYK35

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the

user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

9. Radio Equipment Directive (RED)

Rosslare hereby declares that the Multi-Smart™ Readers are in compliance with essential requirements and other

relevant provisions of Directive 2014/53/EU.

Multi-Smart™ Readers Installation & User Guide

www.rosslaresecurity.com 10

Table des matières

Autres manuels Rosslare Lecteur de cartes

Rosslare

Rosslare AY-K6255 Manuel utilisateur

Rosslare

Rosslare AY-x25B Series Manuel utilisateur

Rosslare

Rosslare AY-U9**BT series Manuel d'utilisation

Rosslare

Rosslare AY-x20 Series Manuel utilisateur

Rosslare

Rosslare Mifare CP-R25 Instructions de montage

Rosslare

Rosslare AY-U910 Manuel utilisateur

Rosslare

Rosslare AY-R12 Manuel utilisateur

Rosslare

Rosslare AYC-F60 Series Instructions de montage

Rosslare

Rosslare AY-B8620 Manuel utilisateur

Rosslare

Rosslare MIFARE AY-T6350 Instructions de montage

Rosslare

Rosslare CSN SELECT AYC-6355 Series Manuel utilisateur

Rosslare

Rosslare AY-Z12A Manuel utilisateur

Rosslare

Rosslare DR-12C Manuel utilisateur

Rosslare

Rosslare Anti-Vandal MIFARE AY-Q6 60 Series Manuel utilisateur

Rosslare

Rosslare AY-Q12 Instructions originales

Rosslare

Rosslare AY-K6255 Manuel utilisateur

Rosslare

Rosslare AY-Z12 Manuel utilisateur

Rosslare

Rosslare DR-U955BT Manuel utilisateur

Rosslare

Rosslare MIFARE Classic AY 5B Series Manuel utilisateur

Rosslare

Rosslare DR-12C Manuel utilisateur

Rosslare

Rosslare CSN SMART AY-H6355BT Manuel utilisateur

Rosslare

Rosslare AY-U920BT-US Manuel utilisateur

Rosslare

Rosslare DR-U955BT Manuel utilisateur

Rosslare

Rosslare DR-6280 Manuel utilisateur

Manuels Lecteur de cartes populaires d'autres marques

Lindy

Lindy 43185 Manuel utilisateur

Lindy

Lindy 43185 Manuel utilisateur

ViziT

ViziT RD-4F Manuel utilisateur

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Manuel utilisateur

AVID ID

AVID ID AVID1043 Manuel utilisateur

Conrad

Conrad PCMCIA Manuel utilisateur

Lindy

Lindy 51541 Manuel utilisateur

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Manuel utilisateur

Johnson Controls

Johnson Controls Kantech tyco ioSmart Manuel utilisateur

ACS

ACS ACR122L Manuel utilisateur

Secukey

Secukey S2-MF Manuel utilisateur

Elecom

Elecom MR-SMC07 series Manuel utilisateur

Alien

Alien ALR-9800 Manuel utilisateur

ACS

ACS ACR310 Manuel utilisateur

Datamars

Datamars R-IN1300 MID Manuel utilisateur

Alarm Lock

Alarm Lock AL-PRE2 Manuel utilisateur

xpr

xpr B100PROX-AH Guide de l'utilisateur

SimpleTech

SimpleTech FlashLink Manuel utilisateur
