Ricoh M-G1a Manuel

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 1

Model M-G1a/M-G1b/M-G1L/M-G1W/R-G1 Training

Machine Codes: J017/J019/J021/J023/J018

Full Course - Based on previous GelJet Machines

Options: Multi-bypass Tray BY1000 (J507)

Multi-bypass Tray BY1030 (J309)

Multi-bypass Tray BY1020 (J311)

Paper Feed Unit TK1110 (J307)

Paper Feed Unit TK1110 (J308)

Photo of:

J017/J019

Revised 28 January 2010

Slide 147 deleted

Revised 19 April 2010

200 sheet multi-bypass tray (J309) added

Revised 30 May 2011

M-G1W (J023) added (including new duplex unit)

BY1020 multi-bypass tray (J311) added

TK1140 Paper Feed Unit (J308) added

Machine codes / development names / product names

J017 / M-G1a / GX e3300N

J019 / M-G1b / GX e3350N

J021 / M-G1L / GX e2600N

J023 / M-G1W / GX e7700N

J018 / R-G1 / GX e5550N

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 2

J017/J019/J021/J023/J018

Service Training

1) Product Outline

M-G1a/M-G1b/M-G1L/M-G1W/R-G1

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 3

Low TCO with Useful Business Specifications

New level color

» Unique technology for reducing cost per-page of color printing

High productivity

» 29 ppm (J017/J019/J021/J023)

» 30 ppm (J018)

Fast duplex speed (J017/J019/J018)

» Over 80% of simplex speed (over 75% for J023)

– There is no duplex option for J021.

First print speed [For more details, see service manual]

» J017/J019/J021

– Monochrome: Less than 6.0 seconds

– Color: Less than 7.5 seconds

» J023

– Monochrome: Less than 6.5 seconds

– Color: Less than 9.0 seconds

» J018

– Monochrome: Less than 4.0 seconds

– Color: Less than 5.0 seconds

Product Concept - 1/2

TCO – Total Cost of Ownership

RPCS - Refined Printing Command Stream

PPM - Prints Per Minute

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 4

Eco-Friendly

Low power consumption

»35 W or less in print mode (J017/J019/J021/J023)

»38 W or less in print mode (J018)

New Energy Star compliant

BAM compliant

Plant-based plastic

Advanced Technology Improves Usability

Counter function for click charge

Counter data obtained via @Remote

Multi-bypass trays supports different types of paper

User-friendly tilting operation panel

Product Concept - 2/2

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 5

Improved ink

New ink provides improved performance in high temperature and/or

low humidity environments. The better flowing inks gel quickly, with

less ink clogging, which can cause poor images or trigger errors like

SC999, SC990, etc.

Lower ink consumption

Redesigned print heads, ink supply unit, head cleaning algorithm,

and reversible pumps

Redesigned ink level detection pins prevent machine tilt-induced

ink leakage

Effective for up to 30 degree angle

Newly designed bidirectional ink pumps with independent motor

for each ink color

Reversible pumps create vacuum in head tanks without wasting ink.

Improvements (over previous model) - 1/3

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 6

Adjustable tilting operation panel

Improved paper tray unit

Easy to remove and reinsert

New side fence locks

More skew-resistant

Fewer jams

More compact

Shorter depth (J017/J019/J021/J018/J023)

Improved Ink Collector Unit Design

Access from front of machine (easy to change)

Sealed unit (no ink leakage when changing)

ID chip added (counter automatically reset when replaced)

Improvements (over previous model) - 2/3

Tilting Operation Panel

Position of the tilting operation panel is made by slowly pulling it forward, and

then carefully letting it back until it catches on one of two latches.

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 7

Improved Duplex Unit (J017/J019/J023/J018)

Automatic locks (unit automatically locks into place when

pushed in)

» This helps prevent paper jams caused by incorrectly inserted unit.

Improved Head Maintenance

New method helps to prevent clogged nozzles

Carriage Unit / Ink Supply Unit

Carriage Unit and Supply Unit now Replaceable

» Carriage Unit & Ink Supply Unit

– J017/J019/J021/J023

» Carriage Unit (alone)

– J018

New right-side Ink Sump

Expected to last the lifetime of the machine

Easier cover removal and replacement

Improvements (over previous model) - 3/3

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 8

Print Heads

J017/J019/J021/J023

» Two print heads (YM & BC)

J018

» Four print heads (YM & BB & CC & MY)

Motors & Pumps

J017/J019/J021/J023

» 4 motors and 4 pumps (reversible)

– Each color has its own motor & pump.

J018

» 6 motors and 6 pumps (reversible)

– Dual-color heads are supplied by two pumps each, one for each

color.

– Dual-channel black and cyan heads have one motor per head

(single ink tank feeds two output channels).

Model Differences - 1/2

Print Heads for J017/J019/J021J023

Two dual-channel, 2-color print heads

¾Yellow & Magenta and Black & Cyan (YM & BC)

Print Heads for J018

Two dual-channel, 2-color print heads

¾Yellow & Magenta and Magenta & Yellow (YM & MY)

Two dual-channel, single-color print heads

¾Cyan & Cyan and Black & Black (CC & BB)

Note: All four print heads are same dual-channel type & size. Single

color, dual-channel heads have single head ink tank (which feeds both

channels), but otherwise are identical to dual-channel, two-color heads.

Motors & pumps for J017/J019/J021/J023

4 motors and 4 pumps (reversible)

¾Each color has its own motor & pump.

Motors & pumps for J018

6 motors and 6 pumps (reversible)

¾Dual-color heads are supplied by two pumps each, one for each color.

¾Dual-channel black and cyan heads have one motor per head (single ink

tank feeds two output channels, so only one pump is necessary).

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 9

Ink Cartridges

J017/J019/J021/J023

» M-size only

J018

» M-size or L-size

Operation Panel

J017/J019/J023

»White

J021

»Grey

J018

» White (on slightly larger panel)

Duplex Unit

J017/J019/J018/J023

» Standard

J021

» Not available

Ink collector unit is larger in J018.

The horizontal encoder film is longer in J018 due to wider print

head carriage unit. It is also longer in the J023 due to greater

machine width.

Model Differences - 2/2

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Model: M-G1a/M-G1b/M-G1L/M-G1W/R-

Machine Codes:

J017/J019/J021/J023/J018

Slide 10

J017/J019/J021/J023/J018

Service Training

2) Specifications

No additional notes.
