Rinnai E75CN Mode d’emploi

8W.52.6001/08.10 Changes reserved

High efciency condensing gas boiler

E75CN / E110CN

E75CP / E110CP

Notice! This manual must be retained for future reference.

Address: 103 International Drive, Peachtree City, GA, 30269

Toll-free: 1-800-621-9419 • Fax: 678-829-1666 • www.rinnai.us

User information manual

WARNING!

Installation and service must be

performed by a qualied installer,

service agency or the gas supplier.

- Do not store or use gasoline or other ammable

vapors and liquids in the vicinity of this or any other

appliance.

- WHAT TO DO IF YOU SMELL GAS

- Do NOT try to light any appliance.

- Do NOT touch any electrical switch.

- Do NOT use any phone in your building.

- Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

- If you cannot reach your gas supplier, call the re

WARNING!

If you do not follow these instructions exactly, a re or

explosion may result causing property damage, personal

injury or loss of life.

Français: voir page 17

Operating instructions Rinnai E-Series

Contents of instructions

These instructions contain important information for the safe use of Rinnai

E-Series gas boilers.

These user instructions are intended for the owner or responsible tenant of

the premises where the boiler is installed.

Subject to technical changes

Changes may be made to the illustrations, process steps and technical data

as a result of our policy of continuous improvement without prior notice.

Updating of documentation

Please contact us if you have any suggestions for improvements or

corrections.

Find our contact details on the back of this manual.

Operating instructions Rinnai E-Series

Please observe these instructions in the interest

of your own safety.

Safety and general instructions

The boiler is designed to heat water for a central

heating system and, if applicable, generating

domestic hot water. The boiler is delivered with

a burner controller pre-installed.The boiler can

be tted with a modulating outdoor reset control

ARV12 (included), a room controller RS100

(optional), a zone controller (optional) or an

On/Off thermostat or relay panel end switch

(accessories).

Designated use

Hazard denitions

The following dened terms are used throughout

the documentation to bring attention to the

presence of hazards of various risk levels.

Notices give important information concerning the

operation of the product.

DANGER:

Indicates the presence of hazards that

will cause severe personal injury, death or

substantial property damage.

WARNING:

Indicates the presence of hazards that

can cause severe personal injury, death or

substantial property damage.

CAUTION:

Indicates presence of hazards that will or

can cause minor personal injury or property

damage.

NOTICE:

Indicates special instructions on installation,

operation or maintenance that are important

but not related to personal injury or property

damage.

CAUTION

WARNING

NOTICE

DANGER

Operating instructions Rinnai E-Series

These operating instructions describe the

operation of the Rinnai E-Series condensing

gas boilers. This manual is for the end user. For

installation and servicing there is a installation &

servicing instructions manual for the installer.

Read this manual fully before operating the boiler.

In case of doubt or errors contact your installer.

The manufacturer reserves the right to change

the specications and dimensions without prior

notice.

Work on the boiler must be carried out by a State

licenced contractor, (Ref: Gas Safety Installation

and Use ) using correctly calibrated instruments

with current test certication.

Operating instructions Rinnai E-Series

Safety

FOR YOUR SAFETY READ BEFORE OPERATING

WARNING: If you do not follow these instructions

exactly, a ﬁre or explosion may result causing

property damage, personal injury or loss of life.

8U.34.01.00 / 05.09

A. This appliance does not have a pilot. It is equipped with an ignition device which automatically

lights the burner. Do NOT try to light the burner by hand.

B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the ﬂoor

because some gas is heavier than air and will settle on the ﬂoor.

WHAT TO DO IF YOU SMELL GAS

- Do NOT try to light any appliance.

- Do NOT touch any electrical switch.

- Do NOT use any phone in your building.

- Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

- If you cannot reach your gas supplier, call the ﬁre department.

C. Use only your hand to push in or turn the gas control knob. Never use tools.

If the knob will not push in or turn by hand, don’t try to repair it, call a qualiﬁed service technician.

Force or attempted repair may result in a ﬁre or explosion.

D. Do not use this appliance if any parts have been under water. Immediately call a qualiﬁed service

technician to inspect the appliance and to replace any part of the control system and any gas

control which has been under water.

OPERATING INSTRUCTIONS

1. STOP! Read the safety information above this label.

2. Turn off al electrical power of the appliance.

3. Set the thermostat or other operating control to the lowest setting.

4. This appliance is equipped with an ignition device

which automatically lights the burner.

Do NOT try to light the burner by hand.

