ROSE DISPLAYS ANOCONNECTOR WITH ANOQUICK Manuel utilisateur

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instructions for Hanging

Step 1

Push one AnoConnector into one end of first

AnoQuick rail. Be sure to start with single barb

side of the AnoConnector going into rail first.

Push in until it stops at the middle barb. Fig. 1

Note: The AnoConnector can also be used to

connect lengths of AnoGotcha and AnoMulti.

Step 2

Repeat with second AnoConnector going into

back slot of first AnoQuick rail. Fig. 2

Step 3

Push second AnoQuick holder onto first assembly.

Fig. 3

Instruction Sheet

AnoConnectorTM

Important note:

It is very important to insert single barb side first.

The middle barb acts as a stop for the AnoQuick

rail.

Instructions for Hanging

Incept-9.9.02

The AnoConnectorTM is a trademark of Rose Displays, Ltd.

Neither the manufacturer nor any sales agent may be held

liable for injury, loss or damage resulting from the use of

these products.

Part #02INSAnoConnector

AnoConnectors

06-2930

AnoQuick

12A300

Figure 1

Figure 3

Figure 2

Parts

Instructions for Hanging

Step 1

Push one AnoConnector into one end of first

AnoQuick rail. Be sure to start with single barb

side of the AnoConnector going into rail first.

Push in until it stops at the middle barb. Fig. 1

Note: The AnoConnector can also be used to

connect lengths of AnoGotcha and AnoMulti.

Step 2

Repeat with second AnoConnector going into

back slot of first AnoQuick rail. Fig. 2

Step 3

Push second AnoQuick holder onto first assembly.

Fig. 3

Instruction Sheet

AnoConnectorTM

Important note:

It is very important to insert single barb side first.

The middle barb acts as a stop for the AnoQuick

rail.

Instructions for Hanging

Incept-9.6.02

The AnoConnectorTM is a trademark of Rose Displays, Ltd.

Neither the manufacturer nor any sales agent may be held

liable for injury, loss or damage resulting from the use of

these products.

Part #02INSAnoConnector

AnoConnectors

06-2930

AnoQuick

12A300

Figure 1

Figure 3

Figure 2
