1

Programming Q uick Guide

iLS6300VBU/iLS6300VB

Connecting the Scanner

Be sure that PC is turned OFF, before Connect scanner cable to the

PC USB port on the PC as below described, Ensure that all connections

are ready, and turn on your PC.

1. Please switch ON and charge scanner for 4~5 hours at first time before

use. Scanner switch shown on Fig. 2.

2. After switch ON, the Orange LED will flash following with 3

beep-sounds. The RED LED will be OFF while it links to cradle within

2.4GHz radio range.

3. If RED LED is continual ON, please re-plug USB cable, then, scan the 3

barcodes on the bottom of cradle sequentially. (Shown on Fig. 3 from

1 to 3). If you are unable to complete this setting within 1 minute,

please re-plug USB cable & re-start the scanner, and try again.

4. Charging issue: Cradle works as charger when putting scanner on it.

Even if the scanner's battery is full, the cradle will continue to supply

power to the scanner. We suggest you to remove scanner from cradle

when scanner is charged fully

*Note: Please install PL-2303 driver for iLS6300VB

LED Indicator Information

Orange LED ON

Full charged

Orange LED Flashing

Charging / Low battery

Red LED ON

Offline / out of service

Green LED ON

Good read

Remark:

*When the battery power is too low, the Orange LED will flash and beep once.

Scanner should be charged immediately.

*If scanner shuts down it is recommended to charge it fully before turning it back

on.

*Under power-saving mode, there will not be LED indication when charging.

Reset Configuration to Defaults

(scan from A1 to A8 for iLS6300FBU or B1 to B7 for iLS6300FB)

iLS6300VBU

iLS6300VB

A1

Demo

W010F01

B1

Demo

W010F01

A2

Demo

WFFD980

B2

Demo

WFFD980

A3

Demo

W010F01

B3

Demo

W010F01

A4

Demo

WFFD9C3

B4

Demo

WFF115D

A5

Demo

WFF115D

B5

W306A20

A6

W306A20

B6

Demo

W010F00

A7

Demo

W010F00

B7

Demo

%D%F%T

A8

Demo

%D%F%T

*Note: Please install PL-2303 driver for iLS6300VB

Trigger Mode

Demo

%R%T%E

Trigger always

(Trigger available at any time)

Demo

%R%T%D

Trigger standard (Default)

(Trigger available, after data sent to the device)

Transmission Speed

Transmission speed is dependent on your device. In order not to lose

data, please choose the correct speed. Middle-speed is the Default.

Demo

%B%T%H

Demo

.

High-speed

Ultra Slow-speed

Transmission

1transmission

Demo

.

Demo

.

Middle-speed

Ultra Slow-speed

Transmission

(Default)

2transmission

Demo

%B%T%L

Demo

.

Slow-speed

Ultra Slow-speed

Transmission

3transmission

Bluetooth Auto-connection

Demo

%A%L%E

Bluetooth Auto-connection ON:

When out of range, it will keep trying to

connect to device, scanner will not enter

power-saving mode.

Demo

%A%L%D

Bluetooth Auto-connection OFF:

When you are out of BT signal range, scanner

will stop sending auto-connection signal to

device after 2 minutes. During this time, it will

not enter power-saving mode. Once you are

back within range, press trigger to connect to the

device. (Default)

2

Keyboard Country(For USB HID only)

Scan the appropriate country code as below to program the keyboard

layout for your country or language. As a general rule, the following

characters are supported, but need special care for countries other

than the United States: @ | $ # { } [ ] = / ‘ \ < > ~

%+-$.00

%+-$.06

USA

(Original setting)

Italian

%+-$.01

%+-$.07

Norway

France

%+-$.02

%+-$.08

Germany

Vietnam

%+-$.03

%+-$.09

Sweden

Spain

%+-$.04

%+-$.10

Denmark

Portugal

%+-$.05

%+-$.11

Switzerland (F)

Hungary

%+-$.12

%+-$.18

Latin America

Icelandic

%+-$.13

%+-$.19

Brazil

Poland

%+-$.14

%+-$.20

Belgium

Turkey F

%+-$.15

%+-$.21

Bulgarian Latin

Turkey Q

%+-$.16

%+-$.22

Finland

Japan

%+-$.17

%+-$.23

Netherlands

Korea

%+-$.24

%+-$.26

Thai

Russia

%+-$.25

Switzerland German

*The different keyboard language option starts from June. 2017.

Power-saving Mode

Demo

%P%D%T00

Power-saving mode OFF

Demo

%P%D%T03

Power-saving mode ON (Default):

Enter power-saving mode after 3-minute inactivity.

This function converses battery power. When you

press "SCAN/Power ON" button, it will wake up and

begin to scan.

Demo

%P%D%T10

Power-saving mode ON:

Enter power-saving mode after 10-minute

inactivity. This function converses battery power.

When you press "SCAN/Power ON" button, it will

wake up and begin to scan.

