Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get

maximum versatility from this machine all operators should carefully read and follow the instructions in

this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related

to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

Power Source:

220 – 240 V, 50/60 Hz, 1.5 A or more

Please be sure to connect the power cord to a power source as above. For details about power source,

see ⇒P.194

“Power connection”

Notes:

Some illustrations might be slightly different from your machine.

Certain options might not be available in some countries. For details, please contact your local dealer.

Two kinds of size notation are employed in this manual. With this machine refer to the Metric version.

For good print quality, Ricoh recommends that you use genuine Ricoh master and ink.

Ricoh shall not be responsible for any damage or expense that might result from the use of parts other

than genuine Ricoh parts in your Ricoh office product.

Declaration of Conformity

“The Product complies with the requirements of the EMC Directive 89/336/EEC and the Low Voltage

Directive 73/23/EEC.”

In accordance with ISO Standard 7001, this machine uses the following symbols for the main switch:

ameans POWER ON.

bmeans POWER OFF.

Safety Information

When using your machine, the following safety precautions should be always

followed.

Safety During Operation

In this manual, the following important symbols are used:

Examples Of Indications

WARNING:

Ignoring this warning could cause serious injury or even death.

CAUTION:

Ignoring this caution could cause injury or damage to property.

Symbols Rmean a situation that requires you take care.

Do NOT carry out the operation represented by this symbol m.

This example means “Do not take apart”.

Symbols mean you MUST perform this operation.

This example means “You must remove the wall plug”.

•

Only connect the machine to the power source described on

the inside front cover of this manual.

•

Avoid multi-wiring.

•

Do not damage, break or make any modifications to the pow-

er cord. Do not place heavy objects on it, pull it hard or bend

it more than necessary. These actions could cause an elec-

tric shock or fire.

•

Do not plug or unplug the power cord with your hands wet.

Otherwise, an electric shock might occur.

•

Make sure the wall outlet is near the machine and freely ac-

cessible so that in event of an emergency it can be un-

plugged easily.

•

Do not remove any covers or screws other than those spec-

ified in this manual. Some parts of the machine are at a high

voltage and could give you an electric shock. When the ma-

chine needs to be checked, adjusted, or repaired, contact

your service representative.

•

Do not take apart or attempt any modifications to this ma-

chine. There is a risk of fire, electric shock, explosion or loss

of sight.

•

If the machine looks damaged or breaks down, smoke is

coming out, there is a strange smell or anything looks unu-

sual, immediately turn off the main switch then unplug the

power cord from the wall. Do not continue using the ma-

chine in this condition. Contact your service representative.

•

If metal, liquid or foreign matter falls into the machine, turn

off the main switch and unplug the main power cord. Con-

tact your service representative. Do not keep using the ma-

chine with a fault or defect.

•

Do not put any metal objects or containers holding water

(e.g. vases, flowerpots, glasses) on the machine. If the con-

tents fall inside the machine, a fire or electric shock could

occur.

WARNING:

iii

•

Keep the machine away from humidity and dust. A fire or an elec-

tric shock might occur.

•

Do not place the machine on an unstable or tilted surface. If it top-

ples over, it could cause injury.

•

After you move the machine, fix it with the caster fixture. Other-

wise, the machine might move or come down to cause a personal

injury.

•

When you move the machine, unplug the power cord from the

wall outlet to avoid fire or electric shock.

•

When the machine will not be used for a long time, unplug the

power cord.

•

When you pull out the plug from the socket, grip the plug to avoid

damaging the cord and causing fire or electric shock.

•

If you use the machine in a confined space, make sure there is a

continuous air turnover.

•

Do not reuse stapled paper. Do not use aluminum foil, carbon-

containing paper or other conductive paper. Otherwise, a fire

might occur.

•

This machine has been tested for safety using this supplier's

parts and consumables. We recommend you only use these

specified supplies.

•

This equipment is only to be installed by a qualified service per-

sonnel.

•

Deliver to collection point for waste products. Do not be disposed

of via domestic refuse collection.

•

If ink comes into contact with your eyes, rinse immediately in run-

ning water. In the case of any abnormal symptoms, consult a

doctor.

CAUTION:

•

Keep the ink or ink container out of reach of children.

•

If ink is ingested, force vomiting by drinking a strong saline solu-

tion and consult a doctor immediately.

•

Be careful not to cut yourself on any sharp edges when you reach

inside the machine to remove misfed sheets of paper or masters.

•

While printing, do not touch the belt at the end of the paper deliv-

ery tray or the job separator. You might be injured.

When your machine is equipped with the PC controller option:

•

Do not place this equipment on an unstable or tilted surface. If

you do, it could fall.

•

Do not place heavy objects on top of this equipment. They might

cause the equipment to become unstable and topple over.

When your machine is equipped with the PC controller option:

•

If by any chance this equipment falls over or a breakage occurs

(e.g., the cover), turn off the main switch of this equipment, un-

plug the power cable and contact your service representative. If

you continue to use the equipment in this state it could result in

fire or electric shock.

How To Read This Manual

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation that might result in

death or serious injury when you misuse the machine without following the in-

structions under this symbol. Be sure to read the instructions, all of which are de-

scribed in the Safety Information section.

CAUTION:

This symbol indicates a potentially hazardous situation that might result in mi-

nor or moderate injury or property damage that does not involve personal injury

when you misuse the machine without following the instructions under this

symbol. Be sure to read the instructions, all of which are described in the Safety

Information section.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be

damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before op-

erating.

Note

This symbol indicates precautions for operation, or actions to take after misop-

eration.

Limitation

This symbol indicates numerical limits, functions that cannot be used together,

or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[ ]

Keys that appear on the machine's panel display.

{ }

Keys built into the machine's operation panel.

Making Prints

Before making prints using this ma-

chine, you have to make a master by

pressing the {

Start

}key. When you

press the {

Start

}key, the machine

scans the original image and makes a

master. This procedure describes

how to make basic prints.

ASet your originals.

When you set original on the

exposure glass (contact glass)

ASet one original face down.

When you set originals in the

optional document feeder

ASet the originals face up.

BPress the {

{{

{

Start

}

}}

}key.

CPress the {

{{

{

Proof

}

}}

}key.

Check the print image.

Reference

When you want to change the

image position, see ⇒P.25 “Ad-

justing Print Image Position”.

When you want to increase the

image density, press the {W}

key. See ⇒P.26 “Adjusting Print

Image Density”.

When you want to decrease the

image density, press the {V}

TPEH270E

TPEH281E

TPES050E

TPES060E

TPES560E
