Prism III Specifications 2002860_A

Rimage®Prism III Printer Specifications

This document provides product specification information for the Rimage Prism III printer. For more information on

how to operate, configure, and maintain the Prism printer, refer to the Rimage Prism III Printer User Guideavailable

at www.rimage.com/support. From the Support menu select: Printer Series > Prism Printer > User Manuals tab.

Note: For autoloader specifications, refer the specifications document found at www.rimage.com/support. From the

Support menu, select: Product Series > Product Name > User Manuals tab.

Prism III Printer / Model Name: CDPR6

Physical size

Height 6.0 in (15.24 cm)

Width 8.5 in (21.59 cm)

Depth*

With printer tray closed: 14.0 in (35.56 cm)

With printer tray extended: 21.8 in (55.3 cm)

Weight 20 lb (9.07 kg)

*Leave an additional 3.5 in (9 cm) for cabling.

Printing

Print speed 0.65 inches/second @ 300 x 300 dpi, typical

0.45 inches/second @ 300 x 600 dpi, typical

Print modes Single-pass (standard) and double-pass (monocolor ribbon only) for improved

print quality on some media types.

Print quality 300 x 300 or 300 x 600 dpi (11.8 dots per mm)

Print direction Images are printed from a top to bottom orientation as the media is moving out of

the machine.

Label design

requirements

Note: These requirements are for labels designed and printed with CD Designer.

Refer to the Prism user guide for more information about label design

requirements.

File format .btw

Color mode RBG

Resolution 300x300 dpi or 300x600 dpi

Label design size Width: 5.12 in (1536 pixels)

Height:

4.52 in (1356 pixels)

Printable area Disc: 4.567 in (116 mm)

Hub: 1.496 in (38 mm)

Prism III Specifications 2002860_A

Prism III Printer / Model Name: CDPR6

Media

requirements 120 mm CD, DVD, and BD media with thermal print compatible surface

Ribbon

requirements

Important! The Prism III printer will only accept and use the following Rimage

ribbons:

2002364 Black

2002365 CMY

2002366 Red

2002367 Blue

Monocolor ribbon Color: Black, red, and blue monocolor ribbon

Capacity: 2100 discs

Multi-color ribbon

Color: 3-color (CMY) panel ribbon

Capacity: 500 discs

Minimum PC

requirements

Important! If you do not understand these requirements, ask your computer

technician for help or refer to your PC documentation.

Supported operating

systems

•Windows 7 Professional and Ultimate (32-/64-bit)

•Windows 7 Enterprise (64-bit)

•Windows XP Professional SP3 (32-bit)

•Windows Vista Business, Enterprise, and Ultimate with SP2 (32-bit)

Interface USB 2.0

Power 100 – 240 VAC, 60/50 Hz, 1.10 – 0.45 Amp, auto-ranging 110 watt maximum

Data Transmission

System 13.56 MHz, TI Model Number: TRF7960

Temperature and

humidity

Printer

Ribbon

Operating

temperature 41° to 95° F (5° to 35° C)

Humidity 20% to 80% RH non-condensing 30% to 80% relative humidity, non-

condensing. Avoid direct sunlight.

Storage

temperature 5° to 95° F (-15° to 35° C) 23° to 104° F (-5° to 40° C)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rimage Imprimante

Rimage

Rimage Prism Manuel de service

Rimage

Rimage AutoEverest AutoPrinter Manuel utilisateur

Rimage

Rimage Prism III Manuel utilisateur

Rimage

Rimage Professional 3400 Manuel utilisateur

Rimage

Rimage 480i Instructions d'utilisation et de sécurité

Rimage

Rimage 480i Manuel utilisateur

Rimage

Rimage Amigo II Instructions d'installation