5. Close main gas shut off valve.

6. Wait (5) minutes to clear out any gas. Then smell for

gas. Including near the ﬂoor.

If you smell gas, STOP! Follow “B” in the safety

information above on this label.

If you don’t smell gas, go to the next step.

7. Open main shut off valve.

8. Set the thermostat or other operation control to desired setting.

9. Turn on all electric power to the appliance.

10. If the appliance will not operate, follow the instructions “To Turn Off Gas To Appliance” and call your

service technician or gas supplier.

TO TURN OFF GAS TO APPLIANCE

1. Turn off all electric power to the appliance if service is to be performed.

2. Set the thermostat or other operating control to the lowest setting.

3. Close main gas shut off valve.

Manual Gas Valve (Main valve)

OPEN

Operating instructions Rinnai E-Series

Should overheating occur or the gas supply

fail to shut off, do not turn off or disconnect

the electrical supply to the pump. Instead, shut

off the gas supply at a location external to the

appliance.

Protection for corrosion

Do not use any sprays, chlorine containing agents,

solvents, paint etc. around the boiler or around

the air intake supply entrance of the boiler. These

substances have negative inuences on the boiler

and can lead to corrosion resulting in failure of

the boiler.

!WARNING

NOTICE

iChecking the water pressure

Check the water pressure in the central heating

installation regularly.

Use only potable water for lling.

Additives only after clearance by Rinnai.

Contact your installer in case of doubt.

Products to avoid present in boiler room

and/or around combustion air intake

Spray cans containing chloro-/fluorcarbons

Ammonium and/or ammonium solutions

Permanent wave solutions

Chlorinated waxes and/or cleaners

Swimming pool chemicals based on chlorine

Calcium chloride used for thawing

Sodium chloride used for water softening

Refrigerant leaks

Paint or varnish removers

Hydrochloric acid/muriatic acid

Cements and glues

Antistatic fabric softeners used in clothes dryers

Chlorine-type bleaches, detergents, and cleaning solvents

found in household laundry rooms

Adhesives used to fasten building products and

other similar products

Areas likel

to have contaminants

Dry cleaning/laundry areas and establishments

Swimming pools

Metal fabrication plants

Beauty shops

Refrigeration repair shops

Photo processing plants

Auto body shops

Plastic manufacturing plants

Furniture refinishing areas and establishments

New building construction

Remodeling areas

Garages with workshops

DANGER

Operating instructions Rinnai E-Series

The Rinnai E boiler is a room sealed, condensing

and modulating central heating boiler with an

integrated hot water facility.

The boiler is provided with a integrated control

system. Because an outdoor sensor is connected

to the boiler, the boiler works weather dependantly.

This means that the boiler control measures the

outside temperature and ow temperature. With

this data the boiler calculates the optimal ow

temperature for the installation.

When the boiler is connected to an RS100 room

thermostat information can be retrieved from the

boiler. For more information about the Rinnai

thermostats. Please refer to the user manuals.

On the bottom left side of the front panel there is a

small door. Through the transparent panel you can

see the boiler status on the display. After opening

this door you will nd the function buttons.

On the following pages you will nd the explanation

of the function buttons and display messages.

Description of the boiler

RS100

Operating instructions Rinnai E-Series

Explanation of the function buttons

Only qualied personel who are trained for

these boilers are permitted to make alterations

in the controller to chronolize the boiler to the

installation.

1. Display.

See following pages for further information.

2. ON-OFF Switch (Placed separately next to

the boiler). This switch turns the power supply

to the boiler on or off.

3. Central Heating program button.

Switching the Central Heating on or off (Led

on/off);

4. Hot Water program button.

Switching the Domestic Hot Water (DHW)

facility on or off (Led on/off);

5. Pump program button.

When the pump program LED is ON, the pump

is switched into a continuous circulation mode.

When the pump mode is switched OFF, LED is

off the pump is control by the boiler processor.

In most situations it is best to leave the pump

mode OFF and let the boiler control cycle the

pump as needed.

During freezing temperatures it is possible (when

there is no outside sensor connected), to manually

place the circulation pump in constant circulation

mode, thus reducing the chance of freezing pipes

(garage, attic or other cold spaces / rooms) which

are sensitive to frost.

When the pump is switched

on continuously it can lead to

undesired heating up of the

central heating system during

the summer.

NOTICE

Operating instructions Rinnai E-Series

6 Mode-button.

Only for Service personel

7 Step-button.

After briey pressing, the water pressure can

be retrieved.

