Rocktron REPLITONE MP Manuel utilisateur

MANUAL

Digital Modeling Preamp

May be covered by one or more of the following: U.S. Patents #4538297, 4647876, 4696044, 4745309, 4881047,

4893099, 5124657, 5263091, 5268527, 5319713, 5333201, 5402498 and 5493617.

Other patents pending. Foreign patents pending.

16 Amplifier Emulations

Direct Recording Capabilities

128 User Programable Presets Available

HUSH Noise Reduction

Rocktron's Hallmark Effects

Reverb, Delay, HUSH, & one additional

effect available at all times!

Suggested Footcontroller(s) - Rocktron MIDI Mate, Rocktron MIDI I.T.

or Rocktron All Access.

Suggested MIDI Cable(s) - Rocktron M7 Pin MIDI Cable Model #

RMM900

Suggested Power Amplifier(s) - Rocktron Velocity 100 (2x50 Watt)

Suggested Speaker Cabinets(s) - Rocktron Velocity S112 (1x12 cabs)



Your Rocktron RepliTone MP preamp has been tested and complies with the following

Standards and Directives as set forth by the European Union:

Standard(s): IEC60065 Professional Audio/Video or Similar

Equipment, EN55013:1997, EN61000-3-2 (1995)

EN61000-3-3(1995), EN55020:1995, CSA E65-94

This means that this product has been designed to meet stringent guidelines on how much RF

energy it can emit, and that it should be immune from other sources of interference when

properly used. Improper use of this equipment could result in increased RF emissions, which may

or may not interfere with other electronic products.

To insure against this possibility, always use good shielded cables for all audio input connections.

This will help insure compliance with the Directive(s).



Contents

1. Introduction to the RepliTone MP.................................... 4

2. RepliTone MP Quick Start ................................................ 5

3. RepliTone Models ............................................................... 5

4. Precautions .......................................................................... 6

5. RepliTone Emulations ........................................................ 7

6. Front Panel .......................................................................... 8

7. Rear Panel ......................................................................... 10

8. MIDI Implementation ...................................................... 12

9. PC Interface ..................................................................... 15

10. Effects .............................................................................. 16

11. Connections ..................................................................... 19

12. Specifications................................................................... 23

13. Other Rocktron Products............................................... 24

1. Introduction to the RepliTone MP

The Rocktron RepliTone MP is a 24-bit DSP professional guitar preamp & direct recording

device containing 16 different amp emulation models and 128 user programmable presets (15 user

presets on the front panel with a total of 128 presets available via a Rocktron MIDI footcontroller).

The RepliTone MP also offers effect algorithms and superb sound quality. Full MIDI implementation

and a user-friendly operating format ensure that designing unique and useful preset sounds is as

simple as possible.

In addition, the RepliTone MP also features:

•Advanced Speaker Simulation, which provides a strikingly realistic

approximation of a miked speaker cabinet at line-level specifically for

"direct recording", and mixer input to play directly over a PA system or

headphonelistening.

•Rocktron's patented HUSH®noise reduction provides noise reduc-

tion while playing and complete silence when not.

•High-quality digital effects, including:

- Reverb - Phaser

- Tremolo (1 & 2) - Flanger

- Detune - Compression

- Chorus - Delay

- Wah - Rotary

•Effects Loop, MIDI In Out/Thru with Phantom Power for MIDI

Footcontroller

•Suggested Power Amplifier - Rocktron Velocity 100 (2x50Watt

Single Space Rack Mount Power Amp)

•Suggested Footcontrollers - Rocktron MIDI Mate, Rocktron MIDI

I.T. or Rocktron All Access

For a thorough explanation of the RepliTone MP and its features, please read this manual care-

fully and keep it for future reference. After removing the RepliTone MP from the box, save all pack-

ing materials in case it becomes necessary to ship the unit.

NOTE: Product and manufacturer names are trademarks of their respective owners and

are in no way associated with Rocktron. The names are mentioned solely for the purpose of

describing certain amplifier tones and emulations produced by the RepliTone MP.