*When charging, the scanner will not enter power-saving mode

automatically

How to append a “prefix” or a “suffix” to the

barcode data

Demo

%C%P%S

Demo

%C%S%S

prefix

suffix

1. Scan above configuration code for Prefix or Suffix

2. Enter the required values (right, numeric barcode) for Prefix or

Suffix using the hex values for the desired HEX values from “Prefix

& Suffix TABLE (blew page)”

3. Then, end by scanning Code X (below, right)

*The max. of special characters is 5.

*When you append 1~4 required values for Prefix or Suffix, it must

end with Code X.

*It doesn’t need Code X, if you append 5 values to barcode data.

How to delete Prefix or Suffix

1. Scan above configuration code for Prefix or Suffix

2. Enter the “0” “0” (above, right)

3. Then end by scanning Code X (below, right)

Numeric barcode for settings

Demo

0

Demo

6

Demo

C

Demo

1

Demo

7

Demo

D

Demo

2

Demo

8

Demo

E

Demo

3

Demo

9

www.tec-it.com

F

Demo

4

Demo

A

Demo

5

Demo

B

Demo

X

3

Prefix & Suffix TABLE

HEX

HID

(SPP)

HEX

HID

(SPP)

HEX

HEX

HEX

HEX

01

CTRL A

(SOH)

19

CTRL Y

(EM)

20

SPACE

38

8

50

P

68

h

02

CTRL B

(STX)

1A

CTRL

Z(SUB)

21

!

39

9

51

Q

69

i

03

CTRL C

(ETX)

1B

ESC

(ESC)

22

"

3A

:

52

R

6A

j

04

CTRL D

(EOT)

1C

CTRL \

(FS)

23

#

3B

;

53

S

6B

k

05

CTRL E

(ENQ)

1D

CTRL ]

(GS)

24

$

3C

<

54

T

6C

l

06

CTRL F

(ACK)

1E

CTRL ^

(RS)

25

%

3D

=

55

U

6D

m

07

CTRL G

(BEL)

1F

CTRL _

(US)

26

&

3E

>

56

V

6E

n

08

Backspace

(BS)

27

'

3F

?

57

W

6F

o

09

Tab

(HT)

28

(

40

@

58

X

70

p

0A

CTRL J

(LF)

29

)

41

A

59

Y

71

q

0B

CTRL K

(VT)

2A

*

42

B

5A

Z

72

r

0C

CTRL L

(FF)

2B

+

43

C

5B

[

73

s

0D

Enter

(CR)

2C

,

44

D

5C

\

74

t

0E

CTRL N

(SO)

2D

-

45

E

5D

]

75

u

0F

CTRL O

(SI)

2E

.

46

F

5E

^

76

v

10

CTRL P

(DLE)

2F

/

47

G

5F

_

77

w

11

CTRL Q

(DC1)

30

0

48

H

60

`

78

x

12

CTRL R

(DC2)

31

1

49

I

61

a

79

y

13

CTRL S

(DC3)

32

2

4A

J

62

b

7A

z

14

CTRL T

(DC4)

33

3

4B

K

63

c

7B

{

15

CTRL U

(NAK)

34

4

4C

L

64

d

7C

|

16

CTRL V

(SYN)

35

5

4D

M

65

e

7D

}

17

CTRL W

(ETB)

36

6

4E

N

66

f

7E

~

18

CTRL X

(CAN)

37

7

4F

O

67

g

Barcode Configuration Method:

(Flow chart for setup procedure :)

W010F01

W010F00

Start

Configuration

End

Configuration

1D Symbologies –1

ENABLE

CODE 39

DISABLE

Demo

.

Demo

.

ENABLE

GS1-128

UCC/EAN-128

DISABLE

Demo

.

Demo

.

ENABLE

EAN8

DISABLE

Demo

.

Demo

.

ENABLE

EAN-13

DISABLE

Demo

.

www.tec-it.com

.

1D Symbologies –2

ENABLE

CODE 93

DISABLE

Demo

.

Demo

.

ENABLE

CODE 11

DISABLE

Demo

.

Demo

.

ENABLE

ISSN

DISABLE

Demo

.

Demo

.

ENABLE

ISBN

DISABLE

Demo

.

Demo

.

ENABLE

UPC-E

DISABLE

Demo

.

Demo

.

ENABLE

UPC-A

DISABLE

Demo

.

Demo

.

ENABLE

Interleaved

25

DISABLE

Demo

.

Demo

.

ENABLE

Matrix 25

DISABLE

www.tec-it.com

.

Demo

.

ENABLE

Industrial 25

DISABLE

Demo

.

Demo

.

4

Barcode Configuration Method:

(Flow chart for setup procedure :)

W010F01

W010F00

Start

Configuration

End

Configuration

1D Symbologies –3

ENABLE

GS1-Databar

(RSS)

DISABLE

w w w .tec-it.com

.

Demo

.

ENABLE

GS1-Databar

(RSS-Limited)

DISABLE

Demo

.

Demo

.

ENABLE

GS1-Databar

(RSS-Expand)

DISABLE

Demo

.

Demo

.

ENABLE

MSI

DISABLE

Demo

.

Demo

.

ENABLE

CODABAR

DISABLE

www.tec-it.com

.

Demo

.

Quick guide is subject to change without notice.

R_180808_01