After pressing for 5 seconds it switches from

the Good-state to technical read out and vice

versa (see following pages);

8 Reset-button.

When a fault occurs it will be shown by the

ashing E (Error) with a number code after

which the boiler is shut down. After pressing

the reset key you can try to start the boiler

again. If the error message keeps occurring

contact your installer.

DO NOT attempt to make repairs or remove

any of the boiler panels. Contact a qualied

service agency to make necessary repairs or

adjustments.

!WARNING

Operating instructions Rinnai E-Series

The boiler display

Two boiler displays, “Good or Technical” see below.

Good

or standard read out.

During this reading the display will only show what

is necessary. Under normal circumstances the

display will give a Good reading. In case of a

fault this will be shown with, alternate display of

Good, with an E or BL code. See further "Errors,

maintenance and warranty" .

Technical

The second way is a technical read out. In normal

situations the following will be shown:

• on the left the status in which the boiler is active

(see bottom of this page);

• on the right the supply temperature in °F;

• the water pressure in the installation in PSI.

When a message (E or BL code) is necessary this

will be shown instead of the technical read out.

To switch over from the Good-state to the

Technical read out (and vice versa):

- Press 5 sec. on the STEP-button.

Operation indication

(in the first display position by technical read out)

No heat demand

Fan pre/post purge

Ignition phase

Burner active on central heating

Burner active on DHW

Fan check

Burner off when room thermostat is demanding

Pump overrun phase for central heating

Pump overrun phase for hot water

Burner off because of to high ow temperature

Automatic de-aeration program (Press no button for 17 min.)

Autres manuels pour E75CN

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Rinnai Chaudière

Rinnai

Rinnai E75CRN Note de version

Rinnai

Rinnai Continuum HV Series 1 Manuel utilisateur

Rinnai

Rinnai Q175S Manuel utilisateur

Rinnai

Rinnai EPA-09-0001 Manuel utilisateur

Rinnai

Rinnai E60SRN Instructions d'installation et d'entretien

Rinnai

Rinnai Q130SN Mode d’emploi

Rinnai

Rinnai E50CRN Note de version

Rinnai

Rinnai M060S Manuel utilisateur

Rinnai

Rinnai Q Premier QP130N Mode d’emploi

Rinnai

Rinnai REB-KBI2424FF Manuel d'utilisation

Rinnai

Rinnai E85SRN Note de version

Rinnai

Rinnai M060C Manuel utilisateur

Rinnai

Rinnai Q series Manuel de programmation

Rinnai

Rinnai Mirai 24 Manuel utilisateur

Rinnai

Rinnai REB-KA2024FF Manuel utilisateur

Rinnai

Rinnai E110CN Note de version

Rinnai

Rinnai aiM 65 M/S Manuel utilisateur

Rinnai

Rinnai E50C Note de version

Rinnai

Rinnai CHS199100 Manuel utilisateur

Rinnai

Rinnai I Series Manuel utilisateur

Rinnai

Rinnai RCB301AN Manuel utilisateur

Rinnai

Rinnai CHS1998HEiN Manuel utilisateur

Rinnai

Rinnai REU-2018W Manuel utilisateur

Rinnai

Rinnai E50C Mode d’emploi

Manuels Chaudière populaires d'autres marques

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur

Radijator

Radijator BIO max 23.1 Manuel utilisateur

Brunner

Brunner BSV 20 Manuel utilisateur

Buderus

Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur

Potterton

Potterton 50e Fiche technique

UTICA BOILERS

UTICA BOILERS TriFire Manuel utilisateur

Joannes

Joannes LADY Series Manuel

ECR International

ECR International UB90-125 Manuel d'instructions

Froling

Froling FHG Turbo 3000 Manuel utilisateur

Froling

Froling P4 Pellet 8 - 105 Manuel utilisateur

U.S. Boiler Company

U.S. Boiler Company K2 Manuel utilisateur

Henrad

Henrad C95 FF Manuel utilisateur

NeOvo

NeOvo EcoNox EF 36 Manuel utilisateur

Potterton

Potterton PROMAX SL 12 Manuel utilisateur

Eco Hometec

Eco Hometec EC 25 COMPACT Manuel utilisateur

Viessmann

Viessmann VITODENS 200 Mode d’emploi

Baxi

Baxi Prime 1.24 Manuel utilisateur

REXNOVA

REXNOVA ISA 20 BITHERMAL Manuel utilisateur