Turn the MASTER VOLUME control all the way down on the RepliTone

MP and Power Amp.

Using high quality 1/4" guitar cables (standard guitar cables are OK)

connection the RepliTone MP to Power amp as such:

-RepliTone MP Left Pre-amp "OUT" to - "IN" on the Power Amp

-RepliTone MP Right Pre-amp "OUT" to - "IN" on the Power Amp"

Plug the supplied power adapter into the AC INPUT socket on the rear

panel, and plug the other end into an AC wall socket.

Connect your guitar to the INPUT jack.

Press the POWER button on the RepliTone MP and then power on the

Power amp.

Select a PRESET position (or MANUAL).

Select an AMP Model.

Set the GAIN and LEVEL controls to your taste. Adjust the Master

Volume on the RepliTone MP and on the Power Amp to a comfortable

level. Set the BASS, MID, and TREBLE.

Set the EFFECTS SELECT knob to the desired Effect and modify as

needed with the EFFECTS ADJUST control.

Play!

RepliTone MP Quick Start

Modeling Preamp - Stereo - Single Rack Space Preamp with Multi-effects and amp

models. The HEADPHONES and LOOP SEND/RETURN jacks are stereo.

Mono, 60 watt combo amp with a single 12 inch speaker. The HEADPHONES

and LOOP SEND/RETURN jacks are stereo.

Stereo, 100 watt combo amp with two 12 inch speakers. The

HEADPHONES and LOOP SEND/RETURN jacks are stereo.

1 x 12

2 x 12

Available RepliTone Products3.

NOTE: IT IS VERY IMPORTANT THAT YOU READ THIS SECTION TO PROVIDE

YEARS OF TROUBLE FREE USE. THIS UNIT REQUIRES CAREFUL HANDLING.

• All warnings on this equipment and in the operating instructions should be

adhered to and all operating instructions should be followed.

• Do not use this equipment near water. Care should be taken so that objects do

not fall and liquids are not spilled into the unit through any openings.

• The power cord should be unplugged from the outlet when left unused for a

long period of time.

DO NOT ATTEMPT TO SERVICE THIS EQUIPMENT. THIS EQUIPMENT SHOULD

BE SERVICED BY QUALIFIED PERSONNEL ONLY. DO NOT MAKE ANY INTERNAL

ADJUSTMENTS OR ADDITIONS TO THIS EQUIPMENT AT ANY TIME. DO NOT

TAMPER WITH INTERNAL ELECTRONIC COMPONENTS AT ANY TIME. FAILURE

TO FOLLOW THESE INSTRUCTIONS MAY VOID THE WARRANTY OF THIS

EQUIPMENT, AS WELL AS CAUSING SHOCK HAZARD.

OPERATING TEMPERATURE

Do not expose this unit to excessive heat. This unit is designed to operate between 32° F and

104° F (0° C and 40° C). This unit may not function properly under extreme temperatures.

4. Precautions

Note: Fender, Marshall, Vox, Boogie and other amplifier model designations are all trade-

marks of their respective owners and are not associated or affiliated with Rocktron. The names are

used solely to describe the amplifier tones produced using the RepliTone's emulating software.

AmpEmulation Name Original Amp Name

BRIT CLASS A VOX AC30

BRIT BLUES MarshallBluesbreaker

BRIT CLASSIC Marshall Plexi 100W into 1960A 4 x 12 Cabinet

BRIT HI GAIN Marshall JCM 800 into 1960A 4 x 12 Cabinet

HI GAIN Rocktron Prophesy Channel 3

MEGA GAIN Rocktron Vendetta VP4 Channel 4

THRASH Voodu Valve High Gain, with mid scoop

GRUNGE MEGA GAIN but with LF boost on pre-EQ

FUZZ Dallas-ArbiterFuzzface

70's Mesa Boogie Mk llB

TEXAS Rocktron Vendetta Head Channel 2

BLUES Fender '65 Deluxe Reverb

TWEED Fender '59 Bassman 4 x 10

POLY JAZZ "Inspired" by a Polytone

CLEAN 2 Fender Twin with Bright switch ON

CLEAN 1 Fender Twin Reverb

RepliTone MP Emulations5.

