Ricoh Ri 100 Guide de démarrage rapide
1
Notes for Users
This supplement includes corrections and additional information for the manuals
provided with this machine.
Operating Instructions
Safety Information > Safety Precautions to Be Followed > Handling the main
machine
Correction
Error Corrections
Do not put fabrics on the front cover
while it is open. Doing so may damage
the machine, cause injury or burns.
Do not put objects on the front cover
while it is open. Doing so may damage
the machine, cause injury or burns.
Do not open the front cover if the fabric
smokes or ignites. Doing so may cause
a fire.
Disconnect the power plug immediately
from the outlet if the fabric smokes or
ignites. Do not open the front cover.
Doing so may cause a fire.
Do not touch the terminals with your
hand or a metal object. Doing so may
cause a short circuit, resulting in smoke
or fire.
This caution does not apply to this ma-
chine.
2
Safety Labels of This Machine > Positions of WARNING and CAUTION labels
Correction
Error Corrections
1 2
DSA131
1, 2.
Do not touch the surroundings de-
scribed by the safety symbol labels.
1 2
DSA131
1.
Do not touch the inside of the finisher
because it may become very hot. Do-
ing so may cause burns.
The weight of the finisher is about 16.5
kg (36.4 lb.). When moving the finisher,
hold the handle at the center bottom of
both sides and lift it slowly so that you
do not strain your body.
2.
Do not touch the inside of the finisher
because it may become very hot. Do-
ing so may cause burns.
3
Smoothing Wrinkles/Flattening Fibers (Press ) > Standard mode
Smoothing Wrinkles/Flattening Fibers (Press ) > Professional mode
Fixing Ink (Fix ) > Standard mode
Fixing Ink (Fix ) > Professional mode
Correction
Error Corrections
Take out the cassette.
Remove the cassette, and then close
the front cover. An alarm sounds if you
leave it open more than 10 seconds.
Take out the cassette.
Remove the cassette, and then close the
front cover. If you leave it open more
than 10 seconds, an alarm sounds to
warn you of risks such as injury or burns.
Troubleshooting
Correction
Error Corrections
After the high temperature caution
indicator goes out, wait until the heater
cools down sufficiently, and then wipe
off the dirt.
After the high temperature caution in-
dicator goes out and the heater cools
down sufficiently, wipe off the dirt with
a soft, dry or damp cloth.
Specifications
Correction
Error Corrections
■Power consumption
1,000W
■Power consumption
980-1,160W
980-1,300W
4
Operating Instructions
Additional information
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervi-
sion or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children.
Safety Information
Additional information
• This product can be safely used in areas whose height above sea level is 2,500
meters (8,202.1 feet) or below.
5
Safety Information > Safety Precautions to Be Followed > Handling the main
machine
Additional information
• When loading or removing a cassette, hold the part (a). If you hold another
part, you might be burned.
(a)
DXD001
• The high-temperature state inside the machine may continue. As it may cause
injury or burns, be sure to close the front cover (b) after removing the cas-
sette.
DSB061
(b)
6
Precautions when using the machine
Additional information
• Take out the cassette from the finisher soon after pressing (smoothing wrinkles/
flattening fibers) or fixing ink is completed. Leaving the cassette in the hot finisher
for a long time may cause the cassette to malfunction.
1
2
1 2
DSA131
1 2
DSA131
■
W
■
W
W