6. Front Panel

POWER switch

On/Off switch - Note: when powering up your rack be sure to turn all preamps and effects on first before

you turn on your power amp. When powering down your rack set up always turn the power amp off first.

INPUT jack

This ¼" jack accepts the output from the guitar.

MASTER VOLUME

Controls overall output level of the amp and also headphone volume.

PRESET switch

Selects one of 16 channels, as desired. MANUAL position uses all current control positions to determine

sound as opposed to stored values. These correspond to MIDI program change numbers 1 - 15. 113 more

user presets are accessible only via MIDI program changes (16 - 128).

AMP select switch

Selects one of 16 available Amp Emulations.

STORE/EXECUTE Button and LED

This button is used to store values into the RepliTone's presets when settings are altered - see "Storing

Changed Preset Parameters" for more information on this procedure.

GAIN control

Adjusts the amount of drive. Higher settings increase distortion and sustain.

RECALL LEDS

Allows you to get back to your "original" setting. Whenever a knob is turned (even just slightly) these

LEDs will light. To get back to the "original" setting (not the knob position - but the actual setting of the

control) start turning the knob you changed. When the LEDs go "out" the knob is at its original (or

stored) setting. If you pass the original setting and only one LED is lit, turn the knob in the direction of

the arrow. For example:

Left LED is Lit:

Turn the knob slowly to the right until both LEDs are out.

Turn the knob slowly to the left until both LEDs are out.

LEVEL CONTROL

Controls the relative volume level of the preset (or channel). Used to balance between two different

sounds.

BASS, MID and TREBLE controls

The BASS, MID and TREBLE controls are like any standard guitar amp. Levels are adjusted over the

ranges appropriate for the amp emulation selected.

REVERB LEVEL control

Adjusts the amount of reverb. (Reverb is always available.)

213

1316

DELAY LEVEL control

Adjusts the overall level of the delayed signal at the output relative to the direct signal and other effect

signals. (Delay is always available.)

DELAY TIME button and LED

Adjusts the current delay time. To set the delay time, tap the button twice at the interval desired (up to

one second). The LED flashes to indicate the set time. For the longest delay time tap button only once.

EFFECT ADJUST control

Adjusts one effect parameter, depending upon the effect selected (see Effect Select Control section (16)

for more detailed information).

EFFECT SELECT EFFECT ADJUST knob controls.

Chorus Depth Depth of Chorus

Chorus Level Level of Chorus

Flanger Depth Depth of Flanger

Flanger Res Resonance of Flanger

Delay Regen Regeneration of Delay

Delay Pan Pan of delay - knob turned full left - delay is on left

knob turned full right - delay is on right.

Detune Pitch Amount of Detune Pitch

Detune Level Level of Detune Pitch

Bypass Nothing

HUSH Threshold (HUSH is always active)

Compressor Threshold

Wah Frequency of Wah - knob sets only the one

frequency - but you can use an expression pedal to

get the wah wah effect

Rotary Slow Speed of Rotary

Phaser Depth of Phaser

Tremolo 1 Depth of Tremolo 1

Tremolo 2 Depth of Tremolo 2

RATE button & LED

Sets the modulation rate of the selected effect. To set, press the button twice at the rate you want. The

LED flashes to indicate the setting. When the Rotary effect is selected, tap the button once to change

between the two rates. To set the slowest rate tap the button just once.

EFFECT SELECT control

Selects one of the available effects and selects which parameter is controlled with the EFFECT ADJUST

control.

Chorus Depth Bypass

Chorus Level Hush

Flanger Depth Compressor

Flanger Res Wah

Delay Regen Rotary

Delay Pan Phaser

Detune Pitch Tremolo 1 (Sine wave modulation)

Detune Level Tremolo 2 (Square wave modulation)

7. Rear Panel

PRE-AMP OUT (To Power Amp)

Jacks for connection to a power amp (we suggest the Rocktron Velocity 100 power amp

- 2x50 watts - stereo). These are stereo output jacks that should be connected to a

power amp input.

MIDI THRU/OUT

This standard 5-pin DIN connector can be connected to the MIDI IN jack of another

device via a standard MIDI cable. There are limitations to the number of devices that

can be chained (or series connected) in this fashion.

NOTE: There is a limit to the number of devices which can be chained together

(connected in series). With more than three devices, a slight distortion of the MIDI

signal can occur (due to signal degradation) which can cause an error in MIDI signal

transmission. Should this problem arise, a MIDI Thru box can be used which connects

directly to the MIDI device. The MIDI Thru box transmits MIDI information through

multiple connectors to the devices receiving MIDI. MIDI cables should not exceed 50

feet (15 meters) in length.

MIDI IN and Suggested Footcontrollers

This 7-pin DIN connector is specially designed to receive MIDI program changes from a

Rocktron MIDI Footcontroller and to provide phantom power to that controller.

Although, you may use a standard 5-pin MIDI cable and any MIDI footcontroller to run

this unit, we suggest that you use the Rocktron RMM900 MIDI Cable and the Rocktron

MIDI Mate or MIDI I.T. footcontrollers (available at your Rocktron dealer). We have

designed the RepliTone MP to have a 7-pin Din connector where Pins 6 & 7 carry

phantom power to a Rocktron MIDI Mate or MIDI I.T. footcontroller. Using this set up

you can power your footcontroller directly from the RepliTone MP thus eliminating the

need to plug in your footcontroller on stage. This will eliminate additional wires and

cables from the front of the stage.

This connector must be connected to the MIDI OUT jack of the transmitting MIDI

device via the Rocktron RMM900 7-pin DIN MIDI cable or a standard 5 -pin MIDI

cable, or the MIDI THRU jack of the preceding device (if this unit is within a chain of

MIDI devices).

Table des matières

Autres manuels Rocktron Amplificateur

Rocktron

Rocktron Taboo ARTIST Manuel utilisateur

Rocktron

Rocktron Velocity V30R Manuel utilisateur

Rocktron

Rocktron CHAMELEON Manuel utilisateur

Rocktron

Rocktron Velocity V30D Manuel utilisateur

Rocktron

Rocktron VOODU Valve Manuel utilisateur

Rocktron

Rocktron Vendetta Manuel utilisateur

Rocktron

Rocktron PIRANHA Manuel utilisateur

Rocktron

Rocktron PROGAP ULTRA Manuel utilisateur

Rocktron

Rocktron Widowmaker Manuel utilisateur

Rocktron

Rocktron Gainiac 2 Manuel utilisateur

Rocktron

Rocktron Bass 200 Manuel utilisateur

Rocktron

Rocktron Velocity 300 Manuel utilisateur

Rocktron

Rocktron Vendetta VP4 Manuel utilisateur

Rocktron

Rocktron Velocity 100LTD Manuel utilisateur

Rocktron

Rocktron PRO G.A.P. Manuel utilisateur

Rocktron

Rocktron R112 Manuel utilisateur

Rocktron

Rocktron RA30DSP Manuel utilisateur

Rocktron

Rocktron Velocity V30R Manuel utilisateur

Rocktron

Rocktron Blue Thunder Manuel utilisateur

Rocktron

Rocktron ValveSonic Black Plate+ Manuel utilisateur

Rocktron

Rocktron Velocity 100 Manuel utilisateur

Rocktron

Rocktron Rampage Bass 15 Manuel utilisateur

Rocktron

Rocktron RA50DSP Manuel utilisateur

Rocktron

Rocktron VooDu Valve Online Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur
